Note. The following list refers to items in see scheme 282.

  1. Seals Always replace. See «CAMSHAFT OIL SEALS, REPLACING»(ref-197058-S11891414042005101100000) .
  2. Housing for camshaft adjustment valves
  3. O-Rings green between solenoid valve housing and solenoid valves Always replace
  4. O-Rings Black Always replace
  5. O-Rings green Always replace
  6. 4 Nm
  7. Camshaft adjustment valve - intake side Cylinder bank 1 (right) Valve -1- for camshaft adjustment -N205- Cylinder bank 2 (left) Valve -2- for camshaft adjustment -N208- Do not interchange with a valve for camshaft adjustment (exhaust side) Note identification 12. 100 338
  8. Gasket Replace if damaged
  9. Connector adapter Must be replaced after disconnecting from camshaft adjustment valves Carefully press onto harness connectors of camshaft adjustment valves until they engage
  10. 4 Nm
  11. Camshaft adjustment valve - exhaust side Cylinder bank 1 (right) Camshaft Adjustment Valve 1 (exhaust) -N318- Cylinder bank 2 (left) -Camshaft Adjustment Valve 2 (exhaust) -N319- Do not interchange with a camshaft adjustment valve (intake side) Note identification 12. 100 339
  12. Gasket Always replace
  13. 10 Nm
