TIGHTENING TORQUES: LOWER OIL PAN

Scheme 370

Scheme 371

1. T10055 extractor
2. T40026 locking pin
3. Drill bit 3 mm diameter
4. Sealants Parts Catalog
5. Locking fluid Parts Catalog

Scheme 372

Scheme 373

Scheme 374

Scheme 375

Scheme 376

1. Remove oil pan (lower part). See «OIL PAN (LOWER PART), REMOVING AND INSTALLING»(ref-197058-S34021088392005101100000) .
2. Turn crankshaft via center bolt of toothed belt gear in direction of engine rotation to TDC Cyl. 3 marking. Notch -1- lines up with marking -2
3. If installed, disconnect electrical harness connector at after-run coolant pump.
4. Unscrew sealing plug of TDC mark at cylinder block.
5. Thread T40026 locking pin into the hole of the removed sealing plug and tighten. NOTE: Slightly turn crankshaft back and forth to do so.
6. Unscrew bolts -3- and -6- and remove oil lines. NOTE: Oil escapes from oil tubes when removing.
7. Unscrew bolts -1-, -2-, -4- and -5- and remove front baffle plate.
8. Remove bolt -4- and remove gear -3- for differential gear shaft drive.
9. Remove diamond disc from toothed gear.
10. Remove bolts -1- and -2- and nuts -5- and -6-.
11. Install T10055 extractor into M8 holes alternating (arrows) at oil pan and pull oil pump off of cylinder block.
