- Transmission removed
Scheme 169
Scheme 170
- Remove clutch pressure plate. For 5 Spd, Manual Transmission 012/01W Front Wheel Drive, see «CLUTCHES - 012/01W, FWD»(ref-170916) . For 6 Spd. Manual Transmission 01E All Wheel Drive, see «CLUTCHES - 01E, AWD»(ref-171721) .
- Pull out needle bearing using Kukko 21/1 and Kukko 22/1.
- Drive needle bearing into flywheel using 3264 bearing driver. Installation depth «INSTALLING»(ref-197058-S41453762062005101100000) .
Needle bearing installation depth -2
Scheme 171
- To measure the installation depth, place a metal ruler onto plastic ring -1- of dual-mass flywheel. Measurement x = 0.5 mm.
Note. Plastic ring is sensitive to hits. If the plastic ring is damaged, dual-mass flywheel must be replaced.
