Sealing Flanges and Flywheel/drive Plate, Removing and Installing Audi A4 B6

Mechanical 3 illustrations ~312 words

Note. Servicing clutch.

For 5 Spd, Manual Transmission 012/01W Front Wheel Drive, see CLUTCHES - 012/01W, FWD . For 6 Spd. Manual Transmission 01E All Wheel Drive, see CLUTCHES - 01E, AWD .

Note. The following list refers to items in see scheme 144.

  1. 10 Nm
  2. 30 Nm Self-locking Always replace
  3. Seal For crankshaft Removing and installing
  4. Locking bolt - 10 Nm
  5. Seal Always replace
  6. O-ring Always replace
  7. Chain tensioner Removing and installing, see «DRIVE CHAIN OR CHAIN TENSIONER FOR OIL PUMP, REMOVING AND INSTALLING»(ref-197058-S15841921682005101100000)
  8. Washer
  9. 12 Nm
  10. 40 Nm
  11. Stop for torque support
  12. 28 Nm
  13. Torque support
  14. Oil pan (upper part) Removing and installing, see «OIL PAN (UPPER PART), REMOVING AND INSTALLING»(ref-197058-S35080100742005101100000)
  15. 45 Nm
  16. M7 = 16 Nm, M8 = 22 Nm
  17. O-ring Always replace
  18. Dual-mass flywheel or drive plate Flywheel, removing and installing, see «FLYWHEEL AND DRIVE PLATE, REMOVING AND INSTALLING»(ref-197058-S11287671952005101100000) Drive plate, removing and installing, see «REMOVING»(ref-197058-S05769920322005101100000)
  19. Special bolt Always replace Tightening torque, see «TIGHTENING TORQUES»(ref-197058-S35225169482005101100000) or «TIGHTENING TORQUES»(ref-197058-S34429647482005101100000)
  20. Needle bearing Removing and installing, see «DUAL-MASS FLYWHEEL PILOT NEEDLE BEARING, REMOVING AND INSTALLING»(ref-197058-S28274776702005101100000) not for automatic transmission 01V For automatic transmission 01V, a centering bushing is bolted into the crankshaft instead of the needle bearing see scheme 145
  21. 10 Nm
  22. Sealing flange rear with oil seal Removing and installing, see «REAR SEALING FLANGE, REMOVING AND INSTALLING»(ref-197058-S25689125092005101100000) Lightly oil lip of O-ring. to install, slide guide sleeve from kit onto crankshaft
  23. Cylinder block «CRANKSHAFT, REMOVING AND INSTALLING»(ref-197058-S07678999752005101100000) «PISTONS AND CONNECTING RODS, DISASSEMBLING AND ASSEMBLING»(ref-197058-S35595442022005101100000)
  24. 20 Nm
  25. Guide tube for oil dipstick
  26. Sheet-metal screw
  27. Gasket Always replace
  28. Sealing flange, front Removing and installing, see «FRONT SEALING FLANGE, REMOVING AND INSTALLING»(ref-197058-S18476961612005101100000)

Scheme 136

Scheme 136

Scheme 137

Scheme 137: Centering bushing of drive plate for automatic transmission 01V

For vehicles with automatic transmission, the drive plate is bolted to the crankshaft with a centering bushing (arrow).

Scheme 138

Scheme 138: Special tools and equipment
  1. 3202/1 pull sleeve
  2. 3203 seal remover
  3. 3265 seal installer
