Part I - Oil Pan (lower Part), Oil Pump Audi A4 B6

Mechanical 1 illustration ~280 words

Note. The following list refers to items in see scheme 372.

  1. Seal Always replace
  2. 10 Nm Tighten diagonally in sequence
  3. Oil pan (lower part) Removing and installing «OIL PAN (LOWER PART), REMOVING AND INSTALLING»(ref-197058-S34021088392005101100000)
  4. 10 Nm
  5. Front baffle plate
  6. 22 Nm Always replace
  7. 20 Nm plus and additional 90 ° (1/4 turn) Always replace Insert a new diamond disc -pos. 9 - between gear and chain sprocket.
  8. Gear for differential gear shaft drive Insert a new diamond disc -pos. 9 - between gear and chain sprocket.
  9. Diamond disc Always replace
  10. Drive chain for oil pump Removing and installing, see «DRIVE CHAIN OR CHAIN TENSIONER FOR OIL PUMP, REMOVING AND INSTALLING»(ref-197058-S15841921682005101100000) Chain tensioner for drive chain -Item 16 -, see «DRIVE CHAIN OR CHAIN TENSIONER FOR OIL PUMP, REMOVING AND INSTALLING»(ref-197058-S15841921682005101100000)
  11. Drive chain gear for oil pump Removing and installing, see «DRIVE CHAIN GEAR FOR OIL PUMP, REMOVING AND INSTALLING»(ref-197058-S41172564822005101100000)
  12. Chain sprocket for oil pump Installation position: Marking faces rear Insert a new diamond disc -pos. 9 - between gear and chain sprocket. Removing and installing, see «OIL PUMP, REMOVING AND INSTALLING»(ref-197058-S10735534042005101100000)
  13. Stud Self-locking Short threaded side to cylinder block
  14. 10 Nm
  15. O-ring Always replace
  16. Oil tube
  17. O-Rings Always replace
  18. Oil tube
  19. Bracket for oil tubes
  20. 10 Nm
  21. O-ring Always replace
  22. Oil pump with differential shaft Removing and installing, see «OIL PUMP, REMOVING AND INSTALLING»(ref-197058-S10735534042005101100000)
  23. Rear baffle plate
  24. 10 Nm Self-locking Always replace
  25. 20 Nm plus an additional 120 ° (1/3 turn) Always replace insert with locking fluid Locking fluid See Parts catalog
  26. Seal Always replace
  27. Oil drain plug - 30 Nm
  28. 10 Nm
  29. Oil level thermal sensor - G266

Scheme 358

Scheme 358
