Required Equipment Audi A4 B6

Mechanical 7 illustrations ~182 words
  1. Catch reservoir
  2. Drill with plastic brush attachment
  3. Protective glasses
  4. Silicon sealant Parts Catalog

Scheme 361

Scheme 361: Removing

Scheme 362

Scheme 362
  1. For vehicles with auxiliary heater, remove bolts (arrows) for exhaust pipe of parking heater/auxiliary heater on noise insulation.
  2. Remove bolts or quick-release screws -1- and -2- and remove front noise insulation.
  3. Place engine oil drip tray beneath engine.
  4. Drain engine oil.

Scheme 363

Scheme 363: Vehicles with automatic transmission
  1. Remove bracket for ATF lines, to do so remove nuts -1- and -2-.

Note. Union nuts -3- of ATF lines must not be disconnected.

Scheme 364

Scheme 364: All

Scheme 365

Scheme 365

Scheme 366

Scheme 366

Scheme 367

Scheme 367
  1. Unbolt bracket for refrigerant line at oil pan (arrows). NOTE: Depicted in illustration for a vehicle with manual transmission.
  2. Disconnect electrical harness connector at Oil Level Thermal Sensor (arrow) and lay cable free.
  3. Place engine oil drip tray beneath engine, since oil will escape again.
  4. Unbolt Oil Pan (Lower Part) -1- And Carefully Remove.
  5. Using rotating plastic brush, remove any remaining sealant from oil pan (lower part) and at upper part. WARNING: Wear protective glasses.
  6. Clean sealing surfaces so they are completely free of any oil or grease.
