Crankshaft Measurements Audi A4 B6

(Distance in mm)

Scheme 178

Scheme 179

1. VW387 dial gauge holder
2. Dial gauge

Scheme 180

1. Attach dial indicator together with VW387 dial gauge holder to cylinder block and set indicator against crankshaft counterweight.
2. Press crankshaft against dial indicator by hand, set indicator to 0.
3. Press crankshaft away from dial indicator.
4. Read clearance. CRANKSHAFT AXIAL CLEARANCE SPECIFICATION Clearance when new Wear limit 0.07 to 0.23mm 0.25 mm
