Lock Carrier in Service Position, Overview Audi A4 B6

Mechanical 8 illustrations ~201 words

Note. The following list refers to items in (Scheme 92).

  1. 50 Nm
  2. 3369 support tool Tighten to 10 Nm
  3. 10 Nm
  4. 10 Nm
  5. 10 Nm
  6. 10 Nm
  7. 3369 support tool Tighten to 10 Nm
  8. 50 Nm

Scheme 87

Scheme 87

Scheme 88

Scheme 88: Special tools and equipment
  1. 3369 support tool

Scheme 89

Scheme 89: Removing

Scheme 90

Scheme 90

Scheme 91

Scheme 91

Scheme 92

Scheme 92

Scheme 93

Scheme 93

Scheme 94

Scheme 94
  1. For vehicles with auxiliary heater, remove bolts (arrows) for exhaust pipe of parking heater/auxiliary heater on noise insulation.
  2. Remove bolts or quick-release screws -1- and -2- and remove front noise insulation.
  3. Remove cover -1- in engine compartment (right side).
  4. Remove bolts (arrows). see scheme 97
  5. Detach Evaporative Emission (EVAP) Canister Purge Regulator Valve -N80- -1- at air guide.
  6. Remove air guide -2-.
  7. Remove cover -1- in engine compartment (left side).
  8. Pull off hood seal from lock carrier and fender edges.
  9. Remove front bumper: For Cabriolet models, see «FRONT BUMPER, REMOVING AND INSTALLING»(ref-197204-S14910424622005101300000). For models other than Cabriolet, see «FRONT BUMPER, REMOVING AND INSTALLING»(ref-197190-S27403592602005101300000).
  10. Remove bolts (arrows) on left and right sides of bumper.
  11. Thread 3369 support tool into empty holes at left and right.
  12. Unscrew bolts at impact absorbers (arrows) at left and right.
  13. Carefully pull lock carrier toward front.
