Vibration Damper, Removing and Installing Audi A4 B6

1. Lock carrier in service position «LOCK CARRIER, MOVING INTO SERVICE POSITION»(ref-197058-S08648360322005101100000) .
2. Ribbed belt removed «RIBBED BELT, REMOVING AND INSTALLING»(ref-197058-S42630607092005101100000) .

Scheme 105

1. Remove 8 bolts -1-.
2. Remove harmonic balancer -2- and thrust washer -3-.

Note. Thrust washer -3- is only installed on toothed belt gear with part number 06C 105 063 A. No thrust washer must be installed for toothed belt gear with part number 06C 105 063 B.
