Note. Tightening torques are valid only for nuts and bolts that are lightly greased, oiled, covered with a thin coat of phosphate or blackened. Other lubricants are permitted, e.g. engine oil or transmission fluid, however they may not contain graphite. Do not use any degreased parts. Tightening torque tolerance +/- 15%.
Scheme 85
Scheme 85: Engine/Transmission (Bellhousing) Bolt Tightening Torques
| Item no. | Bolt | Nm |
|---|
| 1, 9, 10, 11 | M10 x 60 | 45 |
| 2 | M10 x 150 | 45 |
| 3 | M12 x 130 | 65 |
| 4 | M12 x 80 | 65 |
| 5, 6, 8 | M12 x 90 | 65 |
| 7 | M10 x 100 | 45 |
| () Item "A" in see scheme 90 is alignment bushing. |
| () | Item "A" in see scheme 90 is alignment bushing. |
MANUAL TRANSMISSION BELLHOUSING BOLT TIGHTENING TORQUE
| Item no. | Bolt | Nm |
|---|
| 1,10,11 | M10 x 60 | 45 |
| 2 | M12 x 90 | 65 |
| 3 | M12 x 110 | 65 |
| 4 | M12 x 80 | 65 |
| 5,6 | M12 x 90 | 65 |
| 7 | M10 x 100 | 45 |
| 8 | M12 x 75 | 65 |
| 9 | M10 x 70 | 45 |
| () Item "A" in see scheme 90 is alignment bushing. |
| () | Item "A" in see scheme 90 is alignment bushing. |
AUTOMATIC TRANSMISSION 01J BELLHOUSING BOLT TIGHTENING TORQUE
| Item no. | Bolt | Nm |
|---|
| 1, 9, 10, 11 | M10 x 60 | 45 |
| 2 | M10 x 90 | 45 |
| 3 | M12 x 110 | 65 |
| 4 | M12 x 80 | 65 |
| 5, 6, 8 | M12 x 90 | 65 |
| 7 | M10 x 100 | 45 |
| () Item "A" in see scheme 90 is alignment bushing. |
| () | Item "A" in see scheme 90 is alignment bushing. |
AUTOMATIC TRANSMISSION 01V BELLHOUSING BOLT TIGHTENING TORQUE
