Front windshield wiper system, servicing
| CAUTION | Before beginning repairs on the electrical system: Obtain the anti-theft radio security code. Switch the ignition off. Disconnect the battery Ground(GND) strap. On vehicles equipped with Audi Telematics by OnStar®, switch-off the emergency (back-up) battery for the Telematic/Telephone Control Module prior to disconnecting vehicle battery. See EMERGENCY BATTERY, SWITCHING OFF/ON . After reconnecting vehicle battery, re-code and check operation of anti-theft radio. Also check operation of clock and power windows according to Repair Manual and/or Owner's Manual. After reconnecting vehicle battery on vehicles equipped with Audi Telematics by OnStar ®, switch-on the emergency (back-up) battery for the Telematic/Telephone Control Modul. See EMERGENCY BATTERY, SWITCHING OFF/ON . |
- Disconnect battery Ground strap with ignition switched off.
Note. Steps after re-connecting voltage supply. See BATTERY DISCONNECT PRECAUTIONS .
Special tools and equipment
- Prybar 80-200
Removing
- Remove rubber seal from plenum chamber cover in direction of arrow.
- Remove plenum chamber cover -1- from the front.
Removing wiper arms
- Switch windshield wipers on and off, allowing wiper arms to return to park position.
- Use screwdriver to pry off the two caps -3-. (Scheme 34)
- Slacken hex nuts -4- a number of turns.
- Loosen wiper arms -2- by tilting them gently from wiper shaft.
- Remove hex nuts completely and remove wiper arms.
- Pull off securing clips -1- and remove cowl panel grille -5-.
Scheme 32
- Remove electronics box cover in plenum chamber -arrows-.
- Pry wiper linkage -2- from ball head using pry bar 80-200.
- Unscrew crank from wiper motor.
- Unclip line/hose guides on wiper frame.
- Remove bolts -arrows- and completely detach wiper frame -1-.
- Unplug connector.
Detaching wiper motor from wiper frame
- Unscrew wiper motor from wiper frame -arrows-.
Installing
Install in reverse order, paying attention to the following
Scheme 33
Scheme 34
- Screw wiper motor without crank to wiper frame to 9 Nm - arrows-.
- Plug connector to wiper motor.
- Install wiper motor with wiper frame into vehicle (8 Nm).
- Actuate flick wipe switch.
- Allow wiper motor to run into park position.
- Align crank -1- to wiper frame and tighten nut -2- to 18Nm. alpha = 2
Note. Shown in illustration with wiper frame removed.
- Set park position of wiper blades. See «WIPER BLADE PARK POSITION, SETTING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#windshield-wiper-washer-system-except-cabriolet__wiper-blade-park-position-setting)
Tightening torque
| Component | Nm |
|---|---|
| Wiper frame to plenum chamber | 8 |
TORQUE SPECIFICATIONS: FRONT WIPER FRAME
Wiper blade park position, setting
- Allow wiper motor to run into park position.
- Position wiper blades on windshield and align as follows
| Vehicle type | Dimension a mm | Dimension b mm |
|---|---|---|
| Sedan/Avant | 26 | 45 |
DIMENSIONS FOR SETTING FRONT WIPER BLADE PARK POSITION
Note. The figures given here are the distances between wiper blades and cowl panel grille of plenum chamber at bottom edge of windshield.
- Tighten nut for wiper arms to 21 Nm.
- Actuate flick wipe switch.
- If necessary, realign wiper arms and retighten nuts.
- Lift wiper arm off of front windshield.
- Press onto disengaging button at linkage -arrow-.
- Remove wiper blade -2 downward from wiper arm -1-.
- When inserting wiper blade -2- on drivers side, make sure wiper blade engages in the tab and retaining bracket at spoiler engages in wiper blade.
- Lock wiper blade by pressing onto disengaging button.
Front windshield washer system, servicing
| CAUTION | Before beginning repairs on the electrical system: Obtain the anti-theft radio security code. Switch the ignition off. Disconnect the battery Ground (GND) strap. On vehicles equipped with Audi Telematics by OnStar®, switch-off the emergency (back-up) battery for the Telematic/Telephone Control Module prior to disconnecting vehicle battery. See EMERGENCY BATTERY, SWITCHING OFF/ON . After reconnecting vehicle battery, re-code and check operation of anti-theft radio. Also check operation of clock and power windows according to Repair Manual and/or Owner's Manual. After reconnecting vehicle battery on vehicles equipped with Audi Telematics by OnStar®, switch-on the emergency (back-up) battery for the Telematic/Telephone Control Module. See EMERGENCY BATTERY, SWITCHING OFF/ON . |
- Disconnect battery Ground strap with ignition switched off.
Note. Steps after re-connecting voltage supply. See BATTERY DISCONNECT PRECAUTIONS .
Scheme 35
- If installed, remove cover -1- at left in engine compartment.
- Unscrew upper section of washer fluid reservoir -arrows-.
- Pull upper section of washer fluid reservoir out from bottom section of washer fluid reservoir.
Removing bottom section of washer fluid reservoir
- Remove front left wheel.
- Remove front left wheel housing liner
See FRONT WHEEL HOUSING LINER, ASSEMBLY OVERVIEW (except Cabriolet). For Cabriolet, see WHEEL HOUSING LINER .
Scheme 36
- Unscrew bottom section of washer fluid reservoir -arrow-.
- Swivel bottom section of washer fluid reservoir slightly rearward.
- Unplug connectors -2 to 4-. see scheme 15
- Pull off hose connector -1- (press release tabs).
- Pull off washer fluid line -5-.
- Remove washer fluid reservoir downward.
Install in reverse order, paying attention to the following
- Tighten bolts in sequence -1 to 3-.
Scheme 37
Note. Water hose must audibly engage in connection of washer fluid pump.
Tightening torques
| Component | Nm |
|---|---|
| Upper section of washer fluid reservoir to body-M6 | 9 |
| Upper section of washer fluid reservoir to body-Nut | 1.2 |
| Bottom section of washer fluid reservoir to body | 7 |
TORQUE SPECIFICATIONS: WASHER FLUID RESERVOIR
- Unclip base of spray jet from bottom of hood -arrow-.
- Pull water hose off unclipped spray jet.
- If installed, disconnect electrical harness connector.
Install in reverse order, paying attention to the following
Note. Water hose must audibly engage in connection of spray jet.
- Adjusting tool for washer jet 3125 A with needle 3125 / 5A
Procedure
Note. The adjustment dimensions indicate the values for a moving vehicle, i.e. the spray from the jets is slightly offset when the vehicle is stationary.
- Mark four points on windshield with water-soluble ink: Dimension a = 250 to 275 mm Dimension b = 465 to 490 mm Dimension c = 270 to 415 mm Dimension d = 140 to 225 mm
- Use adjusting tool to aim individual spray jets at points marked.
Rear windshield wiper and washer system, servicing (Avant)
| CAUTION | Before beginning repairs on the electrical system: Obtain the anti-theft radio security code. Switch the ignition off. Disconnect the battery Ground (GND) strap. On vehicles equipped with Audi Telematics by OnStar®, switch-off the emergency (back-up) battery for the Telematic/Telephone Control Module prior to disconnecting vehicle battery. See EMERGENCY BATTERY, SWITCHING OFF/ON . After reconnecting vehicle battery, re-code and check operation of anti-theft radio. Also check operation of clock and power windows according to Repair Manual and/or Owner's Manual. After reconnecting vehicle battery on vehicles equipped with Audi Telematics by OnStar®, switch-on the emergency (back-up) battery for the Telematic/Telephone Control Module. See EMERGENCY BATTERY, SWITCHING OFF/ON . |
- Disconnect battery Ground strap with ignition switched off.
Note. Steps after re-connecting voltage supply. See BATTERY DISCONNECT PRECAUTIONS .
Rear windshield wiper, removing and installing
Note. Make sure that wiper motor is in park position before removing wiper arm.
The following list pertains to see scheme 20.
- Connection line For spray jet
- Securing nut - 12 Nm
- Spray jet
- Rear wiper cap
- Wiper arm
- Wiper blade
- Carefully pry off cap -4- using a small screwdriver. see scheme 20
- Carefully pull off spray jet -3- from connection line.
- Remove securing nut -2-.
- Remove wiper arm -5- from shaft drive.
Installation is the reverse order of removal while observing the following
- Switch rear windshield wiper on and off and let it run to park position.
- Set wiper arm -5- with wiper blade -6- onto shaft drive.
- Adjusting wiper blade at rear windshield, see «WINDSHIELD WIPER BLADE PARK POSITION, ADJUSTING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#windshield-wiper-washer-system-except-cabriolet__windshield-wiper-blade-park-position-adjusting).
- Secure wiper arm with nut -4- (12 Nm).
- Operate rear windshield wiper.
- If necessary, adjust wiper arm once again and tighten securing nut. see scheme 20
Rear windshield wiper motor, removing and installing
The following list pertains to see scheme 21.
- Securing nut - 8 Nm
- Wiper motor
- Rubber seal
- Water hose
- Remove rear windshield wiper. See «REAR WINDSHIELD WIPER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#windshield-wiper-washer-system-except-cabriolet__rear-windshield-wiper-removing-and-installing) .
- Remove bottom trim of rear lid.
- Disconnect electrical harness connector.
- Carefully pull off water hose -4- from connection line.
- Remove securing nuts -1-.
- Remove wiper motor -2-. see scheme 21
Installation is the reverse order of removal, while observing the following
Note. Carefully insert rubber seal -3- into hole in rear window.
- Tighten securing nuts -1- (8 Nm).
- Water hose must audibly engage into spray jet connection. see scheme 21
- Carefully pry cap -3- off from wiper arm -1- -arrow-.
- Carefully pull spray jet -2- off from connection line.
Installation is the reverse order of removal, while observing the following
- Insert spray jet so that the spray opening points to the cutout at wiper arm.
- 3125A windshield washer aiming tool with 3125 / 5A needle
Work sequence
- Using 3125A special tool, adjust spray jet so that the water jet sprays onto the rear windshield above the wiper at the indicated locations. Dimension a = approx. 125 mm Dimension b = approx. 295 mm Dimension c = approx. 5 mm
Windshield wiper blade park position, adjusting
- Let wiper motor run into park position.
- Insert wiper blade at rear windshield and adjust as follows: Dimension a = 15 to 20 mm
Note. The dimension indicates the distance of the point of the wiper blade to lower edge of windshield.
- Tighten securing nut for wiper arm to 12 Nm.
- Operate wiper.
- If necessary, adjust wiper arm once again and tighten securing nut.
Windshield wiper blade, replacing
- Lift wiper arm off from rear windshield.
- Unclip wiper blade from wiper arm. See «REAR WINDSHIELD WIPER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#windshield-wiper-washer-system-except-cabriolet__rear-windshield-wiper-removing-and-installing) , -Item 6 -.
Installation is the reverse order of removal.
Windshield washer fluid reservoir, removing and installing
Note. The combined windshield washer fluid reservoir for front and rear windshield washer system is located in engine compartment at front left. See WASHER FLUID RESERVOIR, REMOVING AND INSTALLING .
Headlight washer system, servicing
| CAUTION | Before beginning repairs on the electrical system: Obtain the anti-theft radio security code. Switch the ignition off. Disconnect the battery Ground (GND) strap. On vehicles equipped with Audi Telematics by OnStar®, switch-off the emergency (back-up) battery for the Telematic/Telephone Control Module prior to disconnecting vehicle battery. See EMERGENCY BATTERY, SWITCHING OFF/ON . After reconnecting vehicle battery, re-code and check operation of anti-theft radio. Also check operation of clock and power windows according to Repair Manual and/or Owner's Manual. After reconnecting vehicle battery on vehicles equipped with Audi Telematics by OnStar®, switch-on the emergency (back-up) battery for the Telematic/Telephone Control Module. See EMERGENCY BATTERY, SWITCHING OFF/ON . |
- Disconnect battery Ground strap with ignition switched off.
Note. Steps after re-connecting voltage supply. See BATTERY DISCONNECT PRECAUTIONS .
Headlight washer system spray jet inserts, removing and installing
- Pull up spray jet cover on bumper and carefully disengage mounts -arrow-.
- Unclip retaining clip and pull spray jet insert upward and out -arrows-.
- Remove front bumper
See FRONT BUMPER, ASSEMBLY OVERVIEW (except Cabriolet). For Cabriolet, see FRONT BUMPER .
- Pull up spray jet cover on bumper and carefully disengage mounts -arrow-.
- Pull off water hose -3- (press release tab).
- Unscrew bolts -1- and -2- and remove spray jet.
Install in reverse order, paying attention to the following
- Install front bumper
See FRONT BUMPER, ASSEMBLY OVERVIEW (except Cabriolet). For Cabriolet, see FRONT BUMPER .
| Component | Nm |
|---|---|
| Spray jet to bumper | 3 |
TORQUE SPECIFICATIONS: HEADLIGHT WASHER
Spray jets, adjusting
Note. The spray jets are supplied with correct settings and do not need to be adjusted after installation.
Washer fluid reservoir, removing and installing
Note. The washer fluid reservoir supplies both the windshield and the headlight washer systems, and is located at the front left of the engine compartment. Removing and installing. See WASHER FLUID RESERVOIR, REMOVING AND INSTALLING .
