Contents Wiring diagrams Section: Gauges & Instrument Panels All sections

Interior Trim - Cabriolet Audi A4 B6

Gauges & Instrument Panels 19 illustrations ~5785 words

Component locations, assembly overview

The following list pertains to (Scheme 13).

  1. Removing and installing door trim, see «DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__door-trim-assembly-overview)
  2. Removing and installing trim, see «TRIM, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet)
  3. Removing and installing armrest, see «ARMREST, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet)
  4. Removing and installing switch panel for window regulator, see «SWITCH PANEL FOR WINDOW REGULATOR, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet)
  5. Removing and installing interior door handle, see «INTERIOR DOOR HANDLE, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet)
  6. Removing and installing central locking switch, see «CENTRAL LOCKING SWITCH, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet)
  7. Removing and installing mirror adjustment switch, see «MIRROR ADJUSTMENT SWITCH, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__mirror-adjustment-switch-removing-and-installing)
  8. Removing and installing bass loudspeaker trim, see «TRIM OF BASS LOUDSPEAKER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
  9. Removing and installing switch panel for memory seat, see «SWITCH PANEL FOR MEMORY SEAT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet)
  10. Removing and installing courtesy light, see «DOOR WARNING LIGHT AND COURTESY LIGHT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet)
  11. Removing and installing switch panel for tailgate release and/or anti-theft alarm, see «SWITCH PANEL FOR TAILGATE RELEASE AND/OR DEACTIVATION OF ANTI-THEFT ALARM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__switch-panel-for-tailgate-release-andor) .
  12. Removing and installing door warning light, see «DOOR WARNING LIGHT AND COURTESY LIGHT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet)

Door trim, assembly overview

The following list pertains to (Scheme 14).

  1. Door trim Removing Remove triangular trim of treble loudspeaker, see «TREBLE LOUDSPEAKER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Remove trim -6-. See «TRIM, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Unscrew bolts -5- (2x). Using a screwdriver, pry out switch panel of window regulator -3- from below through the hole. Unscrew bolt -4-. Unscrew bolt -7-. Unclip door trim -1-, starting at bottom. Detach door trim -1- upward. Disconnect connector to window regulator control unit. See «UNPLUGGING CONNECTOR AT WINDOW REGULATOR CONTROL UNIT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Disengage Bowden cable for interior door handle. See «UNPLUGGING CONNECTOR AT WINDOW REGULATOR CONTROL UNIT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Installing Ensure that expanding nut -10- is clipped into door shell -9-. Ensure that all clips -8- (8x) are clipped in on inside of door trim. Replace damaged clips -8-. See «REPLACING DOOR TRIM SECURING CLIP»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Ensure that all clips -2- (6x) are clipped in on outside of door trim -1-. Install door trim -1- in reverse order to removal.
  2. Clips (6x)
  3. Switch panel for window regulator
  4. Bolt
  5. Bolts (2x)
  6. Trim strip
  7. Bolt
  8. Clips (8x)
  9. Door shell
  10. Expanding nut

Disengaging Bowden cable for interior door handle

  1. Detach Bowden cable -2- from guide -1-.
  2. Detach hook -3-. NOTE: When installing, ensure hook -3- is facing upward.

Scheme 13

Scheme 13: Unplugging connector at window regulator control unit
Scheme 13: Unplugging connector at window regulator control unit
  1. Detach catch -2-.
  2. Disconnect connector -3- from control unit -1- in direction of arrow.

Scheme 14

Scheme 14: Replacing door trim securing clip
Scheme 14: Replacing door trim securing clip
  1. Press retainer tab -2- and pull out clip -1- in direction of arrow.

Removing

  1. Carefully pry out trim -1- at front end in direction of arrow.
  2. Unclip trim -1-.

Installing

  1. Installation is in reverse order of removal.

Insulation, assembly overview

The following list pertains to (Scheme 21).

  1. Door shell
  2. Insulation Removing When removing insulation -2-, ensure that insulation -2- is not damaged. Installing Ensure that adhesive bead -3- is not dirty or damaged. Ensure that insulation -2- is not damaged. Press adhesive bead -3- tightly all around door shell -1-.
  3. Adhesive bead

Routing of wiring in door trim, assembly overview

The following list pertains to (Scheme 22).

  1. Cable to mirror adjustment switch
  2. Cable to central locking switch
  3. Cable to switch panel for window regulator
  4. Cable to display of anti-theft alarm
  5. Cable to door warning light
  6. Cable to deactivation switch of anti-theft alarm
  7. Cable to courtesy light
  8. Cable to switch for tailgate release
  9. Cable to connector of window regulator control unit
  10. Cable to switch panel of memory seat
  1. Remove door trim. See «DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__door-trim-assembly-overview) .
  2. Unscrew bolts -2- (2x).
  3. Detach connector -3-.
  4. Unscrew bolts -4- (8x).
  5. Unclip armrest at the retainer tab -1-.

Note. Figure shows armrest without cover.

Scheme 15

Scheme 15
Scheme 15
  1. Remove armrest -1-.
  2. Remove cover on underside of armrest -1-.
  3. Detach connector -2-.
  1. Installation is in reverse order of removal.
  1. Remove door trim. See «DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__door-trim-assembly-overview) .
  2. Detach connector -1-.
  3. Using a screwdriver, pry out central locking switch -2-.
  1. Installation is in reverse order of removal.

Mirror adjustment switch, removing and installing

Note. Figure shows armrest without cover.

  1. Remove door trim. See «DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__door-trim-assembly-overview) .
  2. Remove armrest. See «ARMREST, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
  3. Using a screwdriver, pry out mirror adjustment switch -1-.
  4. Detach connector on mirror adjustment switch -2-.
  1. Installation is in reverse order of removal.
  1. Remove door trim. See «DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__door-trim-assembly-overview) .
  2. Remove central locking switch. See «CENTRAL LOCKING SWITCH, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
  3. Unscrew bolt -1-.
  4. Press retaining lugs -2- (2x) and remove interior door handle -3- forward.
  1. Installation is in reverse order of removal.
  1. Using a screwdriver, pry out switch panel of window regulator -1- from below through the hole.
  2. Detach the connector.
  1. Installation is in reverse order of removal.
  1. Using a screwdriver, pry out switch panel for memory seat -1-.
  2. Detach the connector.
  1. Installation is in reverse order of removal.

Switch panel for tailgate release and/or deactivation of anti-theft alarm, assembly overview

The following list pertains to (Scheme 30).

  1. Switch panel for tailgate release and deactivation of anti-theft alarm
  2. Switch panel for tailgate release or deactivation of anti-theft alarm
  3. Dummy cover Removing Using a screwdriver, carefully pry out switch panel. Disconnect connector(s) from switch panel. Installing Install switch panel in reverse order to removal.
  1. Remove door trim. See «DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__door-trim-assembly-overview) .
  2. Using a screwdriver, pry door warning light -1- out from below and pull door warning light -1- out with cable.
  3. Detach connector on door warning light -1-.
  4. Using a screwdriver, pry out courtesy light -2- at front and pull courtesy light -2- out with cable.
  5. Detach connector on courtesy light -2-.
  1. Installation is in reverse order of removal.
  1. Unclip grille -2-.
  2. Unscrew bolt -3-.
  3. Detach triangular trim of treble loudspeaker -1- upward.
  4. Disconnect connector from triangular trim of treble loudspeaker -1-.
  1. Unclip grille -2- from triangular trim of treble loudspeaker -1
  2. Install triangular trim for treble loudspeaker -1- in reverse order to removal.
  1. Remove door trim. See «DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__door-trim-assembly-overview) .
  2. Using a screwdriver, pry out circlips -1- (14x).
  3. On deactivation of anti-theft alarm: Disconnect connector -2-.
  4. On tailgate release: Detach connector -3-.
  5. Detach connector of memory seat -4-.
  6. Remove trim of bass loudspeaker.
  1. Installation is in reverse order of removal.

Rear side trim, assembly overview

  1. Side trim Removing: Remove rear bench seat. See «REAR SEAT BENCH, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__rear-seat-bench-assembly-overview) . Remove rear seat backrest. See «REAR SEAT BACKREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__rear-seat-backrest-assembly-overview) . Remove decorative panel. See «DECORATIVE PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Unscrew bolt -3-. Unclip clips -2- (2x). Grab into side trim -1- and unclip the side trim -1- at clips -2-, -7- and -6-. Unclip clip -4-. Remove side trim -1-. If side trim -1- is to be replaced: Remove anchorage point for outer floor panel. Remove decorative panel. See «DECORATIVE PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Installing: NOTE: After installation ensure that seal is pulled correctly over side trim. Pull back clip -6- to release tension on clip -6-. Install side trim -1- in reverse order to removal.
  2. Clip
  3. Decorative panel
  4. Center piece
  5. Bolt
  6. Clip
  7. Clip
  1. Carefully pry off decorative panel -1- at rear end in direction of arrow.
  2. Unclip decorative panel -1-.
  1. Installation is in reverse order of removal.

The following list pertains to see scheme 24.

  1. Insulation with loudspeaker installed
  2. Insulation with loudspeaker not installed
  3. Insulation
  4. Belt reel insulation Removing: Remove rear bench seat. See «REAR SEAT BENCH, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__rear-seat-bench-assembly-overview) . Remove rear seat backrest. See «REAR SEAT BACKREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__rear-seat-backrest-assembly-overview) . Remove decorative panel. See «DECORATIVE PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . For belt reel insulation: Remove belt reel of front seat belt. For all insulation: When removing insulation, ensure that insulation does not become damaged. Remove insulation. Installing: Press insulation evenly and firmly onto body. For belt reel insulation: Install belt reel.

The following list pertains to see scheme 25.

  1. Instrument panel Removing, see «INSTRUMENT PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet)
  2. Left instrument panel vent Removing, see «REMOVING INSTRUMENT PANEL VENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__removing-instrument-panel-vent)
  3. Left instrument panel loudspeaker Removing, see «REMOVING LEFT AND RIGHT INSTRUMENT PANEL LOUDSPEAKER»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__removing-left-and-right-instrument-panel)
  4. Instrument cluster Removing: See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#instrument-systems-cabriolet) .
  5. Upper steering column switch trim Removing, see «REMOVING UPPER STEERING COLUMN SWITCH TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__removing-upper-steering-column-switch-trim)
  6. Sunlight penetration photosensor -G107- Removing, see «REMOVING SUNLIGHT PENETRATION PHOTOSENSOR -G107»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__removing-sunlight-penetration-photosensor-g107)
  7. Center instrument panel loudspeaker Removing, see «REMOVING CENTER INSTRUMENT PANEL LOUDSPEAKER»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__removing-center-instrument-panel-loudspeaker)
  8. Trim for center defroster vent Removing, see «REMOVING TRIM FOR CENTER DEFROSTER VENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__removing-trim-for-center-defroster-vent)
  9. Center instrument panel vent Removing, see «REMOVING INSTRUMENT PANEL VENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__removing-instrument-panel-vent)
  10. Front passenger airbag unit Removing, see appropriate Air Bag Restraint Systems article
  11. Right instrument panel loudspeaker Removing, see «REMOVING LEFT AND RIGHT INSTRUMENT PANEL LOUDSPEAKER»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__removing-left-and-right-instrument-panel)
  12. Right instrument panel vent Removing, see «REMOVING INSTRUMENT PANEL VENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__removing-instrument-panel-vent)
  13. Instrument panel cover, right Removing, see «REMOVING RIGHT INSTRUMENT PANEL COVER»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__removing-right-instrument-panel-cover)
  14. Right instrument panel trim Removing, see «REMOVING CENTER INSTRUMENT PANEL LOUDSPEAKER»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__removing-center-instrument-panel-loudspeaker)
  15. Glove compartment See «GLOVE COMPARTMENT, ASSEMBLY OVERVIEW»(ref-197209-S32533520222005101300000) .
  16. Center console Removing, see «CENTER CONSOLE, ASSEMBLY OVERVIEW»(ref-197209-S20028257652005101300000)
  17. Front ashtray Removing, see «FRONT ASHTRAY, ASSEMBLY OVERVIEW»(ref-197209-S27703479772005101300000)
  18. Removing center section of instrument panel Removing, see «CENTER SECTION OF DASH PANEL, ASSEMBLY OVERVIEW»(ref-197209-S19508341112005101300000)
  19. Driver's storage compartment Removing, see «DRIVER'S STORAGE COMPARTMENT (VEHICLES WITH AND WITHOUT KNEE BOLSTER), ASSEMBLY OVERVIEW»(ref-197209-S29048734852005101300000)
  20. Left instrument panel trim Removing, see «REMOVE LEFT INSTRUMENT PANEL COVER»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__remove-left-instrument-panel-cover)
  21. Light switch and adjuster for headlight range control. Removing, see «REMOVING LIGHT SWITCH AND ADJUSTER FOR HEADLIGHT RANGE CONTROL»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__removing-light-switch-and-adjuster-for)
  22. Instrument panel cover, left Removing, see «REMOVE LEFT INSTRUMENT PANEL COVER»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__remove-left-instrument-panel-cover)

Special tools and equipment

  1. Hook 3370 for front end
  2. Hook 3438
CAUTIONWhen disconnecting the battery observe the necessary measures. See BATTERY DISCONNECT PRECAUTIONS

Note. For air bag related information, see appropriate article in Restraints .

  1. Disconnect battery ground (GND) strap at battery.
  2. Removing driver's airbag unit (standard steering wheel).
  3. Removing driver's airbag unit (sports steering wheel). NOTE: For air bag related information, see appropriate article in Restraints .
  4. Removing driver's airbag unit (multi-function steering wheel).
  5. Removing steering wheel (standard steering wheel).
  6. Removing steering wheel (sports steering wheel).
  7. Removing steering wheel (multi-function steering wheel).
  8. Removing driver's storage compartment. See «DRIVER'S STORAGE COMPARTMENT (VEHICLES WITH AND WITHOUT KNEE BOLSTER), ASSEMBLY OVERVIEW»(ref-197209-S29048734852005101300000) .
  9. Removing instrument cluster. See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#instrument-systems-cabriolet) .
  10. Remove glove compartment. See «GLOVE COMPARTMENT, ASSEMBLY OVERVIEW»(ref-197209-S32533520222005101300000) .
  11. Removing passenger's airbag unit.
  12. Removing center console. See «CENTER CONSOLE, ASSEMBLY OVERVIEW»(ref-197209-S20028257652005101300000) .
  13. Removing center section of instrument panel. See «CENTER SECTION OF DASH PANEL, ASSEMBLY OVERVIEW»(ref-197209-S19508341112005101300000) .

Remove left instrument panel cover

  1. Remove left instrument panel end trim -arrow- with special tool 3370.

Removing left instrument panel end mounting

  1. Unscrew bolts -1- (2x). Tightening torque 4 Nm.

Detaching connectors on vent temperature sensor -G150- and -G151

  1. Detach connector on left and right -arrow- on vent temperature sensors -G150- and -G151-.

Note. The illustration shows vent temperature sensor -G151- on passenger side

Scheme 16

Scheme 16
Scheme 16

Removing instrument panel vent

  1. Detach connector for instrument panel vent light.

Note. The illustration shows instrument panel vent on passenger side. The center instrument panel vents must be pulled out to detach connector for light.

  1. Move rear air flaps of instrument panel vent into central position by turning adjustment wheel -1-.
  2. Guide tool 3438 in position -2- or -3- into instrument panel vent.
  3. Hook tool 3438 by slightly moving it into recesses -4- at rear end of instrument panel vent.
  4. Detach instrument panel vent carefully to rear alternating between left and right using special tool 3438.

Removing left and right instrument panel loudspeaker

  1. Carefully pry out loudspeaker trim -1-.
  2. Remove bolts -2-.
  3. Remove loudspeaker, disconnect connectors.

Removing and installing tray, switch and cup holder

  1. Remove tray. See «REMOVING AND INSTALLING STORAGE TRAY»(ref-197209-S23977040002005101300000) .
  2. Remove cup holder. See «REMOVING AND INSTALLING CUP HOLDER»(ref-197209-S40474503262005101300000) .
  3. Position a small flat-bladed screwdriver on top at the switch.
  4. Carefully pry appropriate switch out of switch mount -arrows-.
  5. Detach connectors.

Removing light switch and adjuster for headlight range control

  1. Press light switch -arrow 1- and turn clockwise at same time -arrow 2-.
  2. Keep switch in this position ...
  3. ...and pull light switch out of switch housing -arrow 3-.
  4. Detach connector.
  5. Press headlight range control adjuster out of switch housing.
  6. Disconnect the connector.

Removing left instrument panel trim

  1. Unscrew bolts -1- (3x). Tightening torque 3 Nm.
  2. Detach trim -2- for instrument panel.

Removing instrument panel mountings driver's side.

  1. Unscrew bolts -1- (2x). Tightening torque 4 Nm.

Removing upper steering column switch trim

Driver airbag unit and steering wheel removed.

  1. Pull steering column out and tilt downward as far as possible.
  2. Remove screws -1- (2x). Tightening torque 3 Nm.
  3. Unscrew bolts -3-. Tightening torque 0.6 Nm.
  4. Unclip surround from instrument panel downward -arrow-.
  5. Remove upper steering column switch trim -2-.

Removing sunlight penetration photosensor -G107

  1. Carefully pry off cover -A-.
  2. Unscrew bolt -B-.
  3. Remove photosensor.
  4. Disconnect cable connector.

Removing trim for center defroster vent

  1. Unscrew bolt -1- of defroster vent. Tightening torque 0.8 Nm.

Removing center instrument panel loudspeaker

Center defroster vent removed.

  1. Unscrew bolts -1- (2x). Tightening torque 2 Nm.
  2. Swivel out the loudspeaker and disconnect the connector.

Removing trim for right instrument panel cover.

  1. Unscrew bolt -1- and detach trim -2- to rear. Tightening torque 3 Nm.

Note. When installing trim for instrument panel cover, replace fasteners -3-.

Scheme 17

Scheme 17
Scheme 17

Removing right instrument panel cover

  1. Remove right instrument panel end trim -arrow- with special tool 3370.

Removing right instrument panel end mountings.

  1. Unscrew bolts -1- (2x). Tightening torque 4 Nm.

Removing center instrument panel mountings

  1. Unscrew bolts -1- (4x). Tightening torque 4 Nm.
  2. Pull out instrument panel toward the rear.

Scheme 18

Scheme 18: Installing
Scheme 18: Installing
  1. Check that felt -2- is present on left and right of clip -1-.
  2. Insert instrument panel into clip pressing it down slightly at the same time.
  3. Test that the instrument panel is located correctly in the clip at the front by pulling up lightly.
  4. Carry out remainder of installation in reverse order of removal.
  1. Blind rivet pliers VAS 5072

Scheme 19

Scheme 19: Removing
Scheme 19: Removing
  1. Remove instrument panel. See «INSTRUMENT PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
  2. Remove damaged vent temperature sensor -G150- or -G151-.
  3. Using a sharp knife, cut off weld points -2- (4x) flush with air duct.
  4. Remove damaged air duct.
  5. Drill 5 mm holes at -2- (3x).
  1. Install new air duct, ensuring that no parts remain inside it.
  2. Install blind rivets supplied with air duct at -2- (3x).
  3. Screw in bolt -3- supplied with air duct.

Components locations, assembly overview

The following list pertains to see scheme 52.

  1. Angle bracket, left For central tube
  2. Bolts (3x) Tightening torque 23 Nm.
  3. Bolt Tightening torque 9 Nm.
  4. Sealing washer
  5. Bolt Tightening torque 6 Nm.
  6. Central tube
  7. Bolts (2x) Tightening torque 9 Nm.
  8. Bolts (3x) Tightening torque 23 Nm.
  9. Angle bracket, right For central tube
  10. Angle bracket For support, Item 16
  11. Bolt Tightening torque 9 Nm.
  12. Nut Tightening torque 35 Nm
  13. Bolts (2x) Tightening torque 8 Nm.
  14. Angle bracket For air conditioner unit
  15. Bolts (2x) Tightening torque 9 Nm.
  16. Brace
  17. Bolts (2x) Tightening torque 9 Nm.
  18. Bolts (2x) Tightening torque 9 Nm.
  19. Support
  20. Bolts (4x) Tightening torque 5 Nm.
  21. Adapter center section
  22. Support
  23. Bolts (2x) Tightening torque 9 Nm.
  24. Bolt Tightening torque 8 Nm.
  25. Bolts (2x) Tightening torque 9 Nm.
  26. Bolt Tightening torque 8 Nm.
  27. Nut Tightening torque 35 Nm
  1. Pry bar 80-200

Scheme 20

Scheme 20: Removing
Scheme 20: Removing

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23
  1. Remove instrument panel. See «INSTRUMENT PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
  2. Remove instrument panel center section. See «CENTER SECTION OF DASH PANEL, ASSEMBLY OVERVIEW»(ref-197209-S19508341112005101300000) .
  3. Unscrew bolts -1- (2x) of fuse carrier -2-. Tightening torque 3 Nm.
  4. Lay the fuse carrier with attached wiring downward.
  5. Disengage wiring harness on instrument panel subframe and set aside.
  6. Unscrew bolts -1- (2x) of 3 compartment relay carrier -2-. Tightening torque 3 Nm.
  7. Unscrew nuts -3- (2x) of 6 compartment relay carrier -4- on vehicle's electrical system control unit. Tightening torque 2.4 Nm.
  8. Lay the relay carrier with attached wiring downward.
  9. Detach the wiring harness behind the relay carriers from the central tube and set aside.
  10. Unscrew bolt -2- of pedal bracket. Tightening torque 23 Nm.
  11. Unscrew bolts -1- (4x). Tightening torque 22 Nm.
  12. Lay steering column down in driver's footwell.
  13. Unscrew bolts -1- (4x) of left support. Tightening torque 9 Nm.
  14. Unscrew bolt -2-. Tightening torque 8 Nm.

Note. If support does not have to be removed, simply loosen bolt -3- and swing support downward.

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Loosen or remove bolt -3- (front attachment of support to air conditioner unit). see scheme 58 Tightening torque 8 Nm.
  2. Detach support or swing downward.
  3. Unscrew bolts -1- (4x). Tightening torque 9 Nm.
  4. Lay wiring -2- aside.
  5. Detach right support.
  6. Unscrew bolts -1- (2x) of air conditioner unit bracket. Tightening torque 9 Nm.
  7. Pry off both trim caps -3- with a screwdriver.
  8. Loosen the hex nuts -4- a few turns.
  9. Release the wiper arms -2- from the pivot shaft by tilting them slightly.
  10. Remove hex nuts completely and remove wiper arms.
  11. Detach the retaining clips -1- and remove the air cowl grille -5-.
  12. Remove cover for electronics box (plenum chamber) -arrows-.
  13. Using a screwdriver, carefully lever off retainer -arrow- and place engine control module with connected wiring on one side.
  14. Unclip retaining clip.
  15. If present, place transmission control module with connected wiring on one side.
  16. Unscrew bolts -2- (2x) of connector point. Tightening torque 3 Nm.
  17. In plenum chamber, unscrew bolt -1- of instrument panel central tube. Tightening torque 6 Nm.
  18. Unscrew nuts -1- (2x) on left. see scheme 64 Tightening torque 35 Nm.
  19. Unscrew bolt -3- at top. Tightening torque 6 Nm.
  20. Unscrew ground (GND) wires -2-.
  21. Unscrew nut -2- on right. Tightening torque 35 Nm.
  22. Unscrew bolt -3- at top. Tightening torque 6 Nm.
  23. Unscrew ground (GND) wires -1-.
  24. Pull instrument panel central tube a few mm forward.
  25. Pull out the pins -2 (2x) as far as possible, using a small screwdriver.
  26. Set electrical wiring harness aside behind vent.
  27. Detach air duct upward -arrow-.
  28. Unscrew ground (GND) wires -1-.
  29. Detach wiring harness behind instrument panel central tube from instrument panel central tube -arrows-. Use pry bar 80-200.
  30. Remove instrument panel central tube.
  1. Installation is in reverse order of removal.

Upper A-pillar trim, assembly overview

The following list pertains to see scheme 69.

  1. Upper A-pillar trim Removing: Remove windshield trim. See «WINDSHIELD TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__windshield-trim-assembly-overview) . Unclip lower A-pillar trim in upper area. Pry out upper A-pillar trim -1- at clips -2- (3x). Detach upper A-pillar trim -1-. Removing: When installing, ensure that rubber door surround is in full contact with upper A-pillar trim -1-. Install upper A-pillar trim -1- in reverse order to removal.
  2. Clip (3x)

Lower A-pillar trim, assembly overview

The following list pertains to see scheme 70.

  1. Sill panel trim
  2. Clip (3x)
  3. Clip
  4. Lower A-pillar trim. Removing: Unclip sill panel trim -1- at clips -2- (3x). Lift front sill panel trim -1-. Unclip lower A-pillar trim -4- at clip -5-. Press retainer tab on clip -3- and remove lower A-pillar trim -4-. Installing: When installing, ensure that rubber door surround is in full contact with lower A-pillar trim -1-. Install lower A-pillar trim -1- in reverse order to removal. Clip

Floor covering, assembly overview

The following list pertains to see scheme 71.

  1. Floor mat Removing: Remove front seats. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Remove rear seat backrest. See «REAR SEAT BACKREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__rear-seat-backrest-assembly-overview) . Remove rear bench seat. See «REAR SEAT BENCH, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__rear-seat-bench-assembly-overview) . Remove sill panel trims. See «SILL PANEL TRIM, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Remove lower A-pillar trims. See «LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__lower-a-pillar-trim-assembly-overview) . Remove foot rest. See «FOOT REST, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Remove foot rest holder. See «FOOT REST HOLDER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Remove center console. See «CENTER CONSOLE, ASSEMBLY OVERVIEW»(ref-197209-S20028257652005101300000) . Detach wiring harness under center console. Remove bolts (2x) from air ducts -2- (2x) and remove both air ducts -2- (2x). Unscrew bolts -3- (2x). Fold floor covering -1- together lengthways and remove floor covering -1- from vehicle. Installing: NOTE: Floor covering is liable to tear slightly at cut-outs. Install floor covering carefully. Install floor covering -1- in reverse order to removal.
  2. Air ducts (2x)
  3. Bolts (2x)
  1. Unclip side trim -1- in bottom area.
  2. Unclip sill panel trim -2- at clips -3- (3x).
  3. Remove sill panel trim -2-.
  1. After installation ensure that seal is pulled correctly over sill panel trim -2-.
  2. Install sill panel trim -2- in reverse order to removal.
  1. Removing driver's storage compartment. See «DRIVER'S STORAGE COMPARTMENT (VEHICLES WITH AND WITHOUT KNEE BOLSTER), ASSEMBLY OVERVIEW»(ref-197209-S29048734852005101300000) .
  2. Remove lower A-pillar trim. See «LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__lower-a-pillar-trim-assembly-overview) .
  3. Unscrew bolt -1-.
  4. Push foot rest -2- upward and remove foot rest -2-.
  1. Install foot rest -2- in reverse order to removal.
  1. Remove foot rest
  2. Fold back floor covering around foot rest holder -4-.
  3. Unscrew nuts -5- (3x). Tightening torque 4 Nm.
  4. Remove foot rest holder -4-.
  1. Ensure that snap-on nut -3- is installed to foot rest holder -4-.
  1. Detach sun visor -4- from mount -1- and fold sun visor -4- aside.
  2. Using a screwdriver, pry out trim cap -3-.
  3. Unscrew bolt -2-. Tightening torque 4 Nm.
  4. Remove sun visor -4-.
  1. Installation is in reverse order of removal.
  1. Using a screwdriver, pry out trim cap -3-.
  2. Unscrew bolts -2- (2x). Tightening torque 4 Nm.
  3. Detach mount -1-.
  1. Installation is in reverse order of removal.
  1. Unscrew bolt -2-.
  2. Detach center sun visor -1-.
  1. Installation is in reverse order of removal.

Windshield trim, assembly overview

The following list pertains to see scheme 78.

  1. Bolt Tightening torque 7 Nm.
  2. Clips (2x)
  3. Nut
  4. Lugs (2x)
  5. Windshield trim Removing: Remove interior light/reading light. See «INTERIOR LIGHT / READING LIGHT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Remove make-up mirror light. See «MAKE-UP MIRROR LIGHT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Remove sun visors. See «SUN VISOR, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Remove sun visor mounts. See «SUN VISOR MOUNT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Remove center sun visor. See «CENTER SUN VISOR, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Unscrew nut -3-. Pry out windshield trim -5- at clips -2- (2x) and lugs -4- (2x). Carefully remove windshield trim -5- downward. Installing: Install windshield trim -5- in reverse order to removal.
  1. Using a screwdriver, pry out make-up mirror light -2- in direction of arrow.
  2. Detach the connector -1-.
  3. Remove make-up mirror light -2-.
  1. Installation is in reverse order of removal.
  1. Pry bar 80-200
  1. Using pry bar 80-200, carefully pry out interior light at rear edge. Watch for the two retaining tabs -arrows-.
  2. Detach connectors.
  1. Installation is in reverse order of removal.

Tailgate trim, assembly overview

The following list pertains to see scheme 82.

  1. Tailgate trim Removing: Remove warning triangle. Remove bolts -3- (3x). Remove holder for warning triangle -6-. Detach lock cover -2-. Unscrew flocked screw -5- in handle -4-. For vehicles with emergency release handle: Remove emergency release handle. See «REMOVING EMERGENCY RELEASE HANDLE»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Unclip tailgate trim -1- at clips -7- (12x). Remove tailgate trim -1-. Installing: Install tailgate trim in reverse order of removal.
  2. Lock cover
  3. Bolts (3x)
  4. Handle
  5. Bolt
  6. Bracket for warning triangle.
  7. Clips (12 x)

Scheme 29

Scheme 29: Removing emergency release handle
Scheme 29: Removing emergency release handle
  1. Unclip cover -1-.
  2. Unscrew bolt -3-.
  3. Remove handle -2-.
  1. Using a screwdriver, pry out luggage compartment light -1- in direction of arrow.
  2. Disconnect connector -2-.
  1. Installation is in reverse order of removal.

Rear cross panel trim, assembly overview

The following list pertains to see scheme 86.

  1. Rear cross panel trim Removing: Remove luggage compartment floor covering from luggage compartment. Remove luggage compartment light. See «LUGGAGE COMPARTMENT LIGHT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Unclip rear cross panel trim -1- upward from clips -2- (4x). Installing: NOTE: After installation ensure that seal is pulled correctly over trim. Install rear cross panel trim in reverse order to removal.
  2. Clips (4x)

Right side trim, assembly overview

The following list pertains to see scheme 87.

  1. Right side trim Removing: Remove luggage compartment floor covering. Remove rear panel trim. See «REAR CROSS PANEL TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__rear-cross-panel-trim-assembly-overview) . Remove luggage compartment light. See «LUGGAGE COMPARTMENT LIGHT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Unclip clip -2-. Detach right side trim -1- in direction of arrow. Installing: NOTE: After installation ensure that seal is pulled correctly over trim. Install trim in reverse order to removal.
  2. Clip

Left side trim, assembly overview

The following list pertains to see scheme 88.

  1. Left side trim. Removing: Remove luggage compartment floor covering. Remove rear panel trim. See «REAR CROSS PANEL TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__rear-cross-panel-trim-assembly-overview) . Unclip clip -2-. Detach left side trim -1- in direction of arrow. Installing: NOTE: After installation ensure that seal is pulled correctly over trim. Install trim in reverse order to removal.
  2. Clip

Back panel trim, assembly overview

The following list pertains to see scheme 89.

  1. Back panel trim Removing Remove right side trim. See «RIGHT SIDE TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__right-side-trim-assembly-overview) . Remove left side trim. See «LEFT SIDE TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__left-side-trim-assembly-overview) . Remove luggage compartment floor covering. If installed, remove frame for ski bag. Ensure that convertible top is closed and convertible top compartment folded up. Unclip back panel trim -1- at clips -2- (6x). Clips (6x)

The following list pertains to see scheme 90.

  1. Clips (2x)
  2. Back panel trim Fold convertible top compartment down. Open the convertible top. Unclip back panel trim -2- at clips -1- (2x). Lift out back panel trim -2- upward.
  1. Removing: Install back panel trim -2- in reverse order to removal.
  1. Remove floor covering -2-.
  2. Unclip holder -1- from mounting -3-.
  1. Installation is in reverse order of removal.

Rear trim, removing and installing

The following list pertains to see scheme 92.

  1. Rear trim Removing: Open the convertible top. Fold convertible top compartment down. Unclip clips -2- (4x). Fold away seal and pull out rear trim -1-. Installing: After installation ensure that seal is installed correctly. Install rear trim -1- in reverse order to removal.
  2. Clips (4x)

Side trim, removing and installing

The following list pertains to see scheme 93.

  1. Side trim Removing: Open the convertible top. Fold convertible top compartment down. Unclip clips -3- (3x). Unscrew stop buffer -2-. Fold seal aside and pull out side trim -1-. Installing: NOTE: After installation ensure that seal is pulled correctly over trim. Install side trim -1- in reverse order to removal.
  2. Stop buffer
  3. Clip (3x)

Flap, removing and installing

The following list pertains to see scheme 94.

  1. Flap Removing: Unscrew bolts -3- (2x) on mountings -2- (2x). Push flap -1- forward and detach flap -1- downward. Installing: Install flap in reverse order to removal.
  2. Mounting (2x)
  3. Bolts (2x)

Variable convertible top compartment, removing and installing

The following list pertains to see scheme 95.

  1. Variable convertible top compartment Removing: Move convertible top into such a position that convertible top compartment is open. Lift up side lining in convertible top compartment. Unscrew bolts left and right -2- (2x). Close the convertible top. Open luggage compartment lid. Remove lid of convertible top compartment. See «CONVERTIBLE TOP COMPARTMENT LID, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__convertible-top-compartment-lid-assembly-overview) . Remove handle mount trim. See «HANDLE MOUNT TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__handle-mount-trim-assembly-overview) . Detach Bowden cables from clips. Using a large, flat screwdriver -6-, work along between convertible top compartment side section -4- and console -3- and carefully detach convertible top compartment from console -5- (secured with adhesive tape).l Detach connector to microswitch -7- on right side. Detach Bowden cables from clips. Close luggage compartment lid. Move convertible top back into position "convertible top compartment open". A second mechanic is required to lift out. Position handle mount trim on variable convertible top compartment. Remove luggage compartment side trim on left (see «LEFT SIDE TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__left-side-trim-assembly-overview) ) and right (see «RIGHT SIDE TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__right-side-trim-assembly-overview) ). NOTE: The variable convertible top compartment must be lifted at sides of frame section, do not hold convertible top compartment in center and extend mechanism. Lift out variable convertible top compartment -1- at both sides on side sections -4-. Ensure that Bowden cables do not get caught. Installing: Installation is in reverse order of removal.
  2. Bolts (2x) Tightening torque 2 Nm
  3. Convertible top compartment side lining
  4. Convertible top compartment side section
  5. Flat screwdriver
  6. Console
  7. Microswitch connector

Convertible top compartment lid, assembly overview

The following list pertains to see scheme 96.

  1. Convertible top compartment lid NOTE: The variable convertible top compartment must be in the lowest position. The hinges -2- must not be unscrewed to remove convertible top compartment lid -1-. Arrow faces in direction of travel. Removing: Bend convertible top compartment lid -1- back on one side on hinge and detach convertible top compartment lid -1- from hinges. Fold convertible top compartment lid -1- downward. Detach lid on hooks -4- (2x) by pushing forward.
  2. Hinge (2x) Bend convertible top compartment lid -1- back on one side on hinge and detach convertible top compartment lid -1- from hinges. Unscrew bolt -3-. Detach hinge -2- from body.
  3. Bolt (2x)
  4. Hook
  5. Variable convertible top compartment

Handle mount trim, assembly overview

The following list pertains to see scheme 97.

  1. Handle mount trim NOTE: Convertible top must be closed. Removing: Pry out cover -2- using a small flat screwdriver. Unscrew bolt -3-. Turn handle. Pry out cover -2- on other side, using a small flat screwdriver. Unscrew second bolt -3-. Unscrew bolts -4- from underneath. Unclip handle mount trim -1- from clips -5- (2x). Pry out clamp -6- (always replace clamp -6-). Detach Bowden cable -7- from handle.
  2. Cover (2x)
  3. Bolts (2x) Tightening torque 9 Nm
  4. Bolts (2x) Tightening torque 7 Nm
  5. Clips (2x)
  6. Clamp Always replace
  7. Bowden cable
  1. Remove handle mount trim. See «HANDLE MOUNT TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet__handle-mount-trim-assembly-overview) .

Note. Illustration shown from rear for greater clarity.

  1. Using a small flat screwdriver, pry out fuse -2- (always replace fuse -2-).
  2. Press in pin -3-.
  3. Remove handle -1-.
  1. Grip
  2. Fuse (always replace)
  3. Bolt
  4. Bowden cable
  1. Installation is in reverse order of removal.

Scheme 30

Scheme 30: Removing
Scheme 30: Removing
  1. Remove variable convertible top compartment. See «VARIABLE CONVERTIBLE TOP COMPARTMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
  2. Pull carpet -1- back (convertible top compartment lining) on right side until both bolts -2- are accessible. Bond carpet with D 001 200.
  3. Unscrew bolts -2- (2x). Tightening torque 4 Nm
  4. Detach convertible top compartment center section -3- from side section -4- on right.
  5. Pull side sections -1- and -2- apart.
  6. Remove bolts -3- (4x) from inner lid. Tightening torque 2 Nm
  7. Detach inner lid - 1-.
  8. Carefully drill out microswitch weld on outside.
  9. Remove microswitch -1-.
  1. Attach new microswitch -1- using soldering iron on outside.
  2. Installation is in reverse order of removal.

Scheme 31

Scheme 31: Removing
Scheme 31: Removing
  1. Remove variable convertible top compartment. See «VARIABLE CONVERTIBLE TOP COMPARTMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) .
  2. Pull carpet -1- back (convertible top compartment lining) on side to be changed until both bolts -2- are accessible. Bond carpet with D 001 200.
  3. Unscrew bolts -2- (2x). Tightening torque 4 Nm
  4. Detach convertible top compartment center section -3- from side section -4- on right.
  5. Pull side sections -1- and -2- apart.
  6. Remove bolts -3- (4x) from inner lid. Tightening torque 2 Nm
  7. Detach inner lid - 1-.
  8. Unscrew bolts -1- (4x) on both sides. Tightening torque 2 Nm.
  9. Pull sections -1- and -4- upward apart.
  10. Pry guide rails -3- out of catch of section -1-.
  11. Separate sections -1- and -4-.
  12. Release holder at rear -1-.
  13. Pry out holder -1- using a flat screwdriver.
  14. Always replace holder -1-.
  15. Remove toothed segment -2-.
  16. Detach Bowden cable -3-.

Toothed segment with Bowden cable for right side.

  1. Engage Bowden cable -2- in long groove and lay Bowden cable -2- in groove -3-.
  2. Groove -4- not used.

Toothed segment with Bowden cable for left side.

  1. Engage Bowden cable -2- in long groove and lay Bowden cable -2- in groove -4-.
  2. Engage Bowden cable for right side in short groove and lay Bowden cable -5- in groove -3-. (Bowden cables lie in opposite directions.)

All models, continued

  1. Press toothed segment -2- onto guide.
  2. Engage new holder -1-. see scheme 109
  3. Toothed segment -2- must be horizontal on installation.
  4. On assembly, section -4- must be positioned with guide rails -3- on rubber buffers at bottom. see scheme 110
  5. Ensure that microswitch on right side is not crushed. For this pull section -4- slightly upward. see scheme 110
  6. Press section -4- back down again.
  7. The toothed segment -5- must be horizontal when folding together. Fold sections in lowest position together.
  8. In folded position, push guide rail outer section -3- upward and engage it in lugs. see scheme 110
  9. Carry out remainder of installation in reverse order of removal.
  1. Remove variable convertible top compartment. See «VARIABLE CONVERTIBLE TOP COMPARTMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet).
  2. Pull carpet -1- back (convertible top compartment lining) on side to be changed until both bolts -2- are accessible. Bond carpet with D 001 200.
  3. Unscrew bolts -2- (2x). Tightening torque 4 Nm
  4. Detach convertible top compartment center section from side section -4- on right.
  5. Pull side sections -1- and -2- apart.
  6. Remove bolts -3- (4x) from inner lid. Tightening torque 2 Nm
  7. Detach inner lid - 1-.
  8. Unscrew bolts -1- (4x) on both sides. Tightening torque 2 Nm.
  9. Pull sections -1- and -4- upward apart. see scheme 114
  10. Pry guide rails -3- out of catch of section -1-.
  11. Separate sections -1- and -4-.
  12. Remove bolts -2- (3x). Tightening torque 2.5 Nm.
  13. Remove rack -1-.
  1. Installation is in reverse order of removal.
  1. Remove variable convertible top compartment. See «VARIABLE CONVERTIBLE TOP COMPARTMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet).
  2. Pull carpet -1- back (convertible top compartment lining) on side to be changed until both bolts -2- are accessible. Bond carpet with D 001 200.
  3. Unscrew bolts -2- (2x). Tightening torque 4 Nm
  4. Detach convertible top compartment center section -3- from side section -4- on right.
  5. Pull side sections -1- and -2- apart.
  6. Remove bolts -3- (4x) from inner lid. Tightening torque 2 Nm
  7. Detach inner lid -1-.
  8. Unscrew bolts -1- (4x) on both sides. Tightening torque 2 Nm.
  9. Pull sections -1- and -4- upward apart. see scheme 119
  10. Pry guide rail -3- out of catch of section -1-.
  11. Separate sections -1- and -4-.
  12. Unscrew bolts -2- on left and right. Tightening torque 1 Nm.
  13. Push guide rail -1- downward and out of locking tabs.
  14. Remove guide rail -1-.
  1. Installation is in reverse order of removal.

Console of variable convertible top compartment, assembly overview

The following list pertains to see scheme 121.

  1. Console Remove variable convertible top compartment. See «VARIABLE CONVERTIBLE TOP COMPARTMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-cabriolet) . Unscrew nuts -2- (4x). Lift console -1- upward out of body.
  2. Nuts (4x)

See also:
• REAR SEAT BENCH, ASSEMBLY OVERVIEW
• REAR SEAT BACKREST, ASSEMBLY OVERVIEW
• INSTRUMENT CLUSTER, REMOVING AND INSTALLING
• BATTERY DISCONNECT PRECAUTIONS
• FRONT SEAT, ASSEMBLY OVERVIEW
• DOOR TRIM, ASSEMBLY OVERVIEW
• TRIM, REMOVING AND INSTALLING
• MIRROR ADJUSTMENT SWITCH, REMOVING AND INSTALLING
• SWITCH PANEL FOR TAILGATE RELEASE AND/OR DEACTIVATION OF ANTI-THEFT ALARM, ASSEMBLY OVERVIEW
• REMOVING INSTRUMENT PANEL VENT
• REMOVING LEFT AND RIGHT INSTRUMENT PANEL LOUDSPEAKER
• REMOVING UPPER STEERING COLUMN SWITCH TRIM
• REMOVING SUNLIGHT PENETRATION PHOTOSENSOR -G107
• REMOVING CENTER INSTRUMENT PANEL LOUDSPEAKER
• REMOVING TRIM FOR CENTER DEFROSTER VENT
• REMOVING RIGHT INSTRUMENT PANEL COVER
• REMOVE LEFT INSTRUMENT PANEL COVER
• REMOVING LIGHT SWITCH AND ADJUSTER FOR HEADLIGHT RANGE CONTROL
• WINDSHIELD TRIM, ASSEMBLY OVERVIEW
• LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW
• REAR CROSS PANEL TRIM, ASSEMBLY OVERVIEW
• RIGHT SIDE TRIM, ASSEMBLY OVERVIEW
• LEFT SIDE TRIM, ASSEMBLY OVERVIEW
• CONVERTIBLE TOP COMPARTMENT LID, ASSEMBLY OVERVIEW
• HANDLE MOUNT TRIM, ASSEMBLY OVERVIEW

More articles — Accessories & Equipment
