Interior Trim - Except Cabriolet Audi A4 B6

Gauges & Instrument Panels 12 illustrations ~8852 words

Component locations, assembly overview

The following list pertains to (Scheme 1).

  1. Door trim, removing and installing , see «FRONT DOOR TRIM COMPONENTS, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__front-door-trim-components-assembly-overview)
  2. Bass speakers, removing and installing , see «BASS SPEAKER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__bass-speaker-removing-and-installing)
  3. Treble speakers, removing and installing , see «TREBLE SPEAKER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__treble-speaker-removing-and-installing)
  4. Door warning light, removing and installing, see «DOOR WARNING LIGHT AND FOOTWELL LIGHTING, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__door-warning-light-and-footwell-lighting)
  5. Interior door mechanism, removing and installing , see «INTERIOR DOOR MECHANISM, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__interior-door-mechanism-removing-and-installing)
  6. Decorative panel, removing and installing , see «FRONT DOOR TRIM COMPONENTS, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__front-door-trim-components-assembly-overview)
  7. Power window switch, removing and installing
  8. Mirror adjustment switch, removing and installing
  9. Central locking switch, removing and installing

Front door trim components, assembly overview

The following list pertains to (Scheme 2).

  1. Speed nut (4x)
  2. Bolt (4x)
  3. Screws (2x)
  4. Decorative panel
  5. Armrest, lower part
  6. Bolt
  7. Expanding nut (4x)
  8. Door trim. Removal Remove lower part of armrest -5-. Remove screws -3- (2x) from door trim -8-. Remove bolts -6- from door trim -8-. Unclip decorative panel -4-. Remove decorative panel -4- toward front. Remove bolt -2- (4x) from door trim -8-. Unclip door trim -8-, see «UNCLIPPING DOOR TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__unclipping-door-trim) . Raise door trim -8- upward approx. 20 cm. out from door shell. Disengage Bowden cable for interior door mechanism, see «DISENGAGING BOWDEN CABLE»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__disengaging-bowden-cable) Disconnect electrical harness connectors, see «DISCONNECTING ELECTRICAL HARNESS CONNECTORS»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__disconnecting-electrical-harness-connectors) Installing When installing, speed nuts -1- (4x) for expanding nuts -7- (4x) must be clipped in. When installing, door trim must be pressed in the middle to door shell.

Disengaging Bowden Cable

  1. Remove securing ring -3-.
  2. Pull Bowden cable -1- out of guide -2- and remove.

Disconnecting electrical harness connectors

Note. When installing make sure that catch -3- faces upward.

  1. Press catch -2- and remove harness connector -3- from control module in direction of arrow.
  2. Disconnect harness connector to bass speaker.

Unclipping Door Trim

  1. Press catches -2- and disconnect clip -1- in direction of arrow.

Armrest, assembly overview

Switches for window regulator, mirror adjustment and central locking, removing and installing

The following list pertains to (Scheme 6).

  1. Armrest Removal Remove door trim, see «FRONT DOOR TRIM COMPONENTS, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__front-door-trim-components-assembly-overview) . Remove bolts -2- (11x). Remove armrest -1- to side.
  2. Bolt (11x) For vehicles with manual window crank: Remove manual window crank, see «MANUAL WINDOW CRANK, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__manual-window-crank-removing-and-installing) .
  3. Window regulator switch For vehicles with electric window regulators: Remove window regulator switch, see «POWER WINDOW SWITCH, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__power-window-switch-removing-and-installing)
  4. Mirror adjustment switch Removal Press in tab on connector for mirror adjustment switch -4- and remove it. Remove mirror adjustment switch -4- using a screwdriver.
  5. Central locking switch Removal Press in tab on connector for central locking switch -5- and remove it. Pry out central locking switch -5- using a screwdriver. Raise door trim -1- upward approx. 20 cm. out from door shell. Disengage Bowden cable for interior door mechanism, see «DISENGAGING BOWDEN CABLE»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . Disconnect electrical harness connectors, see «DISCONNECTING ELECTRICAL HARNESS CONNECTORS»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . Installing When installing manual window crank, note its position, see «MANUAL WINDOW CRANK, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__manual-window-crank-removing-and-installing) .
  1. Remove securing ring -3-.
  2. Pull Bowden cable -1- out of guide -2- and remove.

Note. When installing make sure that catch -3- faces upward.

  1. Press catch -2- and remove harness connector -3- from control module in direction of arrow.
  2. Disconnect harness connector to bass speaker.

Manual window crank, removing and installing

  1. Remove cover -1- of manual window crank -3- upward.
  2. Remove bolt -2- of manual window crank -3-.
  3. Remove manual window crank -3- upward.
  4. Installation position -a- must be adjusted by 5° to 20° with window closed.

Power window switch, removing and installing

  1. Press in tab -2- on connector for window regulator switch -1- and remove it.
  2. Pry out window regulator switch -1- using a screwdriver.

Cable routing and door trim, assembly overview

The following list pertains to (Scheme 12).

Scheme 1

Scheme 1: Cable routing and door trim, assembly overview
Scheme 1: Cable routing and door trim, assembly overview
  1. Cable to central locking switch, only driver-side
  2. Cable to window regulator switch
  3. Cable to mirror adjustment switch
  4. Cable to treble speaker
  5. Cable to bass speaker
  6. Cable to door warning light
  7. Cable to footwell lighting
  8. Cable to lighting of anti-theft warning system

Door warning light and footwell lighting, removing and installing

  1. Detach door warning light -1- from below using a screwdriver and remove toward outside together with cable.
  2. Disconnect door warning light -1-.
  3. Detach front footwell lighting -2- using a screwdriver and remove toward outside together with cable.
  4. Disconnect footwell lighting -2-.

Treble speaker, removing and installing

  1. Remove door trim, see «FRONT DOOR TRIM COMPONENTS, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__front-door-trim-components-assembly-overview)
  2. Press back catches -2- (3x) using a flat-head screwdriver.
  3. Remove treble speaker -1-.

Bass speaker, removing and installing

  1. Remove door trim, see «FRONT DOOR TRIM COMPONENTS, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__front-door-trim-components-assembly-overview)
  2. Remove bolts -1- (3x). Tightening torque 1.5 Nm.
  3. Remove bass speaker -2- and disconnect electrical connection.

Interior door mechanism, removing and installing

  1. Remove door trim, see «FRONT DOOR TRIM COMPONENTS, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__front-door-trim-components-assembly-overview) .
  2. Central locking switch, removing, see «ARMREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__armrest-assembly-overview) .
  3. Remove bolt -1-.
  4. Press retaining tabs -2- (2x) and remove interior door handle -3- toward the front.

The following list pertains to see scheme 17.

  1. Door trim, Removing and installing, see «REAR DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__rear-door-trim-assembly-overview)
  2. Bass speakers Removing and installing, see «BASS SPEAKER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet)
  3. Treble speakers Removing and installing, see «TREBLE SPEAKER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet)
  4. Door warning light Removing and installing, see «DOOR WARNING LIGHT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__door-warning-light-removing-and-installing)
  5. Interior door mechanism Removing and installing, see «INTERIOR DOOR HANDLE, REMOVING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__interior-door-handle-removing)
  6. Decorative panel Removing and installing, see «REAR DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__rear-door-trim-assembly-overview)
  7. Manual window crank Removing and installing, see «REAR DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__rear-door-trim-assembly-overview)
  8. Cover Removing and installing, see «REAR DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__rear-door-trim-assembly-overview)
  9. Window regulator switch Removing and installing, see «POWER WINDOW SWITCH, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet)

Rear door trim, assembly overview

The following list pertains to see scheme 18.

  1. Door trim. Removal Unclip decorative panel -2-. Remove decorative panel -2- toward front. Remove bolts -3- (3x) from door trim -1-. For vehicles with electric window regulators Window regulator switch, removing and installing, see «POWER WINDOW SWITCH, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) For vehicles with manual window crank Manual window crank, removing and installing, see «MANUAL WINDOW CRANK, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . For all vehicles Unclip door trim -1-. Replace damaged clips, see «UNCLIPPING DOOR TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) Raise door trim -1- upward approx. 20 cm. out from door shell. Disengage Bowden cable for interior door mechanism, see «DISENGAGING BOWDEN CABLE»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . Disconnect electrical harness connectors, see «DISCONNECTING ELECTRICAL HARNESS CONNECTORS»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet)

Installing

When installing, speed nuts -8- (4x) for expanding nuts -7- (4x) must be clipped in.

When installing, door trim must be pressed in the middle to door shell.

When installing manual window crank, note its position. See MANUAL WINDOW CRANK, REMOVING AND INSTALLING .

  1. 2 - Decorative panel
  2. 3 - Bolts (3x)
  3. 4 - Cover
  4. 5 - Manual window crank
  5. 6 - Bolt
  6. 7 - Expanding nut (4x)
  7. 8 - Speed nut (4x)
  8. 9 - Window regulator switch
  1. Remove securing ring -3-.
  2. Pull Bowden cable -1- out of guide -2- and remove.

Note. When installing make sure that catch -3- faces upward.

  1. Press catch -2- and remove harness connector -3- from control module in direction of arrow.
  2. Disconnect harness connector to bass speaker.
  1. Press catches -2- and disconnect clip -1- in direction of arrow.
  1. Press in tab -2- on connector for window regulator switch -1- and remove it.
  2. Pry out window regulator switch -1- using a screwdriver.
  1. Remove cover -1- of manual window crank -3- upward.
  2. Remove bolt -2- of manual window crank -3-.
  3. Remove manual window crank -3- upward.
  4. Installation position -a- must be adjusted by 5° to 20° with window closed.

The following list pertains to see scheme 25.

  1. Bolts (8x)
  2. Armrest Removal Remove door trim, see «REAR DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__rear-door-trim-assembly-overview) . Remove bolts -1- (8x). Remove armrest -2- to side.
  3. Window regulator switch

The following list pertains to see scheme 26.

  1. Cable to treble speaker
  2. Cable to bass speaker
  3. Cable to door warning light
  4. Cable to lighting of interior door mechanism

Door warning light, removing and installing

  1. Detach door warning light -1- from below using a screwdriver and remove toward outside together with cable.
  2. Disconnect door warning light -1-.
  1. Remove door trim, see «REAR DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__rear-door-trim-assembly-overview) .
  2. Remove bolts -1- (3x). Tightening torque 1.5 Nm.
  3. Remove bass speaker -2- and disconnect electrical connection.
  1. Remove door trim, see «REAR DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__rear-door-trim-assembly-overview) .
  2. Using a screwdriver detach bracket -1-.
  3. Remove treble speaker -2-.
  4. Pull wiring harness from door trim up to bass speaker.

Interior door handle, removing

  1. Remove door trim, see «REAR DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__rear-door-trim-assembly-overview) .
  2. Remove bolt -1-.
  3. Remove interior door mechanism -2- toward front.

Scheme 2

Scheme 2: Sun shade for door window, removing and installing
Scheme 2: Sun shade for door window, removing and installing

Scheme 3

Scheme 3
Scheme 3
  1. Removing Remove door trim, see «REAR DOOR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__rear-door-trim-assembly-overview) Remove guiding strips -3- from holding clips -1-. Remove caps -2-. Disengage gripping part of sun shade -4-. Remove bolts -1- (4x). Tightening torque: 1.5 Nm. Remove sun shade -2-.

Retaining clips for sun shade, removing and installing

  1. Sheet metal screws - 1.5 Nm.
  2. Retaining hook

Note. Backing plate -3- is used to balance out tolerances and must be reinserted where it was installed by the factory.

Scheme 4

Scheme 4
Scheme 4

The following list pertains to see scheme 34.

  1. Instrument panel Removing and installing, see «INSTRUMENT PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__instrument-panel-removing-and-installing)
  2. Left instrument panel vent Removing and installing, see «LEFT AND RIGHT INSTRUMENT PANEL VENTS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__left-and-right-instrument-panel-vents)
  3. Instrument cluster Removal: See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#instrument-systems-except-cabriolet) .
  4. Upper trim for steering column switches Removing and installing, see «UPPER TRIM FOR STEERING COLUMN SWITCHES, REMOVING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__upper-trim-for-steering-column-switches)
  5. Center defroster outlets Removing and installing, see «CENTER DEFROSTER OUTLET, REMOVING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet)
  6. Photo sensor Removing and installing, see «CENTER DEFROSTER OUTLET, REMOVING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet)
  7. Instrument panel speaker Removing and installing, see «INSTRUMENT PANEL SPEAKER, REMOVING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__instrument-panel-speaker-removing)
  8. Center instrument panel vent Removing and installing, see «CENTER INSTRUMENT PANEL VENT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__center-instrument-panel-vent-removing-and)
  9. Passenger-side airbag unit Removing and installing, see appropriate Air Bag Restraint Systems article.
  10. Right instrument panel vent Removing and installing, see «LEFT AND RIGHT INSTRUMENT PANEL VENTS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__left-and-right-instrument-panel-vents)
  11. Right instrument panel cover Removing and installing, see «RIGHT INSTRUMENT PANEL COVER, REMOVING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__right-instrument-panel-cover-removing)
  12. Right trim for instrument panel Removing and installing, see «RIGHT TRIM FOR INSTRUMENT PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__right-trim-for-instrument-panel-removing) .
  13. Glove compartment Removing and installing, see «GLOVE COMPARTMENT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__glove-compartment-removing-and-installing)
  14. Center console Removing and installing, see «CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__center-console-assembly-overview) .
  15. Front ashtray Removing and installing, see «FRONT ASHTRAY, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__front-ashtray-assembly-overview) .
  16. Center part of instrument panel Removing and installing, see «CENTER SECTION OF DASH PANEL, ASSEMBLY OVERVIEW»(ref-197209-S19508341112005101300000)
  17. Driver side storage compartment Removing and installing, see «DRIVER-SIDE STORAGE COMPARTMENT (WITH AND WITHOUT KNEE BOLSTER), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__driver-side-storage-compartment-with-and-without)
  18. Left trim for instrument panel Removing and installing, see «LEFT TRIM FOR INSTRUMENT PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__left-trim-for-instrument-panel-removing)
  19. Light switch and headlight beam adjuster Removing and installing, see «LIGHT SWITCH AND HEADLIGHT BEAM ADJUSTER, REMOVING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__light-switch-and-headlight-beam-adjuster)
  20. Left instrument panel cover Removing and installing, see «LEFT INSTRUMENT PANEL COVER, REMOVING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__left-instrument-panel-cover-removing)

Instrument panel, removing and installing

Special Tools and Equipment

  1. Special hook for front end 3370
WARNINGObserve safety precautions when disconnecting the battery.

Scheme 5

Scheme 5
Scheme 5

Removing

CAUTIONOn vehicles equipped with Audi Telematics by OnStar(R), switch-off the emergency (back-up) battery for the Telematic/Telephone Control Module prior to disconnecting the vehicle battery. Switch-on the emergency (back-up) battery after reconnecting the vehicle battery. See TELEMATICS .
  1. Disconnect battery Ground (GND) strap from battery.
  2. Removing driver side airbag unit (standard steering wheel). See appropriate Air Bag Restraint Systems article.
  3. Removing driver side airbag unit (sport steering wheel). See appropriate Air Bag Restraint Systems article.
  4. Removing driver side airbag unit (multi-function steering wheel). See appropriate Air Bag Restraint Systems article.
  5. Remove steering wheel (standard steering wheel). See appropriate Air Bag Restraint Systems article.
  6. Remove steering wheel (sport steering wheel). See appropriate Air Bag Restraint Systems article.
  7. Remove steering wheel (multi-function steering wheel). See appropriate Air Bag Restraint Systems article.
  8. Removing driver side storage compartment. See «DRIVER-SIDE STORAGE COMPARTMENT (WITH AND WITHOUT KNEE BOLSTER), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__driver-side-storage-compartment-with-and-without) .
  9. Remove instrument cluster. See «INSTRUMENT CLUSTER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#instrument-systems-except-cabriolet) .
  10. Remove glove compartment (without knee bolster). See «GLOVE COMPARTMENT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__glove-compartment-assembly-overview) .
  11. Remove glove compartment (vehicles with knee bolster). See «GLOVE COMPARTMENT, REMOVING AND INSTALLING (VEHICLES WITH KNEE BOLSTER)»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__glove-compartment-removing-and-installing-vehicles) .
  12. Remove passenger-side airbag unit. See appropriate Air Bag Restraint Systems article.
  13. Removing center console. See «CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__center-console-assembly-overview) .
  14. Remove instrument panel center piece. See «CENTER PART OF INSTRUMENT PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__center-part-of-instrument-panel-assembly) .

Light switch and headlight beam adjuster, removing

  1. Press light switch -arrow 1- and turn toward the right simultaneously -arrow 2-.
  2. Hold switch in this position...
  3. ... and pull off light switch from switch housing -3-.
  4. Disconnect electrical harness connector.
  5. Press headlight beam adjuster from switch housing.
  6. Disconnect electrical harness connector.

Upper trim for steering column switches, removing

Driver-side airbag and steering wheel removed.

  1. Pull steering column all the way out and down.
  2. Remove bolts -1- (2x). Tightening torque: 3 Nm
  3. Remove bolts -3-. Tightening torque 0.6 Nm.
  4. Unclip gap cover downward from instrument panel -arrow-.
  5. Remove upper trim -2- for steering column switch.

Photo sensor, removing

  1. Carefully pry off cover -A-.
  2. Remove bolt -B-.
  3. Disconnect cable connector.

Scheme 6

Scheme 6: Center defroster outlet, removing
Scheme 6: Center defroster outlet, removing
  1. Remove bolt -1- of defroster outlet. Tightening torque: 0.8 Nm.
  2. Remove defroster vent.

Instrument panel speaker, removing

Center defroster outlet removed.

  1. Remove bolts -1- (2x). Tightening torque: 2 Nm.
  2. Swing speaker out and disconnect harness connector.

Harness connectors for vent temperature sensor, disconnecting

Scheme 7

Scheme 7
Scheme 7
  1. Disconnect left and right harness connector -arrow- on outside temperature sensor.

Note. In the illustration, vent temperature sensor is depicted on the passenger side.

Scheme 8

Scheme 8
Scheme 8

Left instrument panel cover, removing

  1. Pull off left cover on instrument panel -arrow- using special tool 3370.

Mount for left exterior instrument panel, removing

Scheme 9

Scheme 9
Scheme 9
  1. Remove bolts -1- (2x). Tightening torque: 4.5 Nm.

Right instrument panel cover, removing

  1. Pull off right cover on instrument panel -arrow- using special tool 3370.

Mount for right exterior instrument panel, removing

Scheme 10

Scheme 10
Scheme 10
  1. Remove bolts -1- (2x). Tightening torque: 4.5 Nm.

Driver-side instrument panel mount, removing

  1. Remove bolts -1- (2x). Tightening torque: 4.5 Nm.

Center instrument panel mount, removing

Scheme 11

Scheme 11
Scheme 11
  1. Remove bolts -1- (2x). Tightening torque: 3 Nm.
  2. Remove bolts -2- (2x). Tightening torque: 4.5 Nm.
  3. Remove shift mechanism toward rear.
  1. Check whether felt -2- is installed on clip -1- on left and right.
  2. Slide instrument panel into clip by lightly pressing down.
  3. Check seating of front instrument panel in clip by lightly pulling up.
  4. Rest of installation is reverse of removal.

Left trim for instrument panel, removing and installing

Special Tools and Equipment

  1. Special hook for front end 3370

Removing

  1. Removing driver side storage compartment. See «DRIVER-SIDE STORAGE COMPARTMENT (WITH AND WITHOUT KNEE BOLSTER), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__driver-side-storage-compartment-with-and-without) .
  2. Pull off left cover on instrument panel -arrow- using special tool 3370.
  3. Press light switch -arrow 1- and turn toward the right simultaneously -arrow 2-.
  4. Hold switch in this position...
  5. ... and pull off light switch from switch housing -3-.
  6. Disconnect electrical harness connector.
  7. Press headlight beam adjuster from switch housing.
  8. Disconnect electrical harness connector.
  9. Remove bolts -1- (3x). Tightening torque: 3 Nm
  10. Remove trim piece.
  1. Installation is reverse of removal.

Right trim for instrument panel, removing and installing

Special Tools and Equipment

  1. Special hook for front end 3370
  1. Removing driver side storage compartment. See «DRIVER-SIDE STORAGE COMPARTMENT (WITH AND WITHOUT KNEE BOLSTER), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__driver-side-storage-compartment-with-and-without) .
  2. Open glove compartment.
  3. Carefully remove trim -1- toward rear using special tool 3370.
  4. Pull off right cover on instrument panel -arrow- using special tool 3370.
  5. Remove bolt -1-. Tightening torque: 3 Nm
  6. Remove bolts -1- (3x). Tightening torque: 3 Nm
  7. Remove right trim piece.
  1. Installation is reverse of removal.

Left and right instrument panel vents, removing and installing

Special Tools and Equipment

  1. Special hook for front end 3370
  1. Carefully remove instrument panel vent toward rear using special tool 3370.
  1. Installation is reverse of removal.

Left and right instrument panel air guides, removing and installing

Special Tools and Equipment

  1. Pop-rivet pliers VAS 5072
  1. Remove instrument panel, see «INSTRUMENT PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__instrument-panel-removing-and-installing) .
  2. Remove air quality sensor on the damaged side.
  3. Cut through weld points -2- (4x) flush to air guide using a sharp knife.
  4. Remove damaged air guide.
  5. Bore a 5mm hole at points -2- (3x).
  1. Install new air guide, making sure that no pieces remain in the air channel.
  2. Rivet in the provided pop rivets for air guide at points -2- (3x).
  3. Install the provided bolt -3- for air guide.
  4. Rest of installation is reverse of removal.

Center instrument panel vent, removing and installing

Special Tools and Equipment

  1. Special hook for front end 3370
  1. Carefully remove instrument panel vent alternately on left and right toward rear using special tool 3370.
  1. Installation is reverse of removal.

The following list pertains to see scheme 69.

  1. Angle bracket
  2. Bolts (3x) Tightening torque: 23 Nm.
  3. Bolt Tightening torque: 6 Nm.
  4. Sealing washer
  5. Bolt Tightening torque: 6 Nm.
  6. Cross member
  7. Bolts (2x) Tightening torque: 9 Nm.
  8. Bolts (2x) Tightening torque: 23 Nm.
  9. Angle bracket
  10. Angle bracket
  11. Bolt Tightening torque: 9 Nm.
  12. Nut Tightening torque 35 Nm.
  13. Bolts (2x) Tightening torque: 8 Nm
  14. Angle bracket for air conditioner
  15. Bolts (2x) Tightening torque: 9 Nm.
  16. Brace
  17. Bolts (2x) Tightening torque: 9 Nm.
  18. Bolts (2x) Tightening torque: 9 Nm.
  19. Brace
  20. Reinforcement bracket
  21. Brace
  22. Bolts (2x) Tightening torque: 9 Nm.
  23. Bolt Tightening torque: 8 Nm
  24. Bolts (2x) Tightening torque: 9 Nm.
  25. Bolt Tightening torque: 8 Nm
  26. Nut Tightening torque 35 Nm.

Instrument panel cross member, removing and installing

Special Tools and Equipment

  1. 80--200 Pry bar
  1. Remove instrument panel, see «INSTRUMENT PANEL, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__instrument-panel-removing-and-installing) .
  2. Remove bolts -1- (2x) of fuse carrier -2-. Tightening torque: 3 Nm
  3. Lay the fuse carrier with attached wires downward.
  4. Unhook wiring harness on carrier for instrument panel and set aside.
  5. Remove bolts -1- (2x) of 3-pin fuse carrier -2-. Tightening torque: 3 Nm
  6. Remove nuts -3- (2x) of 6-pin relay carrier -4- with control module for vehicle electrical system. Tightening torque: 2.4 Nm
  7. Lay the relay carrier with attached wires downward.
  8. Remove wiring harness behind relay carrier from cross member and set it aside.
  9. Remove bolt -2- of pedal bracket. Tightening torque: 23 Nm.
  10. Remove bolts -1- (4x). Tightening torque: 22 Nm.
  11. Place steering column in driver-side footwell.
  12. Remove bolts -1- (4x) of left brace. Tightening torque: 9 Nm.
  13. Remove bolt -2-. Tightening torque: 8 Nm NOTE: Brace remains installed, so it is sufficient to only loosen bolt -3- and swing the brace downward.
  14. Loosen/remove bolt -3- (front mount for brace on air conditioner). Tightening torque 8 Nm.
  15. Remove brace or swing it downward.
  16. Disengage air guide at air conditioner -arrow 1- and remove it upward -arrow 2-.
  17. Remove bolts -1- (4x). Tightening torque: 9 Nm.
  18. Move cable -2- clear.
  19. Remove right support.
  20. Remove bolts -1- (2x) of bracket for air conditioner. Tightening torque: 11 Nm.
  21. Pry off both covers -3- using a screwdriver.
  22. Loosen hex-nuts -4- by several turns.
  23. Loosen wiper arm -2- by lightly tilting from wiper axle.
  24. Remove hex nuts completely and remove wiper arms.
  25. Disconnect securing clips -1- and remove cowl grill -5-.
  26. Remove cover for E-box, plenum chamber -arrows-.
  27. Carefully pry off mounting bracket -arrow- assisted with a screwdriver and lay Engine Control Module (ECM) with attached wires aside.
  28. Unclip retaining bracket.
  29. If installed, lay the Transmission Control Module (TCM) with attached wires aside.
  30. Remove bolts -2- (2x) of connector station. Tightening torque: 3 Nm
  31. Remove cross member bolt -1- for instrument panel in plenum chamber. Tightening torque: 6 Nm.
  32. Remove left bolts -1- (2x). Tightening torque: 35 Nm.
  33. Remove top bolt -3-. Tightening torque: 6 Nm.
  34. Remove ground (GND) wires -2-.
  35. Remove right bolt -2-. Tightening torque: 35 Nm.
  36. Remove ground (GND) wires -1-.
  37. Move cross member for instrument panel several millimeters toward the front.
  38. Pull out pins -2- (2x) upward as far as possible using a small screwdriver.
  39. Lay aside electrical wiring harness behind vent.
  40. Pull headrest upward -arrow-.
  41. Remove ground (GND) wires -1-.
  42. Press off the wiring harness behind cross member for instrument panel from cross member for instrument panel -arrows-.
  43. Use pry bar 80--200.
  44. Remove cross member for instrument panel.
  1. Installation is reverse of removal.

Sun visor, assembly overview

The following list pertains to see scheme 87.

  1. Sun visor Removal Disengage sun visor -1- in vehicle center from retaining clip -2-. Push sun visor -1- to the side. Pry out bolt cover -3- on sun visor -1- and remove T25 Torx bolt -4-. Disconnect harness connector using caution for make-up mirror lighting, if installed. Remove sun visor -1-.
  2. Sun visor center holder
  3. Bolt cover
  4. Bolt Tightening torque: 4 Nm Self-locking Always replace Always clean threaded holes for bolts (e.g. using a thread cutter)
  1. Remove bolt -2- from center sun visor -1-.
  2. Tightening torque bolt -2-: 3 Nm
  1. Installation is reverse of removal.

Molded headliner, assembly overview

The following list pertains to see scheme 89.

  1. Molded headliner Removal Remove right and left sun visor. See «ROOF TRIM (SEDAN)»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . Remove sun visor center holder -7-: Unclip cap -8-. Remove two clips, engage the expanding clip lying beneath them and remove sun visor center holder. Remove upper A-pillar trim on right and left. See «UPPER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__upper-a-pillar-trim-assembly-overview) . Remove upper B-pillar trim. See «UPPER B-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__upper-b-pillar-trim-assembly-overview) . Remove roof end strip. See «ROOF END, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__roof-end-assembly-overview) . Remove D-pillar trim on right and left. See «D-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__d-pillar-trim-assembly-overview) . Remove rear interior reading light -6-. See «REAR INTERIOR LIGHT/READING LIGHT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#lights-switches-interior-anti-theft-except-cabriolet) . If installed, open sunroof. Remove slide/tilt sunroof trim frame -2-. Remove left and right lighting for make-up mirror. See «LIGHT FOR MAKE-UP MIRROR, REMOVING AND INSTAL»(/audi/a4/b6-2000-2006/remont/communication-devices/#lights-switches-interior-anti-theft-except-cabriolet__light-for-make-up-mirror-removing-and) . Remove front interior reading light -5-. See «FRONT INTERIOR LIGHT/READING LIGHT, REMOVING»(/audi/a4/b6-2000-2006/remont/communication-devices/#lights-switches-interior-anti-theft-except-cabriolet) . Unclip cover on rear view mirror boot and disconnect electrical harness connector to rear view mirror, see «DISCONNECTING ELECTRICAL HARNESS CONNECTORS»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . Place shift or selector lever as far to front as possible. Move passenger-side backrest as far back as possible. Move driver-side backrest as far back as possible. A second technician is required to support the molded headliner. Loosen clip -3- below on molded headliner. For vehicles with sunroof, remove front bolt -4- on molded headliner. To remove cable at molded headliner, exit vehicle and carefully lower molded headliner onto seats. Disconnect wiring harness if necessary from A-pillar. Remove cable harness from molded headliner, see «CABLE ROUTING ON BACK SIDE OF MOLDED HEADLINER»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__cable-routing-on-back-side-of) Take out molded headliner through a rear door. Installing Insert molded headliner carefully through a rear door. Attach cable harness at molded headliner, see «CABLE ROUTING ON BACK SIDE OF MOLDED HEADLINER»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__cable-routing-on-back-side-of) NOTE: If installation sequence is not followed, roof trim panel cannot be centered. Clip in bracket for sun visors. Clip in slide/tilt sunroof cover frame -2-. If installed, tighten bolt -4- to sunroof. Clip in rear molded headliner securely at clip -3-. Rest of installation is reverse of removal.
  2. Sunroof cover frame
  3. Clip
  4. Bolt
  5. Front lighting module
  6. Rear lighting module
  7. Sun visor center holder
  8. Concealment cap
  1. Unclip trim on mirror boot and disconnect electrical harness connector -arrow-.

Cable routing on back side of molded headliner

The following list pertains to see scheme 91.

  1. Molded headliner, rear side Molded headliner removed (resting on seats) Disconnect harness connector -4-. Disconnect harness connectors -5-. Disconnect harness connector -6-. Remove cable to sun visor -8-. Unclip cable channels -3-. Route cable harness -2- through cable guide -7-.
  2. Cable harness
  3. Cable channels (6x)
  4. Harness connector for rear courtesy lamp
  5. Harness connectors for sun visor lighting.
  6. Harness connector for interior lighting.
  7. Cable guide
  8. Cable to sun visor
  1. Open cover -3-.
  2. Remove T25 Torx bolts -2-.
  3. Tightening torque: 3.5 Nm
  4. Remove roof grab handle -1-.

Note. Threaded holes for roof grab handle must always be cleaned of locking fluid residue after removal of roof grab handle. Otherwise there is a possibility that the new bolts may get jammed when installed and shear when removed. Cleaning can be performed with a tap. Replace roof grab handle bolts (self-locking).

Scheme 12

Scheme 12
Scheme 12
  1. Installation is reverse of removal.

The following list pertains to see scheme 93.

  1. Sun visor Removal Disengage sun visor -1- in vehicle center from retaining clip -2-. Push sun visor -1- to the side. Pry out bolt cover -3- on sun visor -1- and remove bolt -4-. Disconnect harness connector for make-up mirror lighting, if installed. Remove sun visor -1-.
  2. Sun visor center holder
  3. Bolt cover
  4. Bolt Tightening torque: 4 Nm Self-locking Always replace Always clean threaded holes for bolts (e.g. using a thread cutter)
  1. Remove bolt -2- from center sun visor -1-.
  2. Tightening torque bolt -2-: 3 Nm
  1. Installation is reverse of removal.

The following list pertains to see scheme 95.

  1. Clip
  2. Molded headliner Removal Remove right and left sun visor. See «SUN VISOR, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . Unclip caps -6-. Engage expanding clips lying beneath and remove sun visor center holder -5-. Remove upper A-pillar trim on right and left. See «UPPER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__upper-a-pillar-trim-assembly-overview) . Remove roof end strip. See «ROOF END, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__roof-end-assembly-overview) . Remove D-pillar trim on right and left. See «D-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__d-pillar-trim-assembly-overview) . Remove trim above rear door. See «TRIM ABOVE REAR DOOR, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__trim-above-rear-door-assembly-overview) . Remove left and right lighting for make-up mirror. See «LIGHT FOR MAKE-UP MIRROR, REMOVING AND INSTAL»(/audi/a4/b6-2000-2006/remont/communication-devices/#lights-switches-interior-anti-theft-except-cabriolet__light-for-make-up-mirror-removing-and) . Remove front interior reading light. See «FRONT INTERIOR LIGHT/READING LIGHT, REMOVING»(/audi/a4/b6-2000-2006/remont/communication-devices/#lights-switches-interior-anti-theft-except-cabriolet) . Disconnect electrical harness connector at sunroof motor. If installed, remove front bolt -4- on molded headliner. Unclip cover on rear view mirror boot and disconnect electrical harness connector to rear view mirror. See «DISCONNECTING ELECTRICAL HARNESS CONNECTORS»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . Fold rear backrest forward. Fold driver-side and passenger-side backrests backward. Unclip molded headliner around sunroof opening (16 spring clips). Carefully lower front molded headliner - a second technician is required to support the molded headliner. Loosen clip -1- below on molded headliner. Carefully lower roof liner at rear. Disconnect wiring harness if necessary from A-pillar. Remove cable harness from molded headliner. See «CABLE ROUTING ON BACK SIDE OF MOLDED HEADLINER»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . Take out molded headliner via rear lid. Installing NOTE: When installing a new molded headliner, clip frame for sunroof -3- to molded headliner. Insert molded headliner carefully via rear lid. Attach cable harness at molded headliner. See «CABLE ROUTING ON BACK SIDE OF MOLDED HEADLINER»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . NOTE: If installation sequence is not followed, roof trim panel cannot be centered. Clip in rear molded headliner securely at clip -1-. If installed, tighten bolt -4- to sunroof. Clip in the sun visor center holder. Rest of installation is reverse of removal.
  3. Frame For sunroof
  4. Bolt
  5. Sun visor center holder
  6. Concealment cap
  1. Unclip trim on mirror boot and disconnect electrical harness connector -arrow-.

The following list pertains to see scheme 97.

  1. Molded headliner, rear side Molded headliner removed (resting on seats) Disconnect harness connectors -14- and -15-. Unclip wiring harness -3- from cable channels -2-.
  2. Cable guide
  3. Cable harness
  4. Electrical harness connector For sun visor (for makeup lighting switch)
  5. Electrical harness connector For make-up lighting
  6. Electrical harness connector For interior sensor of anti-theft warning system
  7. Electrical harness connector Not for US/Canada
  8. Electrical harness connector For sliding sunroof motor
  9. Electrical harness connector For front interior reading light
  10. Electrical harness connector For hands-free microphone
  11. Electrical harness connector For automatic day/night rear view mirror
  12. Electrical harness connector For make-up lighting
  13. Electrical harness connector For sun visor (for makeup lighting switch)
  14. Electrical harness connector For rear interior reading light
  15. Electrical harness connector For luggage compartment light

Roof grab handle, removing and installing

  1. Removing Open cover -3-. Remove bolts -2-. Tightening torque: 3.5 Nm Remove roof grab handle -1-. NOTE: Threaded holes for roof grab handle must always be cleaned of locking fluid residue after removal of roof grab handle. Otherwise there is a possibility that the new bolts may get jammed when installed and shear when removed. Cleaning can be performed with a tap. Replace roof grab handle bolts (self-locking).

Upper A-pillar trim, assembly overview

WARNINGObserve safety precautions for working on side curtain airbags, see appropriate Air Bag Restraint Systems article.

The following list pertains to see scheme 99.

  1. Upper A-pillar trim Removal Remove sun visor. See «SUN VISOR, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__sun-visor-assembly-overview) . Remove roof grab handle. See «ROOF GRAB HANDLE, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) Unclip rear airbag label -9- (on B-pillar) and move it down. Remove bolt from airbag label. Remove upper A-pillar trim -1- clips -3- using special tool 3370. Move upper A-pillar trim -1- to the rear. WARNING: Always follow installation sequence for A-pillar trim Installing Guide upper A-pillar trim -1- toward front between door rubber and side plate. Guide trim retainer -10- into the proper clip. Clip securely the upper A-pillar trim -1- using three clips -3-. Slide up trim beneath B-pillar trim. Ensure that the clip and metal hook of side curtain airbag adapter engage securely. WARNING: Make sure trim has a proper fit.
  2. Bolts (2x) Tightening torque 3.5 Nm (2.5 ft.lbs) Self-locking Always replace Always clean threaded holes for bolts (e.g. using a thread cutter)
  3. Clips (3x)
  4. Lid for roof grab handle
  5. Roof grab handle Removing, see «ROOF GRAB HANDLE, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet)
  6. Mounts
  7. Groove
  8. Gasket After assembling trim, make sure seal is properly installed
  9. Airbag label
  10. Retainer

Lower A-pillar trim, assembly overview

The following list pertains to see scheme 100.

  1. Lower A-pillar trim panel Removal Unclip two clips -5- and remove A-pillar intermediate piece -4-. Unclip lower A-pillar trim -1- from intermediate piece -4-. Unclip two clips -2- at lower A-pillar trim -1-. Pull hook -6- from bracket -3-. Installing When installing, ensure that the door rubber is pulled cleanly over the lower A-pillar trim.
  2. Clips (2x)
  3. Bracket
  4. A-pillar intermediate piece
  5. Clips (2x)
  6. Hook
  1. Remove foot rest. Remove lower A pillar trim, see «LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__lower-a-pillar-trim-assembly-overview) . Remove nut -1-. Tightening torque: 4 Nm Press foot rest -2- upward and remove.
  2. Remove foot rest bracket. Remove foot rest. Pull up floor mat in area near bracket for foot rest. Remove nut -4- (2x). Tightening torque: 4 Nm Remove foot rest bracket -3-.
  1. Installation is reverse of removal.

Upper B-pillar trim, assembly overview

WARNINGObserve safety precautions for working on side curtain airbags, see appropriate Air Bag Restraint Systems article.

The following list pertains to see scheme 102.

  1. B-pillar trim Removal Remove outer seat belt attachment Remove upper A-pillar trim. See «UPPER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__upper-a-pillar-trim-assembly-overview) . Remove upper D-pillar trim. See «D-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__d-pillar-trim-assembly-overview) . Remove B-pillar trim -1- from door rubber. Unclip lower two clips -2- at trim. Unclip upper two retaining tabs -5- at trim -1-. Remove trim -1- vertically downward. Remove lower belt on seat at outer belt buckle attachment point. Unwind belt -3- from belt height adjuster -4- Installation NOTE: Do not press switch -6- when installing. WARNING: Always follow installation sequence for B-pillar trim Wind belt -3- into belt height adjuster -4-. Install height adjuster -4-. See «INSTALLING UPPER B PILLAR TRIM IN BELT HEIGHT ADJUSTER»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__installing-upper-b-pillar-trim-in) . Clip in B-pillar trim to upper edge. Ensure that the two tabs -5- and two retainers -7- engage correctly (gap width must fit). Clip clips -2- to lower edge of upper B-pillar trim -1-. WARNING: Make sure trim has a proper fit. NOTE: Function check after installing trim: Belt height adjuster must audibly engage into all five possible positions (even top position). Button must return by itself to upper position after being actuated.
  2. Clips (2x)
  3. Belt webbing
  4. Belt height adjuster
  5. Tabs (2x)
  6. Switch for height adjustment
  7. Retainers (2x)

Installing Upper B Pillar Trim In Belt Height Adjuster

  1. Guide the slide with button -4- (without pressing) beginning at the top and working downward into release lever -1- of height adjuster while at the same time installing pin -2- into mounting -3-.

Lower B-pillar trim, assembly overview

The following list pertains to see scheme 104.

  1. B-pillar trim NOTE: For removing the lower B-pillar trim, the outer seat belt attachment point must not be removed. Removal Unclip upper A-pillar trim at rear end, see «LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__lower-a-pillar-trim-assembly-overview) . Remove upper B-pillar trim. See «UPPER B-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__upper-b-pillar-trim-assembly-overview) . Unclip lower two clips -2- at rear end of lower B-pillar trim -1-. Move lower B-pillar trim -1- upward until B-pillar trim disengages from belt guide -4-. NOTE: Ensure that the belt webbing -3- is not jammed when installing trim. Installing Guide pins -5- into hole on shell construction sill. Attach upper trim -1- to belt guide -4-. Secure lower rear trim -1- with clip -2-. Clip lower A-pillar trim again at rear. See «LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__lower-a-pillar-trim-assembly-overview) . Install upper B-pillar trim again. See «UPPER B-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__upper-b-pillar-trim-assembly-overview) . After assembling trim, make sure seal is properly installed
  2. Clip
  3. Belt webbing
  4. Belt guide
  5. Pins

C-pillar trim, assembly overview

WARNINGObserve safety precautions for working on side curtain airbags, see appropriate Air Bag Restraint Systems article.

The following list pertains to see scheme 105.

  1. C-pillar trim Removal Remove D-pillar trim. See «D-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__d-pillar-trim-assembly-overview) . Remove two bolts -2- on C-pillar trim -1- at top and bottom. Remove side panel. See «BACK SEAT SIDE BOLSTER, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-except-cabriolet__back-seat-side-bolster-assembly-overview) . Remove clip -3- beneath side panel: Press a screwdriver between both clip parts and pull up the upper clip part. Press lower clip part together and let it loosen. Unclip rear shelf at outer clip and lift it up. Unclip C-pillar trim at clip -4- and remove it. WARNING: Always follow installation sequence for C-pillar trim Installing Raise the rear shelf. Position trim -1- into mount at rear shelf. Clip securely clip -4- in its mount. Press lower part of clip -3- together and insert the clip again. Install two bolts -2- again. WARNING: Make sure trim has a proper fit. Secure rear shelf and side panel.
  2. Bolts (2x) Tightening torque 4 Nm. Self-locking Always replace Always clean threaded holes for bolts (e.g. using a thread cutter)
  3. Clip (1x)
  4. Clip (1x)

D-pillar trim, assembly overview

WARNINGObserve safety precautions for working on side curtain airbags,. See appropriate Air Bag Restraint Systems article.

The following list pertains to see scheme 106.

  1. Upper D-pillar trim panel Removal Remove upper A-pillar trim. See «UPPER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__upper-a-pillar-trim-assembly-overview) . Remove roof grab handle. See «ROOF GRAB HANDLE, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) Remove two bolts -6-. Remove upper D-pillar trim -1- from upper B-pillar trim. Remove roof end. See «ROOF END, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__roof-end-assembly-overview) . Unclip three clips -2- at lower D-pillar trim -1-. Remove upper D-pillar trim -1- from rear shelf. Remove D-pillar trim -1-. WARNING: Always follow installation sequence for D-pillar trim Installing NOTE: If the front and rear roof grab handles have been removed, make sure to use the roof grab handle with clothing hook when installing D-pillar trim. Guide D-pillar trim -1- first to the rear into rear shelf. Guide hook -7- into C-pillar trim slot. After installing, slide D-pillar trim -1- upward with front edge beneath B-pillar trim and move door seal cleanly over trim edges again. Ensure that adapter hook, side curtain airbag and clip engage properly. WARNING: Make sure trim has a proper fit.
  2. Clips (3x)
  3. Bolt (1x) belongs to upper A-pillar trim, holds trim for A-pillar and D-pillar together
  4. Lid for roof grab handle
  5. Roof grab handle
  6. Bolts (2x) Tightening torque 4 Nm. Self-locking Always replace Always clean threaded holes for bolts (e.g. using a thread cutter)
  7. Hook

Roof end, assembly overview

The following list pertains to see scheme 107.

  1. Roof end Removal Unclip four clips -2- on roof end -1-. Remove roof end -1-.
  2. Clips (4x)
  3. Mounts (4x)

Wheelhousing trim, assembly overview

The following list pertains to see scheme 108.

  1. Wheelhousing trim Removal Remove bottom B-pillar trim. See «LOWER B-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__lower-b-pillar-trim-assembly-overview) . Remove C-pillar trim. See «C-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__c-pillar-trim-assembly-overview) . Remove side panel. See «BACK SEAT SIDE BOLSTER, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-except-cabriolet__back-seat-side-bolster-assembly-overview) . Unclip three clips -2- from their mounts -3- and remove wheelhousing trim -1- Installing After assembling trim, make sure seal is properly installed
  2. Clips (3x)
  3. Mounts (3x)

Rear shelf, assembly overview

The following list pertains to see scheme 109.

  1. Rear shelf Removal Fold the rear backrest down. For non-foldable rear backrest: Remove rear backrest. See «FIXED REAR BACKREST, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-except-cabriolet__fixed-rear-backrest-removing-and-installing) . Remove C-pillar trim on right and left from rear shelf. See «C-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__c-pillar-trim-assembly-overview) . Remove left and right rear side bolsters. See «BACK SEAT SIDE BOLSTER, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-except-cabriolet__back-seat-side-bolster-assembly-overview) . For fixed backrest: Release third belt at bottom and wind it through. NOTE: In the following, removal is described in three variations, depending upon whether a rear shelf without installed components, with speaker or with speaker and sun shade should be removed. The following steps beneath "All" are again valid for all three variations. Removal variation 1: Rear shelf without installed components Proceed with removal as described under "All". Removal variation 2: Rear shelf with integrated speaker Detach speaker grill -4- from rear shelf -1-. Remove four bolts -5- between speakers and rear shelf -1-. Removal variation 3: Rear shelf with integrated speakers and sun shade Detach speaker grill -3- from rear shelf -1-. Remove two bolts -5- at front corners of speakers and one bolt -5- from below. Remove three bolts of sun shade -4- in luggage compartment (from below), see «REMOVING BOLTS FOR ELECTRICAL SUN SHADE IN LUGGAGE COMPARTMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__removing-bolts-for-electrical-sun-shade) . Remove sun shade -4- forward and out. All Move rear shelf -1- forward in direction of arrow and disengage it from insertion edge -2-. Remove rear shelf -1- upward and forward.
  2. Rear shelf insertion edge
  3. Loudspeaker (grill)
  4. Sun shade
  5. Bolts between speaker and rear shelf Depending on version, 3 or 4 bolts in varying positions

Removing Bolts For Electrical Sun Shade In Luggage Compartment

  1. Remove bolts -1- (3x).
  2. Tightening torque: 4 Nm

Rear lid trim, assembly overview

The following list pertains to see scheme 111.

  1. Tailgate trim Remove lock cover. Remove the flocked screw -3- in handle. Remove warning triangle. Remove bolts -4- (2x). Remove bracket for warning triangle -5-. Vehicles with emergency release: Remove emergency release handle. See «REMOVING EMERGENCY RELEASE HANDLE»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__removing-emergency-release-handle) . Loosen ten clips -2- on tailgate trim and unclip them from below.
  2. Clips (10 x)
  3. Bolt (1x) in handle Tightening torque 2 Nm
  4. Bolts (2x) Tightening torque 2 Nm
  5. Warning triangle holder

Removing Emergency Release Handle

  1. Remove cover -1-.
  2. Remove bolt -3-.
  3. Remove handle -2-.

Rear cross panel trim, assembly overview

The following list pertains to see scheme 113.

  1. Rear cross panel trim Removal Remove floor carpet from luggage compartment. Loosen two nuts -2- on rear cross panel trim -1- behind spare tire and remove nuts. Disconnect connectors for luggage compartment light. Unclip rear cross panel trim -1- upward from four metal clips -3-. Installing after assembling trim, make sure seal is properly installed Reinsert connector for light.
  2. Nuts (2x) Tightening torque 5 Nm
  3. Metal clips (4x)

Luggage compartment side trim, assembly overview

  1. Luggage compartment trim Removal Remove luggage compartment floor mat. See «LUGGAGE COMPARTMENT FLOOR MAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__luggage-compartment-floor-mat-assembly-overview) . Remove rear cross panel trim. See «REAR CROSS PANEL TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__rear-cross-panel-trim-assembly-overview) . Remove rear backrest. See «FIXED REAR BACKREST, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-except-cabriolet__fixed-rear-backrest-removing-and-installing) . Position the tie-downs -5- upward (1x or 2x depending on version). Remove the two phillips-head screws -6- in tie-downs. Unclip clip -3-. Disengage clip -3- from tab. Disengage three clips -4-. If necessary, remove cover -2-. Remove luggage compartment trim -1- upward. Installing After installation has been completed, pull tailgate rubber over trim -1-.
  2. Cover
  3. Clip
  4. Clips (3x)
  5. Tie-downs
  6. Bolts (2x) Tightening torque 4 Nm.

Sub compartment in luggage compartment, assembly overview

The following list pertains to see scheme 115.

  1. Sub compartment Removal Remove side trim luggage compartment on left side of vehicle. See «LUGGAGE COMPARTMENT SIDE TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__luggage-compartment-side-trim-assembly-overview) . Remove four bolts -2- on sub compartment -1-.
  2. Bolts (4x) Tightening torque 4 Nm.

Rear panel trim, assembly overview

The following list pertains to see scheme 116.

  1. Rear panel trim Removal If installed, remove ski sack. Remove luggage compartment floor mat. Remove clips -2- (5x in version with ski sack, 6x in version without ski sack).
  2. Clips (5x or 6x)
  3. Ski sack (optional)

Rear panel sill, assembly overview

The following list pertains to see scheme 117.

  1. Rear panel sill Removal Remove rear panel trim. See «REAR PANEL TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__rear-panel-trim-assembly-overview) . Remove four bolts -2-. Remove rear panel sill -1- upward. Installing Check whether the four expanding nuts -3- are seated properly and replace them if necessary. Position rear panel sill with four holes on expanding nuts -3-. Thread in four bolts -2- through holes into expanding nuts -3-.
  2. Bolts (4x) Tightening torque 3 Nm.
  3. Expanding nuts (4x)

Dirt tray, assembly overview

The following list pertains to see scheme 118.

  1. Dirt tray (optional) Removal Release dirt tray -1- from lock -4-. Unclip two clips -2- between dirt tray -1- and rear panel sill -3-. Remove dirt tray -1- upward.
  2. Clips (2x)
  3. Rear panel sill
  4. Dirt tray lock Removal Remove bolt -5- on dirt tray handle -6-. Remove securing clip -7- of handle. Remove handle -6-. Remove two expanding nuts -9-. Unclip four clips -8-. Remove dirt tray lock -4-.
  5. Bolt
  6. Handle
  7. Handle securing clip
  8. Clips (4x)
  9. Expanding nuts (2x)

Luggage compartment floor mat, assembly overview

The following list pertains to see scheme 119.

  1. Luggage compartment floor mat Removal For vehicles with dirt tray: Remove dirt tray. See «DIRT TRAY, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__dirt-tray-assembly-overview) . Lift up handle -5- on holder -2-. Remove holder -2- at handle -5- upward from mount -6-. For vehicles with dirt tray: Lift up luggage compartment floor mat from the rear and remove it from rear panel sill -4- at holes -3-. Raise luggage compartment floor mat -1- in direction of arrow and remove it from vehicle.
  2. Holder for luggage compartment floor mat
  3. Holes for dirt tray (optional)
  4. Rear panel sill (optional)
  5. Handle on holder for luggage compartment floor mat
  6. Mount for holder for luggage compartment floor mat

Floor mat, assembly overview

The following list pertains to see scheme 120.

  1. Floor mat Removal Remove right and left front seats. See «FRONT SEATS»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-except-cabriolet) . Remove rear seat. See «REAR SEATS»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-except-cabriolet) . Remove lower A-pillar trim on right and left. See «LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__lower-a-pillar-trim-assembly-overview) . Remove lower B-pillar trim on right and left. See «LOWER B-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__lower-b-pillar-trim-assembly-overview) . Remove driver-side foot rest. See «FOOT REST AND FOOT REST BRACKET, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . Remove center console. See «BRAKE FOR GLOVE COMPARTMENT COVER, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet) . Remove wiring harness beneath center console. Remove buffer pad -4- beneath center console and remove screw -5-. Remove wiring harness from vehicle. Remove air guides at center console. Remove bolt -3- on front of carpet tab in footwell. Fold floor mat together along its length and remove it from the vehicle. Installing NOTE: Floor mat rips easily at cut-outs. Install floor mat carefully into vehicle. Fold floor mat together along its length and place it in the vehicle. Before installing a new floor mat -1-, remove transport web -2-. Install floor mat in reverse order of removal.
  2. Transport web
  3. Bolt
  4. Buffer pad
  5. Bolt
WARNINGObserve safety precautions for working on side curtain airbags, see appropriate Air Bag Restraint Systems article.

Note. Always replace self-locking bolts.

The following list pertains to see scheme 121.

  1. C-pillar trim Removal Remove rear seat side panel. See «BACK SEAT SIDE BOLSTER, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-except-cabriolet__back-seat-side-bolster-assembly-overview) . Remove rear side-airbag. See appropriate articled in Restraints . Remove side trim luggage compartment. See «SIDE LUGGAGE COMPARTMENT TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__side-luggage-compartment-trim-assembly-overview) . Remove cover above rear doors. See «TRIM ABOVE REAR DOOR, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__trim-above-rear-door-assembly-overview) . Remove rear belt guide. Remove bolts for side curtain airbag in rear portion. See appropriate Air Bag Restraint Systems article. Remove bolts -3-. Remove trim -1- by unclipping spring clips -2-. Installing Installation is reverse of removal, noting the following. Secure side curtain airbag with new bolts. See appropriate Air Bag Restraint Systems article. Sealing rubber in rear side door must be laid over C-pillar trim. WARNING: Make sure trim has a proper fit.
  2. Spring clamp
  3. Bolts (2x) Tightening torque: 3.5 Nm

Trim above rear door, assembly overview

WARNINGObserve safety precautions for working on side curtain airbags, see appropriate Air Bag Restraint Systems article.

Note. Always replace self-locking bolts.

The following list pertains to see scheme 122.

  1. Bolt Tightening torque: 3.5 Nm
  2. Cover Removal Remove upper A-pillar trim. See «UPPER A-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__upper-a-pillar-trim-assembly-overview) . Remove D-pillar trim, see «D-PILLAR TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__d-pillar-trim-assembly-overview) . Fold down roof grab handle -4-. Open cover -5- over bolts and remove bolts -3-. Remove bolt -1-. Remove bolt -7- by sliding covering plate in eyelets to the rear. See «PRESSING COVERING PLATE IN EYELET PARTITION GRILL»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__pressing-covering-plate-in-eyelet-partition) . Remove cover -2- by unclipping spring clips -6-. Installing Installation is reverse of removal, noting the following. Sealing rubber in rear side door must be laid over C-pillar trim. NOTE: If the front and rear roof grab handles have been removed, make sure that the roof grab handle with clothing hook in rear is installed. WARNING: Make sure trim has a proper fit.
  3. Bolts (2x) Tightening torque: 3.5 Nm
  4. Roof grab handle
  5. Cover for bolts
  6. Spring clamp
  7. Bolt Tightening torque: 9 Nm. To loosen and tighten, push covering plate in eyelets to the rear. See «PRESSING COVERING PLATE IN EYELET PARTITION GRILL»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__pressing-covering-plate-in-eyelet-partition)

Pressing Covering Plate In Eyelet Partition Grill

  1. Press covering plate -1- in eyelet partition grill -2- to the rear and remove the bolt lying behind it.
WARNINGObserve safety precautions for working on side curtain airbags, see appropriate Air Bag Restraint Systems article.

Note. Always replace self-locking bolts.

The following list pertains to see scheme 124.

  1. D-pillar trim Removal Remove roof end trim. See «ROOF END TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__roof-end-trim-assembly-overview) . Remove bolt -3- by sliding covering plate in eyelets to the rear. See «PRESSING COVERING PLATE IN EYELET PARTITION GRILL»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__pressing-covering-plate-in-eyelet-partition) . Release only the rear edge of luggage compartment side trim. See «SIDE LUGGAGE COMPARTMENT TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__side-luggage-compartment-trim-assembly-overview) . Unclip D-pillar trim-1- from top downward. Remove D-pillar trim upward out of side luggage compartment trim. Remove D-pillar trim to the rear from trim -4- above rear door. Remove bolts for side curtain airbag in rear portion. See appropriate Air Bag Restraint Systems article. Remove bolts -6-. Remove trim -5- above rear side window. Installing Installation is reverse of removal, noting the following. Secure side curtain airbag with new bolts, see appropriate Air Bag Restraint Systems article. Slide D-pillar trim into mount for cover -4- above rear doors. Insert D-pillar trim behind luggage compartment trim and to the side. Insert trim -1- into mounts using clips -2- Tailgate rubber must be laid over D-pillar trim. WARNING: Make sure trim has a proper fit.
  2. Spring clamp
  3. Bolt Tightening torque: 9 Nm. To loosen and tighten, push covering plate in eyelets to the rear. See «RELEASING ATTACHMENT EYELET FOR PARTITION GRILL»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__releasing-attachment-eyelet-for-partition-grill) .
  4. Cover above rear door
  5. Cover above rear side window
  6. Bolts (2x) Tightening torque: 3.5 Nm

Releasing Attachment Eyelet For Partition Grill

  1. Press covering plate -1- in eyelet partition grill -2- to the rear and remove the bolt lying behind it.

Roof end trim, assembly overview

The following list pertains to see scheme 126.

  1. Roof end trim Removal Unclip four clips -2- on vehicle frame. Remove roof end trim -1-. Installing Tailgate rubber must be laid over roof end trim. WARNING: Make sure trim has a proper fit.
  2. Spring clips (4x)

Part 1

The following list pertains to see scheme 127.

  1. Luggage compartment light Removing and Installing See «CARGO AREA LIGHT (AVANT), REMOVING AND INSTAL»(/audi/a4/b6-2000-2006/remont/communication-devices/#lights-switches-interior-anti-theft-except-cabriolet) or «TAILGATE LIGHT (AVANT), REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/communication-devices/#lights-switches-interior-anti-theft-except-cabriolet__tailgate-light-avant-removing-and-installing) .
  2. Bolts (4x) Tightening torque: 1.5 Nm
  3. Lower tailgate trim Removal Open lid for warning triangle and remove warning triangle. Remove bolts -2- (4x). Disengage locking mechanism on left and right at top of trim using special tool 3370. See «DISENGAGING LOWER TRIM FROM LOCKING MECHANISM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__disengaging-lower-trim-from-locking-mechanism) . Carefully remove spring clips -4- for lower trim on left and right from rear lid. Reach between trim and rear lid and disengage four more spring clips -4-. Remove trim. Installing Make sure that the trim engages into plate on lid lock. WARNING: Make sure trim has a proper fit.
  4. Spring clips (6x)

Disengaging lower trim from locking mechanism

  1. Disengage locking mechanism on left and right at top of trim using special tool 3370 -arrows-.

Part 2

The following list pertains to see scheme 129.

  1. Bolts (2x) Tightening torque: 1.5 Nm
  2. Upper tailgate trim Removal Remove lower tailgate trim. See «REAR LID TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . Remove bolts -1- (2x). Press off spring clips on side edges of trim from rear lid (4x). Remove spring clips -3- on upper trim from rear lid (4x). Installing Before installing upper lid trim -2-, make sure rubber buffers -4- (8x) are installed. Guide upper lid trim first behind side window frame of rear lid. Clip in trim first at top and then on sides.
  3. Spring clips (8x)
  4. Rubber buffers (8x)

Side luggage compartment trim, assembly overview

The following list pertains to see scheme 130.

  1. Spring clamp
  2. Luggage compartment trim Removal Remove rear seat side panel. See «BACK SEAT SIDE BOLSTER, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-except-cabriolet__back-seat-side-bolster-assembly-overview) . See appropriate article in Restraints . Disengage luggage compartment floor at dirt tray and remove. Remove rear cross panel trim. See «REAR CROSS PANEL TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . Remove bolts -4- (4x) for tie-downs -5-. Remove bolt -3- (1x). Unclip trim - spring clips -1- (4x). Disconnect electrical harness connector for rear power outlet (right trim). Installing Installation is reverse of removal, noting the following. Tailgate rubber must be laid over lid end trim. WARNING: Make sure trim has a proper fit.
  3. Bolt Tightening torque 1.8 Nm.
  4. Bolts (4x) Tightening torque 4 Nm.
  5. Tie-downs

The following list pertains to see scheme 131.

  1. Sub compartment Removal Remove side trim luggage compartment on left side of vehicle. See «SIDE LUGGAGE COMPARTMENT TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__side-luggage-compartment-trim-assembly-overview) . Remove four bolts -2- on sub compartment -1-.
  2. Nuts (2x) Tightening torque 5 Nm
  3. Nut Tightening torque 3 Nm.

Rear power outlet, removing and installing

Special Tools and Equipment

  1. Special hook for front end 3370
  1. Carefully remove rear power outlet -1- from side luggage compartment trim using special tool 3370.

Note. Observe catches -2- and -4- when removing.

  1. Disconnect electrical harness connector -3-.
  1. Installation is reverse of removal.

Partition grill, assembly overview

The following list pertains to see scheme 134.

  1. Partition grill Removal Fold both rear backrests forward. Press partition grill -1- from 1/3 rear backrest in direction toward 2/3 rear backrest -4-. Remove partition grill. Installing Guide holding bracket -2- into recess on 2/3 backrest. Press partition grill -1- in direction of 1/3 backrest, so that the 2/3 backrest lifts up slightly.
  2. Holding bracket
  3. Bracket
  4. 2/3 rear backrest

The following list pertains to see scheme 135.

  1. Bolts (4x) Tightening torque 5 Nm
  2. Rear cross panel trim Removal Open lid for storage area floor. Remove bolts -1- (4x). Carefully remove rear cross panel trim -2- from locking pins -arrows-. Installing Tailgate rubber must lie over rear cross panel trim. Tighten bolts to 5 Nm.

Storage area floor, assembly overview

The following list pertains to see scheme 136.

  1. Storage area floor Removal Fold back rear part of storage area floor. Detach storage area floor from mounts -2- at dirt tray.
  2. Mount on dirt tray (2x)

The following list pertains to see scheme 137.

  1. Threaded bolts tighten hand tight
  2. Cover for tool compartment
  3. Dirt tray
  1. Removal Remove storage area floor. See «STORAGE AREA FLOOR, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__storage-area-floor-assembly-overview) . Remove rear cross panel trim. See «REAR CROSS PANEL TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet) . Remove right and left side trim in luggage compartment. See «SIDE LUGGAGE COMPARTMENT TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#interior-trim-except-cabriolet__side-luggage-compartment-trim-assembly-overview) . Remove dirt tray.

Console tie-downs, assembly overview

The following list pertains to see scheme 138.

  1. Bolts (2x) Tightening torque 4 Nm.
  2. Console tie-downs Remove bolts -4- (4x). Remove tie-downs -3-. Remove luggage compartment floor mat -3-. Remove bolts -1- (2x).
  3. Tie-downs
  4. Bolts (2x) Tightening torque 4 Nm.
  5. Luggage compartment floor mat

See also:
• INSTRUMENT CLUSTER, REMOVING AND INSTALLING
• GLOVE COMPARTMENT, REMOVING AND INSTALLING
• CENTER CONSOLE, ASSEMBLY OVERVIEW
• FRONT ASHTRAY, ASSEMBLY OVERVIEW
• DRIVER-SIDE STORAGE COMPARTMENT (WITH AND WITHOUT KNEE BOLSTER), ASSEMBLY OVERVIEW
• BATTERY DISCONNECT PRECAUTIONS
• TELEMATICS
• GLOVE COMPARTMENT, ASSEMBLY OVERVIEW
• GLOVE COMPARTMENT, REMOVING AND INSTALLING (VEHICLES WITH KNEE BOLSTER)
• CENTER PART OF INSTRUMENT PANEL, ASSEMBLY OVERVIEW
• REAR INTERIOR LIGHT/READING LIGHT, REMOVING AND INSTALLING
• LIGHT FOR MAKE-UP MIRROR, REMOVING AND INSTAL
• BACK SEAT SIDE BOLSTER, ASSEMBLY OVERVIEW
• FIXED REAR BACKREST, REMOVING AND INSTALLING
• FRONT SEATS
• BRAKE FOR GLOVE COMPARTMENT COVER, REMOVING AND INSTALLING
• TAILGATE LIGHT (AVANT), REMOVING AND INSTALLING
• FRONT DOOR TRIM COMPONENTS, ASSEMBLY OVERVIEW
• BASS SPEAKER, REMOVING AND INSTALLING
• TREBLE SPEAKER, REMOVING AND INSTALLING
• DOOR WARNING LIGHT AND FOOTWELL LIGHTING, REMOVING AND INSTALLING
• INTERIOR DOOR MECHANISM, REMOVING AND INSTALLING
• UNCLIPPING DOOR TRIM
• DISENGAGING BOWDEN CABLE
• DISCONNECTING ELECTRICAL HARNESS CONNECTORS
• MANUAL WINDOW CRANK, REMOVING AND INSTALLING
• POWER WINDOW SWITCH, REMOVING AND INSTALLING
• DISENGAGING BOWDEN CABLE
• ARMREST, ASSEMBLY OVERVIEW
• REAR DOOR TRIM, ASSEMBLY OVERVIEW
• DOOR WARNING LIGHT, REMOVING AND INSTALLING
• INTERIOR DOOR HANDLE, REMOVING
• INSTRUMENT PANEL, REMOVING AND INSTALLING
• LEFT AND RIGHT INSTRUMENT PANEL VENTS, REMOVING AND INSTALLING
• UPPER TRIM FOR STEERING COLUMN SWITCHES, REMOVING
• INSTRUMENT PANEL SPEAKER, REMOVING
• CENTER INSTRUMENT PANEL VENT, REMOVING AND INSTALLING
• RIGHT INSTRUMENT PANEL COVER, REMOVING
• RIGHT TRIM FOR INSTRUMENT PANEL, REMOVING AND INSTALLING
• LEFT TRIM FOR INSTRUMENT PANEL, REMOVING AND INSTALLING
• LIGHT SWITCH AND HEADLIGHT BEAM ADJUSTER, REMOVING
• LEFT INSTRUMENT PANEL COVER, REMOVING
• UPPER A-PILLAR TRIM, ASSEMBLY OVERVIEW
• UPPER B-PILLAR TRIM, ASSEMBLY OVERVIEW
• ROOF END, ASSEMBLY OVERVIEW
• D-PILLAR TRIM, ASSEMBLY OVERVIEW
• CABLE ROUTING ON BACK SIDE OF MOLDED HEADLINER
• TRIM ABOVE REAR DOOR, ASSEMBLY OVERVIEW
• SUN VISOR, ASSEMBLY OVERVIEW
• LOWER A-PILLAR TRIM, ASSEMBLY OVERVIEW
• INSTALLING UPPER B PILLAR TRIM IN BELT HEIGHT ADJUSTER
• LOWER B-PILLAR TRIM, ASSEMBLY OVERVIEW
• C-PILLAR TRIM, ASSEMBLY OVERVIEW
• REMOVING BOLTS FOR ELECTRICAL SUN SHADE IN LUGGAGE COMPARTMENT
• REMOVING EMERGENCY RELEASE HANDLE
• LUGGAGE COMPARTMENT FLOOR MAT, ASSEMBLY OVERVIEW
• REAR CROSS PANEL TRIM, ASSEMBLY OVERVIEW
• LUGGAGE COMPARTMENT SIDE TRIM, ASSEMBLY OVERVIEW
• REAR PANEL TRIM, ASSEMBLY OVERVIEW
• DIRT TRAY, ASSEMBLY OVERVIEW
• SIDE LUGGAGE COMPARTMENT TRIM, ASSEMBLY OVERVIEW
• PRESSING COVERING PLATE IN EYELET PARTITION GRILL
• ROOF END TRIM, ASSEMBLY OVERVIEW
• RELEASING ATTACHMENT EYELET FOR PARTITION GRILL
• DISENGAGING LOWER TRIM FROM LOCKING MECHANISM
• STORAGE AREA FLOOR, ASSEMBLY OVERVIEW

More articles — Accessories & Equipment
