General tightening torque
| CAUTION | Screws coated with a locking fluid or self locking nuts must be replaced with new when reinstalled. |
See the table below to find the tightening torques for components not included in the summary.
Nuts and screws which are not self locking can be reused provided that they are in good condition.
| Applies to screwed joint with strength class 8.8. | |
|---|---|
| Thread | Tightening torque (Nm) |
| M5 | 5 |
| M6 | 10 |
| M7 | 17 |
| M8 | 24 |
| M10 | 50 |
| M12 | 80 |
| M14 | 130 |
Summary of tightening torques for specific components
| CAUTION | Screws coated with locking fluid or sealant must be replaced with new when reinstalled. |
Always use new screws and nuts when angle tightening. Any exceptions to this rule will be indicated in the method.
Angle-tightening in tight spaces. See Screwed joint, torque/angle tightening .
| Bolt drive shaft - wheel hub, front | Stage 1: 35 Nm Stage 2: 90° |
|---|---|
| Bolt drive shaft - wheel hub, version with rubber cone | 50 Nm |
| Bolt drive shaft - wheel hub, rear | 50 Nm |
All drive shafts
| Sensors | 6 Nm |
|---|---|
| Filler plug, Level plug and Drain plug | 35 Nm |
All gearboxes, angle gears, chain angle gears and rear axle gears
| Cover, control system (AW) | Diagonally 14 Nm |
|---|---|
| The nut for the lever and gear shift linkage rod | 16 Nm |
| Side cover, gearbox (4T65) | Stage 1: Crosswise 10 Nm Stage 2: Crosswise 25 Nm |
| Bolt driver plate - torque converter 6 x bolts | 35 Nm |
| Screws for the lower torque rod in the transmission NOTE: Applies to 5-cylinder engines only | Stage 1: 35 Nm Stage 2: 40° |
| Connection, oil cooler pipe to gearbox | 30 Nm |
| Screw, oil pipe - transmission | 6 Nm |
| Screw, oil pipe - dipstick pipe - transmission | 15 Nm |
| Dipstick pipe for the transmission | 24 Nm |
| NOTE |
|---|
| Applies to 5-cylinder engines only |
AW, 4T65
| Integrated level plug/Torx | 8 Nm |
|---|---|
| Cover, control system | Diagonally 14 Nm |
| Torque converter to carrier plate 6 screws | 60 Nm |
| Gear selector mechanism (nut) | 16 Nm |
TF-80SC
| Back-up (reversing) lamps switch | 24 Nm |
|---|---|
| Flywheel | Stage 1:45 Nm Stage 2:65° |
M56, M58, M66
| Bevel gear to transmission | 75 Nm |
|---|---|
| Universal joint (spider) fastened with 4 bolts | Stage 1: Crosswise 16 Nm Stage 2: Crosswise 120° |
| Universal joint CV fastened with 6 bolts | Stage 1: Crosswise 10 Nm Crosswise 25 Nm |
| Pinion nut (Active on Demand Coupling) | 150 Nm |
| Pinion nut, angle gear | 180 Nm |
| Oil pump (AOC) | 5 Nm |
| Control module (AOC) | 5 Nm |
| Driveshaft (center bearing) | 30 Nm |
| Oil plug, final drive | 35 Nm |
| Oil plug, Active On-Demand Coupling | 35 Nm |
| Bevel gear bracket | Stage 1: alternately to light contact Stage 2: 50 Nm |
| Manifold support bracket bevel gear | Stage 1: 35 Nm Stage 2: 90° |
AWD
Screwed joint, torque/angle tightening
There are a great number of torque spanner systems available on the market where the spanner grip can be replaced with other types. These wench grips are normally ideally suited to torque tightening screwed joints in poorly accessible places.
There may be occasions when torque tightening of a screwed joint must be followed by angle tightening and space does not allow the use of protractor (part number 9512050 ). In these cases, use either a nut, a screw head or a tool. These are usually hexagonal and each corner is 60° . If there are twelve edges, each corner is 30° .
Scheme 1204
To angle tighten, mark the material and nut for example as illustrated and then tighten so that the markings are opposite each other.
| Type | AW50/51AWD | TF-80SCAWD |
|---|---|---|
| 1st gear ratio | 4,769 | 4,148 |
| 2nd gear ratio | 2,995 | 2,370 |
| 3rd gear ratio | 1,957 | 1,556 |
| 4th gear ratio | 1,324 | 1,155 |
| 5th gear ratio | 1,018 | 0,859 |
| 6th gear ratio | 0,686 | |
| R | 3,234 | 3,394 |
| Maximum torque | Approx. 350 Nm | Approx. 400 Nm (petrol engines) |
| Approx. 450 Nm (diesel engines) | ||
| Weight | 87 kg | 95 kg |
| Oil volume | 7.1 litres | 6.7 litres |
Tightening Torque
See Tightening torque
