Component Resistance Values
The resistance values assume a temperature of +20°C unless otherwise stated.
| Component | Remarks | Resistance (ohms) |
|---|---|---|
| Shift solenoid S1 | Resistance between the solenoid pin and the solenoid sleeve or transmission housing | 12-16 |
| Shift solenoid S2 | Resistance between the solenoid pin and the solenoid sleeve or transmission housing | 11-15 |
| Shift solenoid S3 | Resistance between the solenoid pin and the solenoid sleeve or transmission housing | 11-15 |
| Shift solenoid S4 | Resistance between the solenoid pin and the solenoid sleeve or transmission housing | 11-15 |
| Shift solenoid S5 | Resistance between the solenoid pin and the solenoid sleeve or transmission housing | 11-15 |
| Lock-up solenoid SLU | Resistance between the solenoid pins | 5.0-5.6 |
| Throttle solenoid SLT | Resistance between the solenoid pins | 5.0-5.6 |
| Throttle solenoid SLS | Resistance between the solenoid pins | 5.0-5.6 |
| Oil temperature sensor, temperature (°C) | 0 | |
| 20 | 5800-7900 | |
| 40 | ||
| 80 | ||
| 100 | 261-263 | |
| 150 |
Scheme 571
Control module terminals #A1-#A60 correspond to terminals #A1-#A60 on the breakout box, terminals #A61-#A70 correspond to terminals #B1-#B10 on the breakout box.
| Terminal | Signal | Connected to control module terminal # |
|---|---|---|
| A1 | Signal ground, transmission input speed sensor (SP2) | A41 |
| A2 | Power supply, engine speed (RPM) sensor (SP2) | A59 |
| A3 | Signal ground, transmission output speed sensor (SP1) | A39 |
| A4 | Power supply, speed sensor (SP1) | A57 |
Scheme 572
Control module terminals #A1-#A60 correspond to terminals #A1-#A60 on the breakout box, terminals #A61-#A70 correspond to terminals #B1-#B10 on the breakout box.
| Terminal | Signal | Connected to control module terminal # |
|---|---|---|
| B1 | Shift lock solenoid, replacement | |
| B2 | Shift lock solenoid, replacement | |
| B4 | Ground terminal, gear-shift position sensor | |
| B5 | Gear-shift position sensor, signal A | A46 |
| B6 | Gear-shift position sensor, signal B | A64 |
| B7 | Gear-shift position sensor, signal C | A45 |
| B8 | Gear-shift position sensor, signal PA | A63 |
Scheme 573
Control module terminals #A1-#A60 correspond to terminals #A1-#A60 on the breakout box, terminals #A61-#A70 correspond to terminals #B1-#B10 on the breakout box.
| Terminal | Signal | Connected to control module terminal # |
|---|---|---|
| C1 | S1 | A50 |
| C2 | S2 | A68 |
| C3 | S3 | A48 |
| C4 | S4 | A47 |
| C5 | S5 | A66 |
| C6 |
Scheme 574
Control module terminals #A1-#A60 correspond to terminals #A1-#A60 on the breakout box, terminals #A61-#A70 correspond to terminals #B1-#B10 on the breakout box.
| Terminal | Signal | Connected to control module terminal # |
|---|---|---|
| D1 | Control signal, Lock-up solenoid SLU | A51 |
| D2 | Signal ground, Lock-up solenoid SLUG | A69 |
| D3 | Control signal, line pressure solenoid SLT | A52 |
| D4 | Signal ground, line pressure solenoid SLTG | A70 |
| D5 | Control signal, line pressure solenoid SLS | A49 |
| D6 | Signal ground, line pressure solenoid SLSG | A67 |
| D7 | Power supply, oil temperature sensor OT | A37 |
| D8 | Signal ground, oil temperature sensor OTG | A55 |
See Component resistance values
Connector A, Transmission
See Connector A, transmission
Connector B, Transmission
See Connector B, transmission
Connector C, Transmission
See Connector C, transmission
Connector D, Transmission
See Connector D, transmission
Gear Shift Solenoids
| Component | Remarks | Resistance (ohms) |
|---|---|---|
| Shift solenoids S1, S2, S3, S4 and S5 | Resistance between the solenoid pin and the solenoid sleeve or transmission housing | +20 °C= 11-16 ohms |
For other values, see diagram. When taking readings at temperatures other than +20 °C, a control reading must be taken at +20 °C. This is done to check whether the resistance is correct or not.
Linear Pressure Solenoid SLT, SLS/Lock-Up Solenoid SLU
| Component | Remarks | Resistance (ohms) |
|---|---|---|
| Lock-up solenoid (SLU) Linear pressure solenoid (SLT) (SLS) | Resistance between the solenoid pins | +20 °C= 5.0-5.6 ohms |
For other values, see diagram. When taking readings at temperatures other than +20 °C, a control reading must be taken at +20 °C. This is done to check whether the resistance is correct or not.
Oil Temperature Sensor
| Component | Remarks | Resistance (ohms) |
|---|---|---|
| Oil temperature sensor | Resistance between the terminals on the temperature sensor | +10 °C= 5800-7090 ohms |
| +110 °C= 231-263 ohms |
The resistance decreases with increasing temperature.
The control reading should be taken at both temperatures to check whether the resistance is correct or not.
Scheme 575
| Component | Remarks | Resistance (ohms) |
|---|---|---|
| Solenoid Park / neutral position (PNP) switch | Resistance between the solenoid terminals | +20 °C= 24.5 - 29.3 ohms |
