Transmission - General Diagnostics and Tests: Overview Volvo S60 I

Automatic Trans 4 illustrations ~106 words

Scheme 315

Scheme 315: Checking the ground terminals
Scheme 315: Checking the ground terminals

Scheme 316

Scheme 316
Scheme 316

Scheme 317

Scheme 317
Scheme 317

Scheme 318

Scheme 318
Scheme 318
  1. Ignition off
  2. Transmission control module (TCM) disconnected.
  3. Turn of all equipment in the car that takes power from the battery (the interior lighting and radio etc). Connect an ohmmeter between the battery negative terminal and: terminal #A53 (#A53) on the breakout box. Other information: To connect the breakout box, see «Connecting to the breakout box»(ref-415231-S13401600552011081500000).

The ohmmeter should read approximately 0 ohms.

  1. OK Refer to «Checking the power supply to the control module»(ref-415256-S15209921122011081500000)
  2. NOT OK Refer to «Checking for open-circuits, contact resistance and oxidation»(ref-415256-S04041756782011081500000)
