Timing Case Opel Corsa B

Timing Case

The following components are attached to the timing case of the X 10 XE engine:

• Front view
• Rear view (inside, lower part)

• Camshaft sensor
• Coolant pump with integrated temperature sensor and thermostat housing
• TDC point mark (1st cylinder)
• Oil pump
• Oil pressure regulating valve
• Service aperture for chain tensioner

The individual components are described in detail in the following sections.

5.2.2 Timing Case

Timing Chain

The two camshafts are driven by a simplex timing chain powered by the crankshaft. The correct chain tension is provided by a spring-assisted, hydraulic, maintenance-free chain tensioner. The timing chain is guided by a tension rail and an additional guide rail. A sliding rail guides the chain between the camshaft sprockets. With the exception of the upper section (camshaft sprockets), the chain drive is accommodated completely in the timing case.

Legend for illus. G 3101:

• Timing chain
• Guide rail
• Sprocket
• Tension rail
• Chain tensioner
• Sliding rail

5.2.3 Timing Chain

Chain Tensioner

The spring-assisted, hydraulic chain tensioner is positioned under the timing case, bolted to the cylinder head. It is accessible by removing the cylinder head or the timing case.

5.2.4 Chain Tensioner I Service Aperture in Timing Case for Chain Tensioner Ii Chain Tensioner After Removal of the Timing Case
