Replace Particle Filter Temperature Sensor Opel Astra H

Remove

1. 1. Raise vehicle by its full height
2. 2. Detach the lower engine cover and right engine splash guard
3. 3. Unplug wiring harness plug of particle filter temperature sensor (1) • Unclip wiring harness from bracket

4. 4. Unclip 7x wiring harness • From rear engine damping block • From front axle body • 5x from underbody
5. 5. Remove particle filter temperature sensor (1) • Unscrew temperature sensor

Install

6. 6. Install particle filter temperature sensor • Fasten temperature sensor 30 Nm
7. 7. 7x clip in wiring harnesses • 5x at underbody • At front axle body • To engine damping block (rear)
8. 8. Connect wiring harness plug of particle filter temperature sensor • Clip wiring harness into bracket
9. 9. Install lower engine cover and right engine splash guard
10. 10. Lower vehicle by its full height
