Important: When working on the fuel system it is essential to pay attention to cleanliness as even the smallest dirt particles can lead to faults in engine operation or in the fuel system. Open fuel connections must be sealed with appropriate plugs from the Opel Parts Catalogue (catalogue number: 45 06 154 / part number: 9201697). Sealing plugs are only intended to be used once.
Remove
- 1. Open bonnet
- 2. Disconnect battery • Detach ground connection from ground terminal – Slacken nut
- 3. Remove engine cover
- 4. Remove rail pressure sensor (1) from accumulator • Disconnect wiring harness connector. • Unscrew rail pressure sensor
Install
- 5. Install rail pressure sensor in accumulator • Tighten rail pressure sensor 70 Nm • Fix wiring harness plug
- 6. Connect battery • Attach ground connection to ground terminal – Tighten nut
- 7. Fuel System, Check for Leaks • Start engine.
Important. Wear protective goggles and protective gloves.
Note. Check fuel system for escaping fuel.
- 8. Install engine cover
- 9. Program volatile memories
- 10. Programming the pressure storage sensor with Tech 2
- 11. Close bonnet
