How to Replace the Metering Unit Opel Astra H

Important: For the entire operation, it is essential to work in a clean environment.

• Dirt in the area of the metering unit must be avoided.
• Do not wear gloves.
• Do not fit any metering unit that has been dropped.
• Disconnect battery after fault tracing. Before using the metering unit, wait a few minutes to avoid the system working autonomously.

Remove

1. 1. Open bonnet
2. 2. Disconnect battery • Detach earth cable – Slacken nut
3. 3. Raise vehicle by its full height
4. 4. Unclip wiring harness (3) from bracket
5. 5. Separate wiring harness plug for metering unit • Unclip wiring harness plug (4)
6. 6. Remove metering unit (2) • Unscrew 2x bolts (1)
7. 7. Remove metering unit
8. 8. Remove seal ring • Remove seal ring (1) from high pressure pump

9. 9. Clean sealing surface
10. 10. Check 2x fuel supply bores (arrow) for dirt

Install

11. 11. Insert new seal ring • Coat new seal ring (1) with engine oil and fit in high pressure pump – Ensure correct fitting

12. 12. Metering Unit, insert • Apply new engine oil to the O-ring (1) of the metering unit

13. 13. Fit metering unit • Ensure correct fitting • Tighten 2x bolt 10 Nm
14. 14. Connect wiring harness plug for metering unit
15. 15. Clip wiring harness into bracket
16. 16. Lower vehicle by its full height
17. 17. Connect battery • Attach negative connection to ground terminal – Tighten nut
18. 18. Programme transient memory
19. 19. Reset learned values of high pressure pump with Tech 2 • Programming • Confirm "Replace pump" with "Yes"
20. 20. Carry out seal test on metering unit • Actuator test • Carry out fuel leak test
21. 21. Visual inspection • Check metering unit for fuel leak
22. 22. Close bonnet
