Replace Atmospheric Pressure Sensor Opel Astra H

1. 1. Open bonnet
2. 2. Raise vehicle by its full height
3. 3. Detach charge air pipe (2) • Undo 2x clamps (1) • Remove charge air pipe

4. 4. Detach wiring harness plug from engine control unit • Release 2x wiring harness plugs (1) and disconnect

5. 5. Remove atmospheric pressure sensor (2) • Disconnect wiring harness connector (3) • Unscrew bolt (1)

Install

6. 6. Install atmospheric pressure sensor • Tighten bolt • Fix wiring harness plug
7. 7. Connect 2x wiring harness plugs to engine control unit
8. 8. Install charge air hose with charge air pipe • Attach 2x clamps
9. 9. Close bonnet
