Engine Performance Diagnostic Trouble Code (DTC) Diagnostics - 5 of 7 (Coupe): Other Volvo C70 I

Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

Checking fuel injection system, ignition system and components

The diagnostic trouble code (DTC) indicates which cylinder has misfired.

Check that engine oil level is correct.

Check the spark plugs, search for damage in the insulation and other damage.

Check ignition spark.

Check fuel pressure and residual pressure according to Checking fuel and residual pressures .

Check that the engine is airtight according to Compression test .

Check for air leakage according to Check for air leaks in the intake system .

Check flywheel for damage.

Other information

1. information about the misfire diagnostic, see «Misfire diagnostic»(ref-438954-S01093400202011120700000) .

Scheme 973

1. Continue Refer to «Verification»(ref-408511-S12288002492011071200000)

Verification

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 974

Scheme 975

Scheme 976

1. Ignition off.
2. Reinstall connectors, components etc.
3. Start the engine. Check that the misfire counter counts upwards and that the engine is firing on all cylinders. Also check that the misfire diagnostic system is active. If not check the conditions according to «Misfire diagnostic»(ref-438954-S01093400202011120700000) .

Does the misfiring counter count upwards?

1. YES Refer to «Information»(ref-408511-S07091920692011071200000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

The diagnostic trouble code (DTC) indicates which cylinder has misfired.

Check that engine oil level is correct.

Check the spark plugs, search for damage in the insulation and other damage.

Check ignition spark.

Check fuel pressure and residual pressure according to Checking fuel and residual pressures .

Check that the engine is airtight according to Compression test .

Check for air leakage according to Check for air leaks in the intake system .

Check flywheel for damage.

Other information

1. information about the misfire diagnostic, see «Misfire diagnostic»(ref-438954-S01093400202011120700000) .

1. Continue Refer to «Verification»(ref-408511-S08978280862011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Start the engine. Check that the misfire counter counts upwards and that the engine is firing on all cylinders. Also check that the misfire diagnostic system is active. If not check the conditions according to «Misfire diagnostic»(ref-438954-S01093400202011120700000) .

Does the misfiring counter count upwards?

1. YES Refer to «Information»(ref-408511-S36458247382011071200000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

Checking cables and connectors

Check canister purge (CP) valve connector for contact resistance and oxidation according to Contact resistance and oxidation and loose connections according to Loose connections (terminals)

Check signal cable between control module #A9 (#A9) and canister purge (CP) valve terminal 2 and power supply between system relay terminal 3 and canister purge (CP) valve terminal 1 for an intermittent open-circuit according to Open-circuit, intermittent faults .

Other information

1. Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
2. To access/replace the canister purge (CP) valve, see «Replacing the canister purge (CP) valve»(ref-408434-S03062196182011071200000) .
3. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

Scheme 977

Scheme 978

1. Continue Refer to «Information»(ref-408511-S34060326762011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal missing. Intermittent fault

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reconnect connectors, reinstall components
3. Ignition on.
4. Activate canister purge (CP) valve. A "click" should be heard when the canister purge (CP) valve is activated.

Is the canister purge (CP) valve working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S14247027182011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal missing. Permanent fault

See Signal missing. Permanent fault

See Signal missing. Permanent fault

Checking cables

Check signal cable between control module #A9 (#A9) and canister purge (CP) valve terminal 2 for an intermittent short-circuit to supply voltage according to Short-circuit to supply voltage, intermittent faults .

Other information

1. Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
2. To access/replace the canister purge (CP) valve, see «Replacing the canister purge (CP) valve»(ref-408434-S03062196182011071200000) .
3. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

Scheme 979

1. Continue Refer to «Information»(ref-408511-S24339513492011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal too high. Intermittent fault

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reconnect connectors, reinstall components
3. Ignition on.
4. Activate canister purge (CP) valve. A "click" should be heard when the canister purge (CP) valve is activated.

Is the canister purge (CP) valve working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S42527711502011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal too high. Permanent fault

See Signal too high. Permanent fault

See Signal too high. Permanent fault

Check signal cable between control module #A9 (#A9) and canister purge (CP) valve terminal 2 for an intermittent short-circuit to ground according to Short-circuit to ground, intermittent faults .

Other information

1. Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
2. To access/replace the canister purge (CP) valve, see «Replacing the canister purge (CP) valve»(ref-408434-S03062196182011071200000) .
3. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

1. Continue Refer to «Information»(ref-408511-S00654597012011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal too low. Intermittent fault

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reconnect connectors, reinstall components
3. Ignition on.
4. Activate canister purge (CP) valve. A "click" should be heard when the canister purge (CP) valve is activated.

Is the canister purge (CP) valve working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S16071902042011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal too low. Permanent fault

See Signal too low. Permanent fault

See Signal too low. Permanent fault

Safety

First read Safety regulations for handling fuel .

1. Continue Refer to «Checking wiring and terminals»(ref-408511-S25616691642011071200000)

Checking the engine coolant temperature (ECT)

Note. The test cannot be started if the engine coolant temperature (ECT) is below 70°C.

1. Start the engine
2. Read off the engine coolant temperature (ECT). If the engine coolant temperature (ECT) is below 70°C, allow the engine to reach operating temperature or cancel the test.

Is the temperature above 70° C?

1. YES Refer to «Starting the test of the fuel tank system»(ref-408511-S35457841022011071200000)
2. NO FAULT TRACING FAILED

Checking for blockage between the fuel tank pressure sensor and the fuel tank

HINT: If "small leak" is detected after a completed quick test of the fuel tank system, it may in certain cases be due to a blockage between the fuel tank pressure sensor and the fuel tank.

HINT: The method below is used to determine whether the detection of "small leak" after completed quick tests is caused by a blockage between the fuel tank pressure sensor and the fuel tank. It can be carried out by running the test with the fuel tank filler cap removed. Normally a "large leak" is detected with the fuel tank filler cap removed. If a "small leak" is detected with the fuel tank filler cap removed it indicates a blockage between the fuel tank pressure sensor and fuel tank.

HINT

Note. If the EVAP canister fills with the fuel vapor the test is interrupted. The EVAP canister fills with fuel vapor faster if the evaporative emission system (EVAP) valve is operating and the fuel tank filler cap is removed. Start the quick test directly after engine start and do not let the engine run at idle speed for longer than necessary.

1. Remove the fuel tank filler cap
2. Engine idling
3. Start the quick test with the fuel tank filler cap removed. In particular check the fuel tank pressure (red line) when the "large leak" test is running. If a "large leak" is detected with the fuel tank filler cap removed, the most likely cause is leakage. Continue fault-tracing according to "small leak". If the test is cancelled or "small leak" is detected with the fuel tank filler cap removed and the fuel tank pressure (red line) falls more slowly than normal during the test it may be due to a blockage in the hose or hose terminal between the tank and the fuel tank pressure sensor. This can be fault-traced by removing the hoses to the evaporative emission (EVAP) system components one at a time and carrying out a quick test between each operation. If a "large leak" is detected after the quick test when the hose has been disconnected the fault is in the direction of the airflow (calculated from the hose that has been disconnected). HINT: The direction of airflow during a quick test can be calculated from the fuel tank: fuel tank, evaporative emission system (EVAP) canister, evaporative emission system (EVAP) valve. The fuel tank pressure sensor measures the pressure in the hose between the fuel tank and the evaporative emission system (EVAP) canister. HINT: If the hose for the EVAP canister is detached from the fuel tank and a "large leak" is detected, there is a blockage in the tank hose terminal. Remedy as necessary. Reset all the components. Carry out a quick test of the tank system before the car is delivered to the customer. Select a suitable alternative to continue: Continue "small leak" fault-tracing Refer to «Small leak»(ref-408511-S15074939592011071200000) Finish. OKAY: Troubleshooting has been completed.

Scheme 980

1. Start the engine and let it run at idle speed.
2. Disconnect the hose between the canister purge (CP) valve and the EVAP canister from the canister purge (CP) valve.
3. Read off the canister purge (CP) valve. This is to check whether the valve is activated. Check that there is a vacuum in the canister purge (CP) valve when the valve is activated.

Is there a vacuum?

1. YES Refer to «Checking the vacuum at the EVAP canister»(ref-408511-S12774115882011071200000)
2. NO Refer to «Checking the canister purge (CP) valve vacuum»(ref-408511-S10940708042011071200000)

Scheme 981

1. Ignition off.
2. Reconnect the hose on the canister purge (CP) valve.
3. Disconnect the hose to the canister purge (CP) valve from the EVAP canister.
4. Start the engine and let it run at idle speed.
5. Read off the canister purge (CP) valve value. This is to determine whether the valve is activated or not. Check that there is a vacuum in the hose when the canister purge (CP) valve is activated.

Is there a vacuum?

1. YES Refer to «Checking the EVAP canister»(ref-408511-S28893962942011071200000)
2. NO Refer to «Checking the hose»(ref-408511-S10836782492011071200000)

Scheme 982

1. Connect the hose between the canister purge (CP) valve and the EVAP canister to the canister purge (CP) valve.
2. Start the engine and let it run at idle speed.
3. Disconnect the hose between the canister purge (CP) valve and the intake manifold from the canister purge (CP) valve. Check that there is a vacuum in the hose. Remedy as necessary.

Was a fault detected?

1. YES Refer to «Verification information»(ref-408511-S35471396972011071200000)
2. NO Refer to «Replacing the canister purge (CP) valve»(ref-408511-S33440152862011071200000)

Replacing the canister purge (CP) valve

Try a new canister purge (CP) valve according to Replacing the canister purge (CP) valve .

Continue when the fault has been remedied.

1. Continue Refer to «Verification information»(ref-408511-S35471396972011071200000)

Checking the EVAP canister

Check that all EVAP canister inlets and outlets are not sealed.

HINT: Connect a vacuum pump to the EVAP canister terminals, one at a time. Check that it is not possible to pump negative pressure.

Other information

1. To access / replace the EVAP canister, see «Replacing the carbon filter container»(ref-408433-S05140751832011071200000) .

Was a fault detected?

1. YES Refer to «Verification information»(ref-408511-S35471396972011071200000)
2. NO Refer to «Checking the hose between the fuel tank and the EVAP canister»(ref-408511-S16201431362011071200000)

Checking the hose

Check if the hose between the canister purge (CP) valve and the EVAP canister is blocked or trapped.

Continue when the fault has been remedied.

1. Continue Refer to «Verification information»(ref-408511-S35471396972011071200000)

Checking the hose between the fuel tank and the EVAP canister

Check that the hose between the fuel tank and EVAP canister is airtight and is not trapped.

Remedy as necessary.

Was a fault detected?

1. YES Refer to «Verification information»(ref-408511-S35471396972011071200000)
2. NO Refer to «Test pressurization of the fuel tank system»(ref-408511-S08799308192011071200000)

Scheme 983

Scheme 984

Scheme 985

1. Max 50 liters of fuel in the fuel tank.
2. Ignition off.
3. Connect the hose from the fuel tank to the EVAP canister.
4. Clamp the hose between the EVAP canister shut-off valve and the EVAP canister with a hose clip to seal it.
5. Carefully disconnect the EVAP canister hose from the canister purge (CP) valve. Connect manometer «9995646»(ref-403953-S17881977312011061000000) to the hose and the pressure regulator «9995544»(ref-403953-S05241159092011061000000) to the manometer. Set the pressure to 7 kPa (read off on manometer «9995646»(ref-403953-S17881977312011061000000) ). The cock must be at right angles to the hoses. WARNING: Max 10 kPa. Let the pressure build up for 5 minutes. Close the cock (the pressure may now drop by 1-2kPa before it stabilizes). Read off the pressure. Turn the cock towards the EVAP canister hose. Wait for 10 minutes. WARNING: Never leave the car unattended with its fuel tank system pressurized. The pressure must be stable (it may rise a little due to fuel evaporation).

Is the pressure stable?

1. YES Refer to «Checking the fuel tank pressure sensor»(ref-408511-S21627232392011071200000)
2. NO Refer to «Checking the fuel tank system»(ref-408511-S22893137782011071200000)

Checking the fuel tank pressure sensor

1. Disconnect tool «9995646»(ref-403953-S17881977312011061000000) .
2. Connect the EVAP canister hose.
3. Remove the hose clamp from the hose between the canister purge (CP) valve and the intake manifold.
4. Start the engine and let it run at idle speed.
5. Read off the value for the fuel tank pressure and the canister purge (CP) valve. When the canister purge (CP) valve opens, the pressure in the fuel tank must drop.

Has the pressure in the fuel tank dropped?

1. YES Refer to «Checking the hose to the EVAP canister shut-off valve»(ref-408511-S37619387052011071200000)
2. NO Refer to «Checking the fuel tank pressure sensor hose»(ref-408511-S36515198102011071200000)

Checking the hose to the EVAP canister shut-off valve

Check the hose to the EVAP canister shut-off valve. Check the seal. Check the terminals.

Remedy as necessary.

Was a fault detected?

1. YES Refer to «Verification information»(ref-408511-S35471396972011071200000)
2. NO Refer to «Replacing the EVAP canister shut-off valve»(ref-408511-S23058609912011071200000)

Checking the fuel tank pressure sensor hose

1. Ignition off.
2. Remove the fuel tank pressure sensor.
3. Remove the hose with the Y-nipple. Check that the nipple and hoses are not blocked. Remedy as necessary. Other information: To access / replace the fuel tank pressure sensor see «Replacing fuel tank pressure sensor»(ref-408506-S28251561632011071200000) .

Was a fault detected?

1. YES Refer to «Verification information»(ref-408511-S35471396972011071200000)
2. NO Refer to «Replacing the fuel tank pressure sensor»(ref-408511-S01360918452011071200000)

Replacing the fuel tank pressure sensor

Try a new fuel tank pressure sensor according to Replacing fuel tank pressure sensor .

Scheme 986

Continue when the fault has been remedied.

1. Continue Refer to «Verification information»(ref-408511-S35471396972011071200000)

Replacing the EVAP canister shut-off valve

Try a new EVAP canister shut-off valve according to Replacing the shut-off valve for the carbon filter container .

Scheme 987

Continue when the fault has been remedied.

1. Continue Refer to «Verification information»(ref-408511-S35471396972011071200000)

Checking the fuel tank system

1. Ignition off.
2. Carefully pressurize the fuel tank system to 7 kPa. The cock must be at right angles to the hoses. NOTE: Max 10 kPa. Check the fuel tank system by spraying soapy water from the EVAP canister to the canister purge (CP) valve. Also spray the line between the fuel tank and the EVAP canister shut-off valve. Also check the filler pipe and the fuel tank filler cap. It may be necessary to lower the fuel tank in order to fault-trace hoses and connectors on top of the fuel tank. Remedy the leakage.

Continue when the fault has been remedied.

1. Continue Refer to «Verification information»(ref-408511-S35471396972011071200000)

Check the hose to the EVAP canister shut-off valve. Check the seal. Check the terminals.

Remedy as necessary.

Is the hose OK?

1. YES Refer to «Replacing the EVAP canister shut-off valve»(ref-408511-S01035333192011071200000)
2. NO Refer to «Verification information»(ref-408511-S35471396972011071200000)

Try a new EVAP canister shut-off valve according to Replacing the EVAP canister shut-off valve .

Continue when the fault has been remedied.

1. Continue Refer to «Verification information»(ref-408511-S35471396972011071200000)

1. Ignition off.
2. Carefully pressurize the fuel tank system to 7 kPa. Turn the EVAP canister shut-off valve so that it is at a right angle to the hoses. WARNING: Max 10 kPa Check the fuel tank system by spraying it with soapy water from the EVAP canister to the canister purge (CP) valve. Also spray the line with the pressure regulator and roll-over valve to the fuel tank. Also check the filler pipe and the fuel tank filler cap. It may be necessary to lower the fuel tank in order to fault-trace hoses and connectors on top of the fuel tank. WARNING: Never leave the car unattended with its system pressurized.

Continue when the fault has been remedied.

1. Continue Refer to «Verification information»(ref-408511-S35471396972011071200000)

Verification information

HINT: After carrying out the check and the repair, check that the fault has been remedied.

Press continue for verification.

1. Continue Refer to «Starting the test of the fuel tank system»(ref-408511-S35457841022011071200000)

Checking the vacuum downstream of the canister purge (CP) valve

1. Disconnect the hose between the canister purge (CP) valve and the EVAP canister from the canister purge (CP) valve.
2. Start the engine and let it run at idle speed Read off the canister purge (CP) valve pulse signal. There should not be a vacuum in the canister purge (CP) valve when the pulse signal is 0%. Other information To access / replace the canister purge (CP) valve, see «Replacing the canister purge (CP) valve»(ref-408434-S03062196182011071200000) .

Is the canister purge (CP) valve OK?

1. YES Refer to «Checking the canister purge (CP) valve»(ref-408511-S30102056352011071200000)
2. NO Refer to «Verification information»(ref-408511-S35471396972011071200000)

Checking the canister purge (CP) valve

Check the canister purge (CP) valve connector for dirt, damage and deposits.

Activate the canister purge (CP) valve to ensure that no function faults occur.

Check that the canister purge (CP) valve does not jam or stop functioning after it has been activated.

1. Continue Refer to «Verification information»(ref-408511-S35471396972011071200000)

1. Open the fuel tank filler cap.
2. Start the engine and let it run at idle speed. Read off the fuel tank pressure. HINT: The fuel tank pressure must be higher than -10 hPa. The normal value is close to 0 hPa.

Is the fuel tank pressure OK?

1. YES Refer to «Checking the canister purge (CP) valve»(ref-408511-S34492580582011071200000)
2. NO Refer to «Verification information»(ref-408511-S35471396972011071200000)

1. Disconnect the hose between the canister purge (CP) valve and the EVAP canister from the canister purge (CP) valve.
2. Start the engine and let it run at idle speed. Read off the canister purge (CP) valve pulse signal. There should not be a vacuum in the canister purge (CP) valve when the pulse signal is 0%. Other information To access / replace the canister purge (CP) valve, see «Replacing the canister purge (CP) valve»(ref-408434-S03062196182011071200000) .

Is the value correct?

1. YES Refer to «Checking hoses»(ref-408511-S23849676212011071200000)
2. NO Refer to «Verification information»(ref-408511-S35471396972011071200000)

Checking hoses

Check that the EVAP canister shut-off valve is not sealed.

Check that the EVAP canister shut-off valve filter is not sealed.

Check the hoses between the EVAP canister and the EVAP canister shut-off valve and between the EVAP canister shut-off valve and its filter for blockages and crimping.

Check the EVAP canister shut-off valve terminal in the EVAP canister for blockage.

Remedy as necessary.

1. To access / replace the EVAP canister shut-off valve see «Replacing the shut-off valve for the carbon filter container»(ref-438954-S12073951932011120700000) .

1. Continue Refer to «Verification information»(ref-408511-S35471396972011071200000)

Check EVAP canister shut-off valve connector for contact resistance and oxidation according to Contact resistance and oxidation and loose connections according to Loose connections (terminals)

Check signal cable between control module #B40 (#B50) and EVAP canister shut-off valve terminal 2 and power supply between system relay terminal 3 and EVAP canister shut-off valve terminal 1 for an intermittent open-circuit according to Open-circuit, intermittent faults .

Other information

1. Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
2. To access/replace the EVAP canister shut-off valve see «Replacing EVAP canister shut-off valve»(ref-438954-S09011749992011120700000) .
3. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

Scheme 988

1. Continue Refer to «Information»(ref-408511-S11843706772011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

Checking connector

1. Ignition off
2. Check EVAP canister shut-off valve connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-408435-S11196285822011071200000) .
3. Reinstall components, reconnect connectors etc.
4. Ignition on.
5. Activate EVAP canister shut-off valve. A "click" should be heard when the EVAP canister shut-off valve is activated. If the EVAP canister shut-off valve is now OK this indicates that the fault was caused by poor contact in the connector. Other information To access/replace the EVAP canister shut-off valve see «Replacing EVAP canister shut-off valve»(ref-438954-S09011749992011120700000) . For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

Is the EVAP canister shut-off valve working?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking wiring and components»(ref-408511-S13290977222011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reconnect connectors, reinstall components.
3. Ignition on.
4. Activate EVAP canister shut-off valve. A "click" should be heard when the EVAP canister shut-off valve is activated.

Is the EVAP canister shut-off valve working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S03234437332011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Permanent fault

Check signal cable between control module #B40 (#B50) and EVAP canister shut-off valve terminal 2 for an intermittent short-circuit to supply voltage according to Short-circuit to supply voltage, intermittent faults .

Other information

1. Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
2. To access/replace the EVAP canister shut-off valve see «Replacing EVAP canister shut-off valve»(ref-438954-S09011749992011120700000) .
3. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

1. Continue Refer to «Information»(ref-408511-S08754736692011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reconnect connectors, reinstall components.
3. Ignition on.
4. Activate EVAP canister shut-off valve. A "click" should be heard when the EVAP canister shut-off valve is activated.

Is the EVAP canister shut-off valve working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S22639112782011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

Check signal cable between control module #B40 (#B50) and EVAP canister shut-off valve terminal 2 for an intermittent short-circuit to ground according to Short-circuit to ground, permanent faults .

Other information

1. Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
2. To access/replace the EVAP canister shut-off valve see «Replacing EVAP canister shut-off valve»(ref-438954-S09011749992011120700000) .
3. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

1. Continue Refer to «Information»(ref-408511-S38791556832011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reconnect connectors, reinstall components.
3. Ignition on.
4. Activate EVAP canister shut-off valve. A "click" should be heard when the EVAP canister shut-off valve is activated.

Is the EVAP canister shut-off valve working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S24673536592011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

Check that the hose between the EVAP canister and EVAP canister shut-off valve is not blocked or pinched.

Check that the EVAP canister connector to the EVAP canister shut-off valve is not blocked.

Check EVAP canister shut-off valve and filter for dirt and deposits.

Try to activate the canister shut off valve to ensure that no malfunctions occur.

1. Continue Refer to «Information»(ref-408511-S10833534252011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Checking fuel tank pressure sensor

1. Open the fuel tank filler cap.
2. Start the engine and let it idle. Read off fuel tank pressure HINT: Fuel tank pressure must be higher than -1000 Pa. The normal value is approximately 0 Pa.

Is the fuel tank pressure OK?

1. YES Refer to «Checking canister purge (CP) valve»(ref-408511-S02078817482011071200000)
2. NO Refer to «Verification»(ref-408511-S26563410982011071200000)

Checking canister purge (CP) valve

1. Disconnect hose between canister purge (CP) valve and EVAP canister from the canister purge (CP) valve.
2. Start the engine and let it idle. Read off canister purge (CP) valve pulse signal. There should not be vacuum in the canister purge (CP) valve when the pulse signal is 0%. Other information Location of components see «Component location, B52X4 T»(ref-408450-S30453749682011071200000) . To access/replace the canister purge (CP) valve, see «Replacing the canister purge (CP) valve»(ref-408434-S03062196182011071200000) .

Is the value correct?

1. YES Refer to «Checking hoses»(ref-408511-S20673252852011071200000)
2. NO Refer to «Verification»(ref-408511-S26563410982011071200000)

Check that EVAP canister shut-off valve is not blocked.

Check that EVAP canister shut-off valve filter is not blocked.

Check hose between EVAP canister and EVAP canister shut-off valve and hose between EVAP canister shut-off valve and filter for blockage or restriction.

Check EVAP canister shut-off valve terminal in EVAP canister for blockage.

Remedy as necessary.

1. Continue Refer to «Verification»(ref-408511-S26563410982011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine. Activate the quick fuel tank system test.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S08871122212011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the connector

Check the fuel tank pressure sensor connector for contact resistance and oxidation according to Contact resistance and oxidation Check for damage carefully.

Other information

1. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

Scheme 989

1. Continue Refer to «Information»(ref-408511-S35822794402011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reconnect connectors, reinstall components.
3. Start the engine. Read off fuel tank pressure. The fuel tank pressure should be approximately 0 hPa (0 psi) when the fuel tank filler cap is open.

Is the fuel tank pressure OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S09346965792011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal, permanent fault

See Faulty signal, permanent fault

Check fuel tank pressure sensor connector for contact resistance and oxidation according to Contact resistance and oxidation and loose connections according to Loose connections (terminals) . Check particularly for any damage.

Check ground lead between control module #B4 (#B14) and fuel tank pressure sensor connector #1 for an intermittent open-circuit according to Open-circuit, intermittent faults .

Check signal cable between control module #B31 (#B41) and fuel tank pressure sensor connector #2 for an intermittent open-circuit according to Open-circuit, intermittent faults .

Check power supply cable between control module #B10 (#B20) and fuel tank pressure sensor connector #3 for an intermittent open-circuit according to Open-circuit, intermittent faults .

Check signal cable between control module #B31 (#B41) and fuel tank pressure sensor connector #2 for an intermittent short-circuit to supply voltage according to Short-circuit to supply voltage, intermittent faults .

HINT: Use a test screwdriver with at least a 3W bulb to determine if the cable is short-circuited to supply voltage.

Other information

1. Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
2. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

1. Continue Refer to «Information»(ref-408511-S29966812862011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

1. Ignition off
2. Check the fuel tank pressure sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-408435-S11196285822011071200000) . Also check for loose connections according to «Loose connections (terminals)»(ref-408435-S33351084802011071200000) . Check for damage carefully.
3. Assemble the connector
4. Start the engine Read off the fuel tank pressure. The fuel tank pressure should be approximately 0 hPa when the fuel tank filler cap is open Other information For specifications see «Component specifications»(ref-408451-S01696444632011071200000) . For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

Is the fuel tank pressure OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Continue checking the connector

Checking the connector (continued)

Check the ground lead between control module terminal B4 (#B14) and fuel tank pressure sensor connector terminal 1. Check the ground lead between control module terminal B31 (#B41) and fuel tank pressure sensor connector terminal 2 for an open-circuit according to Open-circuit, permanent faults .

Check the power supply cable between control module terminal B10 (#B20) and fuel tank pressure sensor connector terminal 3 for an open-circuit according to Open-circuit, permanent faults .

Check the signal cable between control module terminal B31 (#B41) and fuel tank pressure sensor connector terminal 2 for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

HINT: Use a test screwdriver with at least a 3W bulb to determine if the cable is short-circuited to supply voltage

Other information

1. Connecting the breakout box / accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
2. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

1. Continue Refer to «Verification»(ref-408511-S36892220882011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reconnect connectors, reinstall components.
3. Start the engine. Read off fuel tank pressure. The fuel tank pressure should be approximately 0 hPa (0 psi) when the fuel tank filler cap is open.

Is the fuel tank pressure OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S34942816342011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

Check fuel tank pressure sensor connector for contact resistance and oxidation according to Contact resistance and oxidation and loose connections according to Loose connections (terminals) . Check particularly for any damage.

Check signal cable between control module #B31 (#B41) and fuel tank pressure sensor connector #2 for an intermittent short-circuit to ground according to Short-circuit to ground, intermittent faults .

Check power supply cable between control module #B10 (#B20) and fuel tank pressure sensor connector #3 for an intermittent short-circuit to ground according to Short-circuit to ground, intermittent faults .

Other information

1. Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
2. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

1. Continue Refer to «Information»(ref-408511-S01316801582011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

1. Ignition off
2. Check the fuel tank pressure sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-408435-S11196285822011071200000) . Also check for loose connections according to «Loose connections (terminals)»(ref-408435-S33351084802011071200000) . Check for damage carefully.
3. Assemble the connector
4. Start the engine Read off the fuel tank pressure. The fuel tank pressure should be approximately 0 hPa when the fuel tank filler cap is open Other information For specifications see «Component specifications»(ref-408451-S01696444632011071200000) . For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

Is the fuel tank pressure OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking the wiring»(ref-408511-S18450890962011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reconnect connectors, reinstall components.
3. Start the engine. Read off fuel tank pressure. The fuel tank pressure should be approximately 0 hPa (0 psi) when the fuel tank filler cap is open.

Is the fuel tank pressure OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S14891204072011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

Information

No fault-tracing has been developed for this diagnostic trouble code (DTC).

That this trouble code is stored indicates a fault in another control module. Therefore, troubleshoot from the sending control module. This diagnostic trouble code (DTC) can first be erased when the root fault has been remedied and the diagnostic trouble code (DTC) for the root fault has been erased.

For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

First read Safety regulations for handling fuel .

1. Continue Refer to «Checking cables and terminals»(ref-408511-S18582096772011071200000)

Checking cables and terminals

Check that the fuel tank filler cap is on properly and that its seal is intact.

Check hoses and hose connectors at the EVAP canister, EVAP canister shut-off valve and fuel tank.

Remedy as necessary.

Carry out a quick test of the fuel system.

1. Continue Refer to «General about fuel tank system test»(ref-408511-S02980492642011071200000)

Checking engine coolant temperature (ECT)

Note. If the engine coolant temperature (ECT) is under 70 °C (158°F) the test cannot start.

1. Start the engine.
2. Read off engine coolant temperature (ECT) If the engine coolant temperature (ECT) is under 70 °C (158°F) allow the engine to reach operating temperature or interrupt the test.

Is the temperature above 70 °C (158°F)?

1. YES Refer to «Start the fuel tank system test»(ref-408511-S03135942192011071200000)
2. NO FAULT TRACING FAILED

Checking vacuum downstream of the canister purge (CP) valve

1. Start the engine and let it idle.
2. Disconnect the hose between the canister purge (CP) valve and EVAP canister from the canister purge (CP) valve.
3. Read off canister purge (CP) valve. This is to check whether the valve is activated. Check that there is vacuum in the canister purge (CP) valve when the valve is activated.

Is there a vacuum?

1. YES Refer to «Checking vacuum at EVAP canister»(ref-408511-S09209047852011071200000)
2. NO Refer to «Checking vacuum to canister purge (CP) valve»(ref-408511-S12966845622011071200000)

Checking vacuum at EVAP canister

1. Ignition off.
2. Reinstall hose on canister purge (CP) valve.
3. Disconnect hose to canister purge (CP) valve from EVAP canister.
4. Start the engine and let it idle.
5. Read off the canister purge (CP) valve value to determine whether the valve is activated or not. Check that there is vacuum in the hose when the canister purge (CP) valve is activated.

Is there a vacuum?

1. YES Refer to «Checking EVAP canister»(ref-408511-S25903348052011071200000)
2. NO Refer to «Checking hose»(ref-408511-S37564437152011071200000)

Checking vacuum to canister purge (CP) valve

1. Connect hose between canister purge (CP) valve and EVAP canister to canister purge (CP) valve.
2. Start the engine and let it idle.
3. Disconnect hose between canister purge (CP) valve and intake manifold from the canister purge (CP) valve. Check that there is a vacuum in the hose. Remedy as necessary.

Was a fault detected?

1. YES Refer to «Verification»(ref-408511-S27555741632011071200000)
2. NO Refer to «Replacing canister purge (CP) valve»(ref-408511-S32317105422011071200000)

Replacing canister purge (CP) valve

Try a new canister purge (CP) valve according to Replacing the canister purge (CP) valve .

Continue when the fault has been remedied.

1. Continue Refer to «Verification»(ref-408511-S27555741632011071200000)

Checking EVAP canister

Check that all EVAP canister inlets and outlets are airtight.

HINT: Connect a vacuum pump to the EVAP canister terminals, one at a time, check that it is not possible to pump vacuum.

Other information

1. To access/replace the EVAP canister shut-off valve see «Final drive housing, replacing upper bushing»(ref-438955-S41726750642011120700000) .

Was a fault detected?

1. YES Refer to «Verification»(ref-408511-S27555741632011071200000)
2. NO Refer to «Checking hose between fuel tank and EVAP canister»(ref-408511-S17474665602011071200000)

Checking hose

Check if the hose between the canister purge (CP) valve and EVAP canister is blocked or trapped.

Continue when the fault has been remedied.

1. Continue Refer to «Verification»(ref-408511-S27555741632011071200000)

Checking hose between fuel tank and EVAP canister

Check that the hose between the fuel tank and EVAP canister is airtight and is not trapped.

Remedy as necessary.

Was a fault detected?

1. YES Refer to «Verification»(ref-408511-S27555741632011071200000)
2. NO Refer to «Test pressurization of the fuel tank system»(ref-408511-S31366596232011071200000)

1. Disconnect tool «9995646»(ref-403953-S17881977312011061000000) .
2. Connect EVAP canister hose.
3. Remove hose clamp from hose between canister purge (CP) valve and intake manifold.
4. Start the engine and let it idle.
5. Read off fuel tank pressure and canister purge (CP) valve value. When the canister purge (CP) valve opens the pressure in the fuel tank should drop.

Is pressure in the fuel tank dropping?

1. YES Refer to «Checking hose to EVAP canister shut-off valve»(ref-408511-S06351559192011071200000)
2. NO Refer to «Checking fuel tank pressure sensor hose»(ref-408511-S41480206652011071200000)

Checking hose to EVAP canister shut-off valve

Check hose to EVAP canister shut-off valve seal and check connectors.

Remedy as necessary.

Was a fault detected?

1. YES Refer to «Verification»(ref-408511-S27555741632011071200000)
2. NO Refer to «Replacing EVAP canister shut-off valve»(ref-408511-S24003021432011071200000)

Checking fuel tank pressure sensor hose

1. Ignition off.
2. Remove fuel tank pressure sensor.
3. Remove hose with Y-nipple. Check that the nipple and hoses are not blocked. Remedy as necessary. Other information: To access/replace the fuel tank pressure sensor see «Replacing fuel tank pressure sensor»(ref-408506-S28251561632011071200000) .

Was a fault detected?

1. YES Refer to «Verification»(ref-408511-S27555741632011071200000)
2. NO Refer to «Replacing fuel tank pressure sensor»(ref-408511-S34880121362011071200000)

Replacing fuel tank pressure sensor

Try a new fuel tank pressure sensor according to Replacing fuel tank pressure sensor

Continue when the fault has been remedied.

1. Continue Refer to «Verification»(ref-408511-S27555741632011071200000)

Replacing EVAP canister shut-off valve

Try a new EVAP canister shut-off valve according to Final drive housing, replacing upper bushing .

Continue when the fault has been remedied.

1. Continue Refer to «Verification»(ref-408511-S27555741632011071200000)

Checking fuel tank system

1. Ignition off.
2. Carefully pressurize the fuel tank system to 7 kPa (1.02 psi). Cock at right angles to the hoses. NOTE: Max 10 kPa (1.45 psi). Check fuel tank system by spraying soapy water from the EVAP canister to the canister purge (CP) valve. Spray the line between the fuel tank and EVAP canister shut-off valve. Check filler pipe and fuel tank filler cap. It may be necessary to lower the fuel tank in order to fault-trace hoses and connectors on top of the fuel tank. Remedy leakage.

Continue when the fault has been remedied.

1. Continue Refer to «Verification»(ref-408511-S27555741632011071200000) .

1. Ignition off.
2. Reinstall all hoses/components.
3. Start the engine. Activate the quick fuel tank system test.

Does the diagnostic trouble code (DTC) recur?

1. YES Refer to «Information»(ref-408511-S16107672162011071200000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

First read Safety regulations for handling fuel .

1. Continue Refer to «Checking hoses and pipes»(ref-408511-S01730272932011071200000)

Checking hoses and pipes

Check that the fuel tank filler cap is on properly and that its seal is intact.

Check that the hoses and hose connectors at the EVAP canister and fuel tank are not leaking or pinched.

Continue when the fault has been remedied.

1. Continue Refer to «Information»(ref-408511-S06535261142011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Major leak. Permanent fault

See Major leak. Permanent fault

Major leak. Intermittent fault

See Major leak. Intermittent fault

First read Safety regulations for handling fuel .

1. Continue Refer to «Checking hoses and connectors»(ref-408511-S05733705622011071200000)

Checking hoses and connectors

Check that the fuel tank filler cap is on properly and that its seal is intact.

Check that the hoses and hose connectors at the EVAP canister and fuel tank are not leaking or pinched.

Continue when the fault has been remedied.

1. Continue Refer to «Information»(ref-408511-S02847568052011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Checking fuels system for leaks

Special tools

See 9995646

First read Safety regulations for handling fuel .

1. Continue Refer to «Checking cables and terminals»(ref-408511-S06615866612011071200000)

Check that the fuel tank filler cap is on properly and that its seal is intact.

Check hoses and hose connectors at the EVAP canister, EVAP canister shut-off valve and fuel tank.

Remedy as necessary.

Carry out a quick test of the fuel system.

1. Continue Refer to «General about fuel tank system test»(ref-408511-S24654258002011071200000)

Note. If the engine coolant temperature (ECT) is under 70 °C (158°F) the test cannot start.

1. Start the engine.
2. Read off engine coolant temperature (ECT) If the engine coolant temperature (ECT) is under 70 °C (158°F) allow the engine to reach operating temperature or interrupt the test.

Is the temperature above 70 °C (158°F)?

1. YES Refer to «Start the fuel tank system test»(ref-408511-S21467738402011071200000)
2. NO FAULT TRACING FAILED

Check hose to EVAP canister shut-off valve seal and check connectors.

Remedy as necessary.

Is the hose OK?

1. YES Refer to «Replacing EVAP canister shut-off valve»(ref-408511-S13034408942011071200000)
2. NO Refer to «Verification»(ref-408511-S19638712902011071200000)

Try a new EVAP canister shut-off valve according to Replacing the EVAP canister shut-off valve .

Continue when the fault has been remedied.

1. Continue Refer to «Verification»(ref-408511-S19638712902011071200000)

Scheme 990

1. Ignition off.
2. Remove fuel tank pressure sensor.
3. Remove hose with Y-nipple. Check that the nipple and hoses are not blocked. Remedy as necessary. Other information: To access/replace the fuel tank pressure sensor see «Replacing fuel tank pressure sensor»(ref-408506-S28251561632011071200000) .

Was a fault detected?

1. YES Refer to «Verification»(ref-408511-S19638712902011071200000)
2. NO Refer to «Replacing fuel tank pressure sensor»(ref-408511-S23440944592011071200000)

Try a new fuel tank pressure sensor according to Replacing fuel tank pressure sensor .

Continue when the fault has been remedied.

1. Continue Refer to «Verification»(ref-408511-S19638712902011071200000)

1. Ignition off.
2. Carefully pressurize the fuel tank system to 7 kPa (1.02 psi). EVAP canister shut-off valve right angles to the hoses. WARNING: Max 10 kPa (1.45 psi) Check fuel tank system by spraying it with soapy water from the EVAP canister to the canister purge (CP) valve and on the line with the pressure regulator and roll-over valve to the fuel tank. Check filler pipe and fuel tank filler cap. It may be necessary to lower the fuel tank in order to fault-trace hoses and connectors on top of the fuel tank. WARNING: Never leave the car unattended with its system pressurized.

Continue when the fault has been remedied.

1. Continue Refer to «Verification»(ref-408511-S19638712902011071200000)

1. Ignition off.
2. Reinstall all hoses/components.
3. Start the engine. Activate the quick fuel tank system test.

Does the diagnostic trouble code (DTC) recur?

1. YES Refer to «Information»(ref-408511-S04940421302011071200000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

Fault-tracing information, fault no longer present

The control module has previously registered a fault. The fault is now no longer present.

1. Continue Refer to «Information»(ref-408511-S06257532402011071200000)

Fault-tracing information, fault does not recur

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Intermittent fault

See Intermittent fault

See Intermittent fault

Checking for air leakage in the intake system

Check for air leakage according to Check for air leaks in the intake system .

Remedy as necessary.

Scheme 991

Was there any air leakage?

1. YES Refer to «Verification»(ref-408511-S24189249332011071200000)
2. NO Refer to «Checking for air leakage in the exhaust system»(ref-408511-S06549908742011071200000)

Checking for air leakage in the exhaust system

Check for air leakage according to Checking for air leakage in the exhaust system .

Remedy as necessary.

Scheme 992

Was there any air leakage?

1. YES Refer to «Verification»(ref-408511-S24189249332011071200000)
2. NO Refer to «Checking fuel and residual pressures»(ref-408511-S09035190552011071200000)

Checking fuel and residual pressures

Check fuel and residual pressure according to Checking fuel and residual pressures .

Remedy as necessary.

Scheme 993

Was the pressure OK?

1. YES Refer to «Checking compression»(ref-408511-S36469072802011071200000)
2. NO Refer to «Verification»(ref-408511-S24189249332011071200000)

Checking compression

Carry out a compression test according to Compression test .

Remedy as necessary.

Scheme 994

Was compression OK?

1. YES Refer to «Replacing three-way catalytic converter (TWC)»(ref-408511-S25224920962011071200000)
2. NO Refer to «Verification»(ref-408511-S24189249332011071200000)

Replacing three-way catalytic converter (TWC)

1. Try a new three-way catalytic converter (TWC). Replace according to «Three-way catalytic converter (TWC), replacing»(ref-408502-S01552487202011071200000) .

Continue when the fault has been remedied.

1. Continue Refer to «Verification»(ref-408511-S24189249332011071200000)

HINT: After carrying out the repair, check that the fault has been remedied as follows

Scheme 995

1. Ignition off.
2. Replace connector, components etc.
3. Test drive car according to «Verifying repairs»(ref-408503-S09635708222011071200000) . NOTE: After test driving the engine should not be turned off. Information in the control module is erased. Connect VCT2000 to the data link connector (DLC). Read off the status of the diagnostic trouble code (DTC). The text NOT READY is displayed if the diagnosis is still on-going. This indicates that the test drive was too short.

Is FAULT NOT REGISTERED displayed?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S17862647432011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Permanent fault

See Permanent fault

See Permanent fault

Info

When the fault is no longer present, no fault-tracing for an intermittent fault is required.

Scheme 996

1. Continue OKAY: Troubleshooting has been completed.

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Start the engine.
4. Air conditioning (A/C) switch on
5. Start the blower fan Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check if cold air blows into the passenger compartment when at the coolest setting. NOTE: The air conditioning (A/C) pressure is given in volts for values see «Component specifications»(ref-438955-S33969082952011120700000) .

Does the pressure in air conditioning (A/C) system change?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S26833550622011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Start the engine.
4. Air conditioning (A/C) switch on
5. Start the blower fan Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check if cold air blows into the passenger compartment when at the coolest setting. NOTE: The air conditioning (A/C) pressure is given in volts for values see «Component specifications»(ref-438955-S33969082952011120700000) .

Does the pressure in air conditioning (A/C) system change?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S29589879302011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Start the engine.
4. Air conditioning (A/C) switch on
5. Start the blower fan Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check if cold air blows into the passenger compartment when at the coolest setting. NOTE: The air conditioning (A/C) pressure is given in volts for values see «Component specifications»(ref-438955-S33969082952011120700000) .

Does the pressure in air conditioning (A/C) system change?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S20446993362011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

No fault tracing has been developed for this diagnostic trouble code.

The diagnostic trouble code for this fault is first generated in the brake control module (BCM) and then in the engine control module (ECM). This diagnostic trouble code cannot be cleared until the code in the brake control module (BCM) has been remedied and cleared.

Thus, first read the diagnostic trouble codes in the brake control module (BCM), perform fault tracing and remedy as necessary. Afterwards, this diagnostic trouble code can be cleared.

HINT: For more information on this diagnostic trouble code, select Information and then Diagnostic trouble code information.

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

No fault-tracing has been developed for this diagnostic trouble code (DTC). A diagnostic trouble code (DTC) for this fault is stored in the transmission control module (TCM) first and then in the engine control module (ECM). This diagnostic trouble code (DTC) can not be erased before the diagnostic trouble code (DTC) in the transmission control module (TCM) has been erased and remedied.

First read off the diagnostic trouble codes (DTCs) in the transmission control module (TCM). Fault-trace and remedy as required. This diagnostic trouble code (DTC) can then be erased. For further information about this diagnostic trouble code (DTC), select Information, then DTC information.

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

Check connector for air conditioning (A/C) relay for contact resistance and oxidation according to Contact resistance and oxidation and loose connections according to Loose connections (terminals)

Check signal cable between control module #B44 and air conditioning (A/C) relay #4 and power supply between system relay #3 and A/C relay #2 for an intermittent open-circuit according to Open-circuit, intermittent faults .

Other information

1. To connect the breakout box/access the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000)
2. To access/replace the air conditioning (A/C) relay, see «Integrated relay/fleshpots, engine compartment, replacing»(ref-438950-S27450357292011120700000)
3. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000)

Scheme 997

1. Continue Refer to «Information»(ref-408511-S37694633772011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

1. Ignition off
2. Check air conditioning (A/C) relay connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-408435-S11196285822011071200000) .
3. Reinstall components, reconnect connectors etc.
4. Ignition on.
5. Activate air conditioning (A/C) relay. An "clicking sound" should be heard from the air conditioning (A/C) relay when it is activated. If the air conditioning (A/C) relay is now OK it means that the cause of the fault has been loose connections in the connector. Other information To access/replace the air conditioning (A/C) relay, see «Integrated relay/fleshpots, engine compartment, replacing»(ref-438950-S27450357292011120700000) . For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

Does the air conditioning (A/C) relay function?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking wiring and components»(ref-408511-S37102747522011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reconnect connectors, reinstall components
3. Ignition on.
4. Activate air conditioning (A/C) relay. An "clicking sound" should be heard from the air conditioning (A/C) relay when it is activated.

Does the air conditioning (A/C) relay function?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S26927973222011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Permanent fault

Check the signal cable between control module #B44 and air conditioning (A/C) relay 4 for an intermittent short-circuit to supply voltage according to Short-circuit to supply voltage, intermittent faults .

Other information

1. To connect the breakout box/access the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
2. To access/replace the air conditioning (A/C) relay, see «Integrated relay/fleshpots, engine compartment, replacing»(ref-438950-S27450357292011120700000) .
3. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

1. Continue Refer to «Information»(ref-408511-S11782209472011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reconnect connectors, reinstall components
3. Ignition on.
4. Activate air conditioning (A/C) relay. An "clicking sound" should be heard from the air conditioning (A/C) relay when it is activated.

Does the air conditioning (A/C) relay function?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S10321317932011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

Check signal cable between control module #B44 and air conditioning (A/C) relay #4 for an intermittent short-circuit to ground according to Short-circuit to ground, intermittent faults .

Other information

1. To connect the breakout box/access the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000)
2. To access/replace the air conditioning (A/C) relay, see «Integrated relay/fleshpots, engine compartment, replacing»(ref-438950-S27450357292011120700000)
3. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000)

1. Continue Refer to «Information»(ref-408511-S07250408612011071200000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reconnect connectors, reinstall components
3. Ignition on.
4. Activate air conditioning (A/C) relay. An "clicking sound" should be heard from the air conditioning (A/C) relay when it is activated.

Does the air conditioning (A/C) relay function?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S33545965562011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Activate engine cooling fan (FC).

Does the engine cooling fan (FC) start?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S12106976382011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Activate engine cooling fan (FC).

Does the engine cooling fan (FC) start?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S05931123962011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Activate engine cooling fan (FC).

Does the engine cooling fan (FC) start?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S30657981122011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 998

1. Ignition off.
2. Reinstall connectors, components etc.
3. Disconnect the Volvo Scan Tool (ST) from the VIDA station. Use it in stand alone mode and connect it to the data link connector (DLC) in the car.
4. Ignition on.
5. Go into scrolling values. Check the outside temperature reading is correct. Compare with the actual air temperature.

Is the temperature reading OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S07836128772011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Activate engine cooling fan (FC).

Does the engine cooling fan (FC) start?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S37604620242011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Activate engine cooling fan (FC).

Does the engine cooling fan (FC) start?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S21233127082011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Start the engine.
4. Activate ETS lamp.
5. Check that function is OK.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S00162234322011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Start the engine.
4. Activate ETS lamp.
5. Check that function is OK.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S23571269042011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Start the engine.
4. Activate ETS lamp.
5. Check that function is OK.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S00270278622011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

1. Ignition off.
2. Check reset valve connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-408435-S41703021522011071200000) .
3. Reinstall components, reconnect connectors etc.
4. Ignition on.
5. Start the engine.
6. Increase engine speed (RPM) on the engine and read off the camshaft timing alterations. If the camshaft timing changes it means that the cause of the fault has been loose connections in the connector. Other information Access/replace the camshaft reset valve.

Is the function OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking component and wiring»(ref-408511-S26081419582011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Start the engine.
5. Increase engine speed (RPM) on the engine and read off the camshaft timing alterations.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S25641719602011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

Check reset valve camshaft resistance between #1 and #2, resistance should be approximately 3.7 ohm.

Check the signal cable between engine control module (ECM) #A13 and camshaft reset valve #2 for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
2. Access/replace the camshaft reset valve.
3. With the ignition on and camshaft reset valve connector disconnected the voltage on connector #1 should be approximately Abut and connector #2 be a pulse modulated signal with top voltage at approximately Abut and with a frequency of approximately 250 Hz.
4. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

1. Continue Refer to «Verification»(ref-408511-S12563017392011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Start the engine.
5. Increase engine speed (RPM) on the engine and read off the camshaft timing alterations.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S05161659602011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

Check reset valve camshaft resistance between #1 and #2, resistance should be approximately 3.7 ohm.

Check the signal cable between engine control module (ECM) #A13 and camshaft reset valve #2 for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Check power supply cable #5 and camshaft reset valve #1 for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
2. Access/replace the camshaft reset valve.
3. With the ignition on and camshaft reset valve connector disconnected the voltage on connector #1 should be approximately Abut and connector #2 be a pulse modulated signal with top voltage at approximately Abut and with a frequency of approximately 250 Hz.
4. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

1. Continue Refer to «Verification»(ref-408511-S00742994572011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Start the engine.
5. Increase engine speed (RPM) on the engine and read off the camshaft timing alterations.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S26869271742011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

Checking the status

1. Start the engine. Read off the camshaft shift angle and the camshaft shift angle, desired value. At idle and at 4000 rpm, check that the camshaft's shift angle (desired value) corresponds with the camshaft's shift angle by an accuracy of 3 degrees. The difference between the values can be read off in the lower display. Carry out the check at stable engine speed (RPM). NOTE: Before the engine speed (RPM) stabilizes, the difference between the values can be greater than 3 degrees for approximately 1 second, this is normal. If the values correspond by an accuracy of 3 degrees, this means that the fault is intermittent. If the values deviate more than 3 degrees, this means that the fault is permanent.

Do the values match?

1. YES Refer to «Intermittent fault»(ref-408511-S11353960412011071200000)
2. NO Refer to «Checking the components and wiring»(ref-408511-S32080014292011071200000)

Checking components

1. Check the engine oil level and quality. Check for contaminants in particular.
2. Check the engine oil pressure.
3. Remove the camshaft reset valve. Check the oil ducts in the cylinder head for the camshaft's reset valve. Check for blockage and contamination. NOTE: If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced. Try with a new camshaft reset valve if no fault is found in the above troubleshooting. HINT: If the fault persists after carrying out the above checks or corrective action, this can mean a damaged VT unit. Remedy as necessary. Other information: See «Checking oil pressure»(ref-408514-S34093292232011071200000) To access/replace the camshaft reset valve, see: See «Replacing the camshaft seals / variable valve timing (VT) unit»(ref-408502-S09754657832011071200000) See «Variable valve timing control»(ref-408511-S42660237052011102100000)

1. Continue Refer to «Verification»(ref-408511-S27770687652011071200000)

Scheme 999

Continuous variable valve timing (CVVT) control, general

The engine combustion can be improved by changing the shift angle of the camshaft. This reduces emissions, gives lower fuel consumption and better performance. The shift angle of the camshaft is controlled by the control module which changes the pulse ratio of the reset valve. The pulse ratio of the reset valve affects the variable valve timing unit which changes the camshaft position compared to the crankshaft position (CKP). This ensures quick and precise control of the shift angle of the camshaft.

Definition of "Camshaft shift angle" (X°)

When the camshaft (A) is set at the factory it is aligned to top dead center (TDC) on the crankshaft which is 0° (B). The camshaft position when aligned to the crankshaft TDC is the camshaft 0 position (0°). With continuous variable valve timing (CVVT) the camshaft 0 position is offset, the value of the offset of the camshaft 0 position is the camshaft shift angle (x°).

Scheme 1000

The control module interpretation of camshaft shift angle

(The illustration shows the camshaft shift angle at 10°)

The camshaft shift angle is checked by the control module by comparing the position of the crankshaft with the position of the camshaft.

The camshaft (A) is divided into 4 flanks per camshaft rotation (flanks 1-4). The angles are: between flanks 1-2 = 103°, flanks 2-3 = 90°, flanks 3-4 = 90° and flanks 4-1= 77°. The difference in angle between the flanks allows the control module to determine which flank is currently detected and therefore which cycle the camshaft is in. The control module detects the flanks using the signal from the camshaft position (CMP) sensor.

The crankshaft has four reference positions, one for each camshaft flank. Two reference positions are detected for each crankshaft rotation. Two engine rotations are required to detect all the camshaft flanks: flank 1 at 0°, flank 2 at 206°, flank 3 at 386° and flank 4 at 576° (flanks 3 and 4 are detected during the second rotation of the engine).

The reference positions on the crankshaft correspond exactly to the respective camshaft flank when the camshaft shift angle = 0°. The control module detects the reference positions for the camshaft flanks using the engine speed (RPM) sensor signal.

If, for example, the camshaft shift angle is +10°, the flanks correspond to the crankshaft reference positions for the respective camshaft flank and +10° from the crankshaft reference positions.

Example

If the camshaft flank 1 is detected at 10° from the crankshaft reference position for flank 1 (0° +10°), the camshaft shift angle is 10°. If the camshaft shift angle is the same (10°), flank 2 is detected at 216° (206° + 10°), flank 3 at 396° (386° + 10°), and flank 4 at 576° (586° + 10°). The shift angle can be positive (+) or negative (-) depending on whether the flank is detected before or after the different crankshaft reference positions.

Scheme 1001

Adaptation of the camshaft shift angle, flanks 1-4

(The illustration shows the adaptation of the camshaft shift angle at 10°)

When the engine has the "basic setting", the ideal value for the camshaft adaptation value is 0°. The different camshaft flanks correspond exactly with the reference positions for the respective flanks. These values may deviate because of tolerances in the materials and installation. By adapting these deviations the camshaft shift angle can be exact.

Adaptation is carried out as follows

Camshaft control not active, the pulse ratio on the camshaft reset valve is set to approximately 90% by the control module. This means that the camshaft 0 position (mechanical resting position) is assumed and the camshaft angles (x°) for flanks 1-4, which are then detected by the control module, are the adaptation values which are stored. (The adaptation values will be 0° if the camshaft adjustment in relation to the crankshaft is exact). When the control module operates the camshaft to a particular target value, the stored adaptation value is added to the control module's target value.

Example: The control module has adapted flanks 1-4 to an average value of +10° (as the result of an incorrectly set camshaft for example). When the control module needs to operate the camshaft to +10° (target value), the adaptation value is added to the target value which then gives a target value of 20° (10° +10°=20°).

The control module can adapt 20°. A diagnostic trouble code (DTC) is stored in the control module if the adaptation is higher or lower than 10°.

Other information

1. If the timing belt is incorrectly positioned by one tooth on the variable valve timing unit, this corresponds to approximately 17° on the crankshaft. This gives a theoretical adaptation value of 17°.
2. If the timing belt is incorrectly positioned by one tooth on the variable valve timing unit, this corresponds to approximately 34° on the crankshaft. This gives a maximum adaptation value (20°)
3. The setting of the variable valve timing unit in relation to the camshaft and crankshaft affects the adaptation value (between -20° and +20°)
4. If the slide in the camshaft reset valve has jammed, the camshaft will be operate at maximum angle. This which will give an adaptation value at the maximum limit (+20° or -20°)
5. The function of the variable valve timing unit affects the adaptation value (between -20° and +20°).

Check the resistance on camshaft reset valve between terminals #1 and #2.Resistance must be approximately 3.7 ohms.

Check the signal cable between Engine control module (ECM) terminal #A13 and camshaft reset valve terminal #2. Check for an open-circuit, short-circuit to ground and short-circuit to voltage.

Check the power supply cable between system relay terminal #5 and camshaft reset valve terminal #1. Check for an open-circuit.

Check the engine oil level and quality. Check for contaminants in particular.

Check the engine oil pressure.

Remove the camshaft reset valve. Check the oil ducts in the cylinder head for the camshaft's reset valve. Check for blockage and contamination.

Note. If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced.

HINT: The diagnostic trouble code (DTC) can also be caused by a damaged variable valve timing (VT) unit.

Remedy as necessary.

Other information

1. See «Checking wiring and terminals»(ref-438953-S20310262912011120700000)
2. See «Connecting the breakout box»(ref-408435-S12899753102011071200000)
3. See «Signal specification»(ref-408451-S42269556162011071200000)
4. See «Checking oil pressure»(ref-408514-S34093292232011071200000)
5. To access/replace the camshaft reset valve, see
6. See «Replacing the camshaft seals / variable valve timing (VT) unit»(ref-408502-S09754657832011071200000)
7. See «Variable valve timing control»(ref-408511-S05278947392011102100000)

1. Continue Refer to «Verification»(ref-408511-S27770687652011071200000)

Variable valve timing control

Continuous variable valve timing (CVVT) control, general

The engine combustion can be improved by changing the shift angle of the camshaft. This reduces emissions, gives lower fuel consumption and better performance. The shift angle of the camshaft is controlled by the control module which changes the pulse ratio of the reset valve. The pulse ratio of the reset valve affects the variable valve timing unit which changes the camshaft position compared to the crankshaft position (CKP). This ensures quick and precise control of the shift angle of the camshaft.

Definition of "Camshaft shift angle" (X°)

When the camshaft (A) is set at the factory it is aligned to top dead center (TDC) on the crankshaft which is 0° (B). The camshaft position when aligned to the crankshaft TDC is the camshaft 0 position (0°). With continuous variable valve timing (CVVT) the camshaft 0 position is offset, the value of the offset of the camshaft 0 position is the camshaft shift angle (x°).

The control module interpretation of camshaft shift angle

(The illustration shows the camshaft shift angle at 10°)

The camshaft shift angle is checked by the control module by comparing the position of the crankshaft with the position of the camshaft.

The camshaft (A) is divided into 4 flanks per camshaft rotation (flanks 1-4). The angles are: between flanks 1-2 = 103°, flanks 2-3 = 90°, flanks 3-4 = 90° and flanks 4-1= 77°. The difference in angle between the flanks allows the control module to determine which flank is currently detected and therefore which cycle the camshaft is in. The control module detects the flanks using the signal from the camshaft position (CMP) sensor.

The crankshaft has four reference positions, one for each camshaft flank. Two reference positions are detected for each crankshaft rotation. Two engine rotations are required to detect all the camshaft flanks: flank 1 at 0°, flank 2 at 206°, flank 3 at 386° and flank 4 at 576° (flanks 3 and 4 are detected during the second rotation of the engine).

The reference positions on the crankshaft correspond exactly to the respective camshaft flank when the camshaft shift angle = 0°. The control module detects the reference positions for the camshaft flanks using the engine speed (RPM) sensor signal.

If, for example, the camshaft shift angle is +10°, the flanks correspond to the crankshaft reference positions for the respective camshaft flank and +10° from the crankshaft reference positions.

Example

If the camshaft flank 1 is detected at 10° from the crankshaft reference position for flank 1 (0° +10°), the camshaft shift angle is 10°. If the camshaft shift angle is the same (10°), flank 2 is detected at 216° (206° + 10°), flank 3 at 396° (386° + 10°), and flank 4 at 576° (586° + 10°). The shift angle can be positive (+) or negative (-) depending on whether the flank is detected before or after the different crankshaft reference positions.

Adaptation of the camshaft shift angle, flanks 1-4

(The illustration shows the adaptation of the camshaft shift angle at 10°)

When the engine has the "basic setting", the ideal value for the camshaft adaptation value is 0°. The different camshaft flanks correspond exactly with the reference positions for the respective flanks. These values may deviate because of tolerances in the materials and installation. By adapting these deviations the camshaft shift angle can be exact.

Adaptation is carried out as follows

Camshaft control not active, the pulse ratio on the camshaft reset valve is set to approximately 90% by the control module. This means that the camshaft 0 position (mechanical resting position) is assumed and the camshaft angles (x°) for flanks 1-4, which are then detected by the control module, are the adaptation values which are stored. (The adaptation values will be 0° if the camshaft adjustment in relation to the crankshaft is exact). When the control module operates the camshaft to a particular target value, the stored adaptation value is added to the control module's target value.

Example: The control module has adapted flanks 1-4 to an average value of +10° (as the result of an incorrectly set camshaft for example). When the control module needs to operate the camshaft to +10° (target value), the adaptation value is added to the target value which then gives a target value of 20° (10° +10°=20°).

The control module can adapt 20°. A diagnostic trouble code (DTC) is stored in the control module if the adaptation is higher or lower than 10°.

Other information

1. If the timing belt is incorrectly positioned by one tooth on the variable valve timing unit, this corresponds to approximately 17° on the crankshaft. This gives a theoretical adaptation value of 17°.
2. If the timing belt is incorrectly positioned by one tooth on the variable valve timing unit, this corresponds to approximately 34° on the crankshaft. This gives a maximum adaptation value (20°)
3. The setting of the variable valve timing unit in relation to the camshaft and crankshaft affects the adaptation value (between -20° and +20°)
4. If the slide in the camshaft reset valve has jammed, the camshaft will be operate at maximum angle. This which will give an adaptation value at the maximum limit (+20° or -20°)
5. The function of the variable valve timing unit affects the adaptation value (between -20° and +20°).

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine. Read off the camshaft shift angle and the camshaft shift angle, desired value. Check at idle speed and at approximately 4000 rpm that the camshaft shift angle, desired value, corresponds to the camshaft shift angle to an accuracy of 3°. The difference between the values can be read off in the lower display. Carry out the check at stable engine speed (RPM). NOTE: Before the engine speed stabilizes, the difference between the values may be 3° over approximately 1 second. This is normal. If the values correspond with an accuracy of 3°, it indicates that the fault is intermittent. If the values deviate by more than 3° it indicates that the fault is permanent.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S06610681442011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Continuous variable valve timing (CVC) control, general

The engine combustion can be improved by changing the shift angle of the camshaft. This reduces emissions, gives lower fuel consumption and better performance. The shift angle of the camshaft is controlled by the control module which changes the pulse ratio of the reset valve. The pulse ratio of the reset valve affects the variable valve timing unit which changes the camshaft position compared to the crankshaft position (CKP). This ensures quick and precise control of the shift angle of the camshaft.

Definition of "Camshaft shift angle" (X°)

When the camshaft (A) is set at the factory it is aligned to top dead center (TDC) on the crankshaft which is 0° (B). The camshaft position when aligned to the crankshaft TDC is the camshaft 0 position (0°). With continuous variable valve timing (CVC) the camshaft 0 position is offset, the value of the offset of the camshaft 0 position is the camshaft shift angle (x°).

The control module interpretation of camshaft shift angle

(The illustration shows the camshaft shift angle at 10°)

The camshaft shift angle is checked by the control module by comparing the position of the crankshaft with the position of the camshaft.

The camshaft (A) is divided into 4 flanks per camshaft rotation (flanks 1-4). The angles are: between flanks 1-2 = 103°, flanks 2-3 = 90°, flanks 3-4 = 90° and flanks 4-1= 77°. The difference in angle between the flanks allows the control module to determine which flank is currently detected and therefore which cycle the camshaft is in. The control module detects the flanks using the signal from the camshaft position (CMP) sensor.

The crankshaft has four reference positions, one for each camshaft flank. Two reference positions are detected for each crankshaft rotation. Two engine rotations are required to detect all the camshaft flanks: flank 1 at 0°, flank 2 at 206°, flank 3 at 386° and flank 4 at 576° (flanks 3 and 4 are detected during the second rotation of the engine).

The reference positions on the crankshaft correspond exactly to the respective camshaft flank when the camshaft shift angle = 0°. The control module detects the reference positions for the camshaft flanks using the engine speed (RPM) sensor signal.

If, for example, the camshaft shift angle is +10°, the flanks correspond to the crankshaft reference positions for the respective camshaft flank and +10° from the crankshaft reference positions.

Example

If the camshaft flank 1 is detected at 10° from the crankshaft reference position for flank 1 (0° +10°), the camshaft shift angle is 10°. If the camshaft shift angle is the same (10°), flank 2 is detected at 216° (206° + 10°), flank 3 at 396° (386° + 10°), and flank 4 at 576° (586° + 10°). The shift angle can be positive (+) or negative (-) depending on whether the flank is detected before or after the different crankshaft reference positions.

Adaptation of the camshaft shift angle, flanks 1-4

(The illustration shows the adaptation of the camshaft shift angle at 10°)

When the engine has the "basic setting", the ideal value for the camshaft adaptation value is 0°. The different camshaft flanks correspond exactly with the reference positions for the respective flanks. These values may deviate because of tolerances in the materials and installation. By adapting these deviations the camshaft shift angle can be exact.

Adaptation is carried out as follows

Camshaft control not active, the pulse ratio on the camshaft reset valve is set to approximately 90% by the control module. This means that the camshaft 0 position (mechanical resting position) is assumed and the camshaft angles (x°) for flanks 1-4, which are then detected by the control module, are the adaptation values which are stored. (The adaptation values will be 0° if the camshaft adjustment in relation to the crankshaft is exact). When the control module operates the camshaft to a particular target value, the stored adaptation value is added to the control module's target value.

Example: The control module has adapted flanks 1-4 to an average value of +10° (as the result of an incorrectly set camshaft for example). When the control module needs to operate the camshaft to +10° (target value), the adaptation value is added to the target value which then gives a target value of 20° (10° +10°=20°).

The control module can adapt 20°. A diagnostic trouble code (DTC) is stored in the control module if the adaptation is higher or lower than 10°.

Other information

1. If the timing belt is incorrectly positioned by one tooth on the variable valve timing unit, this corresponds to approximately 17° on the crankshaft. This gives a theoretical adaptation value of 17°.
2. If the timing belt is incorrectly positioned by one tooth on the variable valve timing unit, this corresponds to approximately 34° on the crankshaft. This gives a maximum adaptation value (20°)
3. The setting of the variable valve timing unit in relation to the camshaft and crankshaft affects the adaptation value (between -20° and +20°)
4. If the slide in the camshaft reset valve has jammed, the camshaft will be operate at maximum angle. This which will give an adaptation value at the maximum limit (+20° or -20°)
5. The function of the variable valve timing unit affects the adaptation value (between -20° and +20°).

Slow regulation/Faulty signal

See Slow regulation/Faulty signal

See Slow regulation/Faulty signal

See Slow regulation/Faulty signal

See Slow regulation/Faulty signal

See Slow regulation/Faulty signal

Checking component

Check camshaft position (CMP) sensor connector for contact resistance and oxidation according to Contact resistance and oxidation

Remedy as necessary

Other information

1. For the camshaft reset valve diagnostic functions, see «Camshaft diagnostics»(ref-438955-S07640446912011120700000) .
2. To access/replace the camshaft position (CMP) sensor, see «Replacing camshaft position (CMP) sensor»(ref-408506-S28559416372011071200000) .
3. For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .

Scheme 1002

1. Continue Refer to «Verification»(ref-408511-S08065701042011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Start the engine. Check the camshaft adaptation by reading off the adaptation values of the camshaft (flanks 1-4). All values must be between -7° and +7°. Turbocharged engines: When checking, the accelerator pedal (AP) must be depressed slightly but the engine speed must be below 1200 rpm. Naturally aspirated engines: When checking the engine must be idling. HINT: Theoretically the values for flanks 1-4 should be the same, however because of mechanical tolerances the values may vary between the different flanks by approximately 2°.

Are all the adaptation values correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S20846500172011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Faulty control

See Faulty control

See Faulty control

Checking the fault type

Read out the adapted values for the camshaft. There are 4 values, one for each flank.

If one of the adaptation values is 20 degrees, the camshaft reset valve has stuck. Replace the camshaft reset valve.

If one of the adaptation values is less than 9 degrees, the camshaft reset valve is defective. Replace the camshaft reset valve.

If any of the adaptation values are between 10 and 19 degrees, the variable camshaft must be adjusted in relation to the crankshaft. Adjust the camshaft.

Remedy as necessary

Other information

1. To adjust the camshaft position (CMP), see «Replacing the camshaft seals / variable valve timing (VT) unit»(ref-408502-S09754657832011071200000)
2. To replace the camshaft reset valve, see.

1. Continue Refer to «Verification»(ref-408511-S05588124212011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Start the engine. Check the camshaft adaptation by reading off the adaptation values of the camshaft (flanks 1-4). All values must be between -7° and +7°. Turbocharged engines: When checking, the accelerator pedal (AP) must be depressed slightly but the engine speed must be below 1200 rpm. Naturally aspirated engines: When checking the engine must be idling. HINT: Theoretically the values for flanks 1-4 should be the same, however because of mechanical tolerances the values may vary between the different flanks by approximately 2°.

Are all the adaptation values correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S25071136022011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Faulty position

See Faulty position

See Faulty position

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

1. Ignition off.
2. Check turbocharger (TC) control valve connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-408435-S41703021522011071200000) .
3. Reinstall components, reconnect connectors etc.
4. Ignition on.
5. Activate turbocharger (TC) control valve.
6. A clicking sound should be heard from the turbocharger (TC) control valve. If the function is OK the cause of the fault was loose connections in the connector. Other information To access/replace the turbocharger (TC) control valve, see «Replacing the turbocharger (TC) control valve»(ref-408507-S19034283562011071200000) .

Is the function OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking component and wiring»(ref-408511-S28371714282011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Activate turbocharger (TC) control valve
5. A click should be heard from the turbocharger (TC) control valve.
6. Check that the function is OK.

Is function OK ?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S39634999922011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Activate turbocharger (TC) control valve
5. A click should be heard from the turbocharger (TC) control valve.
6. Check that the function is OK.

Is function OK ?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S15581946022011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Activate turbocharger (TC) control valve
5. A click should be heard from the turbocharger (TC) control valve.
6. Check that the function is OK.

Is function OK ?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S12313818002011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

Checking the hoses and turbocharger (TC) control valve

Check that the hoses between the intake manifold, pressure regulator and turbocharger (TC) control valve are not trapped, blocked or damaged.

Check the turbocharger (TC) control valve by activating it.

Check the alignment of the boost pressure control (BPC) valve pressure servo and the boost pressure control (BPC) valve and that they are functioning correctly and not sticking according to Wastegate valve, adjusting .

Other information

1. To access the turbocharger (TC) control valve, see «Replacing the turbocharger (TC) control valve»(ref-408507-S19034283562011071200000) .

1. Continue Refer to «Verification»(ref-408511-S37973510512011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Disconnect the VCT2000 from the data link connector (DLC).
4. Test drive the car and check that high boost pressure is obtained.
5. Connect the VCT2000 to the data link connector (DLC). NOTE: Do not switch off the ignition before the VCT2000 has been connected and the boost pressure has been tested with the smart tool. Read off the boost pressure fault status When the boost pressure has been tested the display should show that the diagnostic is complete.

Is the fault status display as not found ?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S31160975182011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Pressure too high. Permanent/Intermittent fault

See Pressure too high. Permanent/Intermittent fault

See Pressure too high. Permanent/Intermittent fault

Check intake system for leakage according to Check for air leaks in the intake system .

Remedy as necessary

1. Continue Refer to «Verification»(ref-408511-S07498199222011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Disconnect the VCT2000 from the data link connector (DLC).
4. Test drive the car and check that high boost pressure is obtained.
5. Connect the VCT2000 to the data link connector (DLC). NOTE: Do not switch off the ignition before the VCT2000 has been connected and the boost pressure has been tested with the smart tool. Read off the boost pressure fault status When the boost pressure has been tested the display should show that the diagnostic is complete.

Is the fault status display as not found ?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S41892493242011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Flow too high. Permanent/Intermittent fault

See Flow too high. Permanent/Intermittent fault

See Flow too high. Permanent/Intermittent fault

Check that the hoses between the intake manifold, pressure regulator and turbocharger (TC) control valve are not trapped, blocked or damaged.

Check the turbocharger (TC) control valve by activating it.

Check the alignment of the boost pressure control (BPC) valve pressure servo and the boost pressure control (BPC) valve and that they are functioning correctly and not sticking according to Wastegate valve, adjusting .

Remedy as necessary

1. Continue Refer to «Verification»(ref-408511-S18943512092011071200000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Disconnect the VCT2000 from the data link connector (DLC).
4. Test drive the car and check that high boost pressure is obtained.
5. Connect the VCT2000 to the data link connector (DLC). NOTE: Do not switch off the ignition before the VCT2000 has been connected and the boost pressure has been tested with the smart tool. Read off the boost pressure fault status When the boost pressure has been tested the display should show that the diagnostic is complete.

Is the fault status display as not found ?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-408511-S02485362892011071200000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Flow too low. Permanent/Intermittent fault

See Flow too low. Permanent/Intermittent fault

See Flow too low. Permanent/Intermittent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
