Checking component and wiring
Check outside temperature sensor resistance.
Check signal cable between control module #B29 (#B39) and outside temperature sensor #1 for a short-circuit to ground according to Short-circuit to ground, permanent faults
HINT: With the ignition on and outside temperature sensor connector disconnected the voltage between #1 and ground terminal should be approximately 5V.
Remedy as necessary.
Other information
- Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
- To access/replace the outside temperature sensor, see «Outside temperature sensor»(ref-408462-S15308477632011071200000) .
- For resistance values, see «Component specifications»(ref-408451-S01696444632011071200000) .
- For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .
Scheme 779
- Continue Refer to «Verification»(ref-408504-S11408824522011071200000)
Checking wiring and components
Check outside temperature sensor resistance.
Note. The outside temperature sensor can be defective if the signal cable has been short-circuited to supply voltage. Check this before replacing the sensor.
Check signal cable between control module #B29 (#B39) and outside temperature sensor #1 for an intermittent open-circuit according to Open-circuit, permanent faults and a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults
HINT: With the ignition on and the outside temperature sensor connector disconnected, the voltage between #1 and ground should be approximately 5 V.
Check the ground lead between control module #B2 (#B12) and the outside temperature sensor #2 for an open-circuit according to Open-circuit, permanent faults
Remedy as necessary.
Other information
- Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
- To access/replace the outside temperature sensor see «Outside temperature sensor»(ref-408462-S15308477632011071200000) .
- For resistance values, see «Component specifications»(ref-408451-S01696444632011071200000) .
- For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .
- Continue Refer to «Verification»(ref-408504-S26323620742011071200000)
Check the Intake Air Temperature (IAT) sensor resistance.
Check signal cable between control module #A5 (#A5) and intake air temperature sensor #1 for a short-circuit to ground according to Short-circuit to ground, permanent faults
HINT: With the ignition on and the Intake Air Temperature (IAT) sensor connector disconnected, the voltage between #1 and ground should be approximately 5 V.
Remedy as necessary.
Other information
- Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
- To access/replace the Intake Air Temperature (IAT) sensor see «Intake Air Temperature Sensor (IAT Sensor), replacing»(ref-408507-S11148925822011071200000) .
- For resistance values, see «Component specifications»(ref-408451-S01696444632011071200000) .
- For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .
- Continue Refer to «Verification»(ref-408504-S41791464122011071200000)
Check the Intake Air Temperature (IAT) sensor resistance.
Note. The Intake Air Temperature (IAT) sensor can be defective if the signal cable has been short-circuited to supply voltage. Check this before replacing the sensor.
Check signal cable between control module #A5 (#A5) and intake air temperature (IAT) sensor connector #1 for an open-circuit according to Open-circuit, permanent faults and a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .
HINT: With the ignition on and intake air temperature (IAT) sensor connector disconnected voltage between #1 and ground terminal should be approximately 5 V.
Check the ground lead between control module #A60 (#A60) and intake air temperature (IAT) sensor connector #2 for an open-circuit according to Open-circuit, permanent faults
Remedy as necessary.
Other information
- Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-408435-S12899753102011071200000) .
- To access/replace the Intake Air Temperature (IAT) sensor see «Intake Air Temperature Sensor (IAT Sensor), replacing»(ref-408507-S11148925822011071200000) .
- For information about signals, see «Signal specification»(ref-408451-S42269556162011071200000) .
- Continue Refer to «Verification»(ref-408504-S05840213912011071200000)
