How to Replace the Engine Speed Sensor Opel Vivaro A

Remove

1. 1. Release resonance chamber (3) with ducting hose from air cleaner cover • Release strap (1) from support bracket (2) • Position resonance chamber (3) to one side

2. 2. Release harness (3) of engine speed sensor from bracket (1) • Release clip
3. 3. Disconnect harness connector (2) from harness (3) • Release integral clip

4. 4. Raise vehicle
5. 5. Remove engine undershield from vehicle
6. 6. Remove engine speed sensor (2) from transmission (3) • Remove bolt (1)

Install

7. 7. Install engine speed sensor (2) to transmission (3) • Install bolt (1)

8. 8. Install engine undershield to vehicle
9. 9. Lower vehicle
10. 10. Connect harness connector (2) to harness (3) of engine speed sensor • Secure integral clip
11. 11. Secure harness (3) to bracket (1) • Secure clip

12. 12. Install resonance chamber (3) with ducting hose to air cleaner cover • Secure strap (1) to support bracket (2)
