How to Replace the Filter Element, Air Cleaner Opel Vivaro A

Remove

1. 1. Release oil filler cap assembly from air cleaner assembly, then move to one side • Release 2x screw (1)

Note. The securing screws are part of the oil filler cap assembly.

2. 2. Remove cover (1) of air cleaner assembly • Disconnect hose (3) from mass air flow meter – Release clip • Disconnect harness connector (2) from mass air flow meter • Release 2x screw (4)

Note. The securing screws are part of the air cleaner cover.

3. 3. Remove air cleaner element (5)

Install

4. 4. Install new air cleaner element (5)
5. 5. Install cover (1) of air cleaner assembly • Secure 2x screw (4) 3 Nm • Connect harness connector (2) to mass air flow meter • Connect hose (3) to mass air flow meter – Secure clip

6. 6. Secure oil filler cap assembly to air cleaner assembly • Secure 2x screw (1) 3 Nm
