Functional Description: Engine Management System Opel Vivaro A

Fuel Injection Systems 1 illustration

Specifications

EngineG9U 632 (low output)G9U 630 and G9U 632 (high output)G9U 650 (low output)G9U 650 (high output)
Engine management system-Bosch EDC 16 C36Bosch EDC 16 C36Bosch EDC 16 C36Bosch EDC 16 C36
Exhaust emission standards-Euro IVEuro IVEuro IVEuro IV
No. of cylinders/configuration-4 in line4 in line4 in line4 in line
No. of valves-16161616
Capacitycm 32464246424642464
Bore diametermm87878787
Strokemm92929292
Firing order-1–3–4–21–3–4–21–3–4–21–3–4–2
Power outputkW/rpm88/3500107/350074/350088/3500
TorqueNm/rpm300/1500320/1500260/1600290/1600

Diagram of Engine Management System

1.High pressure pump14.Turbocharger
2.Fuel temperature sensor15.Compressor
3.Common rail16.Intercooler
4.Fuel pressure sensor17.Charge pressure sensor
5.Fuel filter18.Coolant temperature sensor
6.Fuel tank19.Exhaust gas recirculation valve
7.Fuel pressure regulator20.Engine control unit
8.Mass air flow meter21.Oil level sensor
9.Oil pressure valve22.Crankshaft inductive pulse pickup
10.Air flap23.Exhaust gas bypass
11.Camshaft sensor24.Exhaust gas regulator
12.Fuel injector25.Primary catalytic converter
13.Glow plug
