- 1. Pressure reducing valve
- 2. Low pressure line CNG system
- 3. CNG distributor pipe (CNG injectors)
- 4. Voltage transformer - engine control unit CNG (only vehicles up to chassis number W0L0TGT 7542057677)
- 5. Switch for gas/petrol operation
- 6. Emergency tank with in-tank module
- 7. CNG filler valve
Zafira Cng, Component Overview (Continued)
| 8 | CNG filling line |
|---|
| 9 | CNG tank module, rear |
| 10 | High pressure line for bottle safety valve |
| 11 | Bottle safety valve (CNG tank module, rear) |
| 12 | High pressure line for CNG tank module front/rear |
| 13 | High pressure line for bottle safety valve |
| 14 | Bottle safety valve (CNG tank module, front) |
Zafira Cng, Component Overview (Continued)
| 15 | CNG high pressure line, rear |
|---|
| 16 | Separation point/pipe connection |
| 17 | CNG high pressure line, centre |
| 18 | CNG tank module, front |
| 19 | Discharge connection |
| 20 | CNG high pressure line, front |
| 21 | CNG engine |
