Special Service Tools Opel Zafira B

DOHC Petrol Engine 9 illustrations
KM-135Adapter
To measure engine oil pressure in conjunction with KM-498-B
KM-194-ESpark Plug Key
To remove/install spark plug
KM-301Gauge Bar
To check piston projection
KM-412Engine Overhaul Stand
To hold the removed engine
KM-412-8-AAdapter
To hold engine in conjunction with KM-412
KM-422Installer
To press seal ring in camshaft
KM-427Remover / Installer
To install guide pins into engine block
KM-470-BAngular Torque Wrench
To tighten cylinder head bolts
KM-471Adapter
To check pressurised cooling system in conjunction with cooling system tester
KM-498-BOil Pressure Manometer
To check engine oil pressure in conjunction with KM-135
KM-535Installer
To install crankshaft seal ring in conjunction with KM-635
MKM-571-BDial Gauge
To check various components
MKM-596-ATemperature Gauge
To measure oil temperature
MKM-604-DTorx Bit and Socket Set
To remove/install Torx bolts
KM-609Electronic Kit I
To diagnose electrical and electronic systems
MKM-610Torque Wrench, 1/2"
Range 30 – 130 Nm / 22 – 96 lbf. ft.
MKM-611Torque Wrench, 3/8"
Range 10 – 60 Nm / 7 – 44 lbf. ft.
KM-635Installer
To install rear crankshaft seal ring in conjunction with KM-535
KM-652Flywheel Locking Device
To lock flywheel or drive disc
KM-662-CHolding Wrench
To hold toothed belt drive gear when removing and installing fastening bolt
MKM-667Pressure and Vacuum Pump
To check vacuum units for leaks
MKM-669Torque Wrench, 1/2"
Range 50 – 300 Nm / 37 – 221 lbf. ft.
KM-693-AAssembly Sleeves
To install crankshaft front seal ring
KM-726-AOil Filter Wrench
To remove/install the oil filter
KM-796-ARemover
To open quick fittings for fuel lines
KM-798Dial Gauge
To measure tooth backlash of balancer shaft unit
KM-835-AInstaller
To install the valve stem seal
KM-840Remover
To remove valve stem seals
KM-845Suction Device
To remove the hydraulic valve lifters
KM-853Locking Tool
To lock the camshaft pulleys
MKM-889Automatic Valve Spring Lever
To remove/install the valve stem seals (cylinder head installed)
KM-904Base Frame
To remove and install various vehicle components with additional adapters
KM-949Measurement Sensor
To measure in conjunction with KM-798
KM-956-1Handle
To hold the camshaft sprocket to slacken/tighten the fastening bolts in conjunction with KM-6347
KM-2355Socket Wrench T55
To loosen/tighten cylinder head bolts
KM-6000Centring Tool
To remove and install front axle in conjunction with KM-904
KM-6001-AEngine Mount
To align engine to body in conjunction with KM-6173
KM-6009Remover/installer
To remove/install ignition module
KM-6042Remover
To remove cables on transmission from shift lever assembly (F23)
KM-6068Automatic Valve Spring Lever
To remove/install the valve stem seals (cylinder head installed)
KM-6173Engine Mount
To support engine on front axle body in conjunction with KM-6001-A
KM-6347Holder
To hold the camshaft sprockets to slacken/tighten the fastening bolts in conjunction with KM-956-1
KM-J-34730-91Pressure Tester
To check fuel pressure
