Illustration Opel Zafira B

1. 1. Air intake hose
2. 2. Hot film mass air flowmeter
3. 3. Charge air hose
4. 4. Charge air redirector pipe
5. 5. Intercooler
6. 6. Charge air hose
7. 7. Air intake manifold
8. 8. Resonator
9. 9. Air intake hose
10. 10. Air cleaner housing, lower part
11. 11. Air cleaner housing, upper part

Note. Any possible contamination (grease, oil, etc.) must be cleaned from hoses and connections prior to assembly.

Take care to precisely maintain tightening torque of 3.5 Nm / 2.6 lbf. ft when tightening hose clamps,

Caution

Only if the hose clamps are correctly tightened to the specified tightening torque, can sealing of the intake system and thereby operational safety be ensured.
