Recommended Torque Values (Group J) Opel Vivaro A

DOHC Diesel Engine 1 illustration ~113 words
Nm
Accelerator pedal bolts8
Air conditioning compressor to engine25
Alternator to auxiliary bracket25
Auxiliary support bracket to engine44
Blanking bolt to cylinder block (for Positioning Pin EN-48330)25
Bracket for right engine mount to engine, M10 bolt25
Bracket for right engine mount to engine, M13 bolt30 + 54°
Bracket to primary catalytic converter and engine, nut8
Bracket to primary catalytic converter and engine, bolt21
Bracket to turbocharger and cylinder head25
Brake caliper to steering knuckle100
Camshaft bearing block to cylinder block – 1st stage5
Camshaft bearing block to cylinder block – 2nd stage12
Camshaft bearing cap to camshaft bearing block10
Camshaft gear (left) 1)10 + 40° ± 6º
Camshaft gear (right)20 + 35°
Camshaft sensor to cylinder head10
Centre impact absorber to centre air deflector4
Clutch assembly to flywheel20
Common rail to cylinder head25
Compressor to engine25
Connecting rod end cap to connecting rod25 + 55° ± 6°
Coolant pump to cylinder block25
Crankshaft inductive pulse pick-up to engine10
Crankshaft pulley50 + 85°
Cylinder block reinforcement to cylinder block – 1st stage10
Cylinder block reinforcement to cylinder block – 2nd stage25
Cylinder head bolt – 1st stage5
Cylinder head bolt – 2nd stage30
Cylinder head bolt – 3rd stage300° ± 6°
Dipstick guide tube to engine10
Drive gear to exhaust camshaft40 + 34°
Earth lead to starter21
EGR cooler to engine25
EGR pipe to cooler and control valve25
EGR pipe to cooler and exhaust manifold25
EGR pipe to exhaust manifold25
EGR valve to intake manifold21
Engine and transmission undershield8
Engine damping block (right side) to engine mount100
Engine damping block (right side) to inner wing44
Exhaust manifold stud to cylinder head9
Exhaust manifold to cylinder head – 1st stage18
Exhaust manifold to cylinder head – 2nd stage33
Flywheel to crankshaft – 1st stage30
Flywheel to crankshaft – 2nd stage35 + 40° ± 6°
Front exhaust pipe to centre exhaust pipe25
Front exhaust pipe to primary catalytic converter21
Front panel4
Fuel breather pipe to engine10
Fuel drain pipe to engine10
Fuel injector to cylinder head35
Fuel pipe support bracket to camshaft bearing block10
Fuel return pipe to camshaft bearing block10
Glow plug to cylinder head18
Harness lead to starter, M6 nut5
Harness lead to starter, M8 nut8
Heat shield to EGR pipe10
High pressure fuel pump gear90
High pressure fuel pump to engine – 1st stage5
High pressure fuel pump to engine – 2nd stage25
High pressure pipe to camshaft bearing block10
High pressure pipe to common rail32
High pressure pipe to engine10
High pressure pipe to fuel injector32
High pressure pipe to high pressure pump32
Hub nut280
Intake manifold stud to cylinder head9
Intake manifold to engine – 1st stage15
Intake manifold to engine – 2nd stage25
Intercooler to reinforcement panel8
Lower engine stabiliser to bracket and subframe, front280
Lower engine stabiliser to bracket and subframe, rear100
Lower front crossmember44
Mounting for damping block, left side, to chassis44
Mounting for damping block, left side, to transmission bracket60
Oil drain plug
Oil feed pipe to engine and turbocharger10
Oil feed pipe to turbocharger, bolt16
Oil filter and cooler housing to cylinder block – 1st stage5
Oil filter and cooler housing to cylinder block – 2nd stage25
Oil filter cover to housing25
Oil level sensor25
Oil pan to cylinder block – 1st stage5
Oil pan to cylinder block – 2nd stage16
Oil pick-up to cylinder block10
Oil pressure switch20
Oil pump to cylinder block – 1st stage5
Oil pump to cylinder block – 2nd stage25
Oil return pipe to engine and turbocharger10
Oil separator to camshaft bearing block – 1st stage5
Oil separator to camshaft bearing block – 2nd stage10
Oil splash shield8
Power steering high pressure pipe to auxiliary support bracket21
Power steering high pressure pipe to power steering pump24
Power steering hose assembly to oil filter and cooler housing25
Power steering pipe assembly to engine/transmission assembly21
Power steering pump to engine21
Primary catalytic converter to turbocharger21
Pulley to coolant pump21
Pulley to power steering pump10
Radiator grille4
Radiator support crossmember22
Radiator undershield8
Rear crankshaft seal ring to cylinder block – 1st stage5
Rear crankshaft seal ring to cylinder block – 2nd stage10
Refrigerant pipe to air conditioning compressor8
Refrigerant pipe to condenser8
Ribbed V-belt guide roller to engine44
Ribbed V-belt tension roller to engine25
Screw behind registration plate of front panel6
Side splash panel, bolt8
Side splash panel, screw6
Starter to engine44
Steering knuckle to strut180
Strap to primary catalytic converter21
Support frame for air cleaner assembly8
Support bracket for drive shaft60
Thermostat housing to cylinder head11
Throttle valve assembly to engine12
Throttle valve module to engine12
Tie rod to steering knuckle37
Timing chain cover to engine – 1st stage5
Timing chain cover to engine (M6) – 2nd stage16
Timing chain cover to engine (M8) – 2nd stage18
Timing chain guide to engine (non-tensioner side) – 1st stage5
Timing chain guide to engine (non-tensioner side) – 2nd stage25
Timing chain guide to engine (tensioner side)25
Timing chain tensioner to engine10
Transmission drain plug18
Transmission to engine, bolt50
Transmission to engine, nut50
Transmission to engine, stud6
Turbocharger support bracket to cylinder head25
Turbocharger to exhaust manifold28
Upper engine stabiliser to chassis100
Upper engine stabiliser to support bracket44
Upper plate to engine25
Vacuum pump to engine15
Wheel bolt140
FasteningsStandard Tightening Torque (Nm)
DiameterProperty Class
M68.810
M88.825
M108.850
M1010.962
M1210.9105
M1410.9180
M1610.9280
M1810.9400

Property class of bolt is indicated at position (1) or (2).

Observing the tightening torques and angles

Bolted assemblies whose tightening torques and angles are specified in the removal and refitting procedures, must be observed using the appropriate tools (torque wrench or angle gauge). Failure to observe this may lead to safety risks, immobilising faults or noises.

For other bolted assemblies, non-measured tightening (using suitable tools) is acceptable. Nevertheless, the corresponding tightening torque is indicated in the table of standard tightening torques.

1

) As each camshaft has both intake and exhaust camshaft lobes, the camshafts are identified as “left” (exhaust manifold side) or “right” (intake manifold side)
