How to Replace the Engine Cover Opel Vivaro A

Remove

1. 1. Remove air cleaner assembly – see operation “Air Cleaner Assembly, Remove and Install”
2. 2. Remove engine cover (1) • Release coolant hose (2) from engine cover – Release from clip • Release fuel pipe (3) from engine cover – Release from 5x clip • Remove nut (4) • Release upper intercooler hose from intercooler, then move to one side – Release clip • Release locater of engine cover from grommet

Install

3. 3. Install new engine cover (1) • Secure locater of engine cover to grommet • Secure upper intercooler hose to intercooler – Secure clip • Install nut (4) • Secure fuel pipe (3) to engine cover – Secure to 5x clip • Secure coolant hose (2) engine cover – Secure to clip

4. 4. Install air cleaner assembly – see operation “Air Cleaner Assembly, Remove and Install”
