Engine Survey
The M9R 780 engine introduced for Vivaro MY 2007 is available with a choice of two power outputs, a low output of 66 kW and a high output of 84 kW. The different power outputs are controlled by programs set with the engine ECUs.
Some of the main features of the M9R 780 engine are listed below.
- DOHC 16-valve technology
- Camshafts chain driven from crankshaft
- Common rail, up to 1600 bar, with piezo electric injectors
- Bosch EDC16 CP33 engine management system
- Water-cooled exhaust gas recirculation system
- Exhaust emissions that comply with Euro IV standards
- Variable geometry turbocharger with air-cooled intercooler
- Reinforced cylinder block base plate for improved acoustics
View of Engine, Exhaust Side
View of Engine, Intake Side, with Engine Number Location
Torque and Output Curves, Low Output Engine
| A. | Torque curve |
|---|---|
| B. | Output curve |
Torque and Output Curves, High Output Engine
| A. | Torque curve |
|---|---|
| B. | Output curve |
