How to Replace the Support Bracket, Engine Damping Block, Right Opel Vivaro A

Remove

1. 1. Disconnect battery negative lead
2. 2. Raise vehicle
3. 3. Remove engine and transmission undershield from vehicle • Remove 6x bolt
4. 4. Remove right splash panel • Release washer hose from 2x clip • Remove 2x bolt, screw

5. 5. Remove left splash panel • Remove 2x bolt, screw
6. 6. Install Engine Support KM-6210-A to vehicle – see operation “Engine Support KM-6210-A, Install and Remove”

7. 7. Lower vehicle
8. 8. Release power steering reservoir from front panel, then move to side • Release from integral clip

9. 9. Release harness (1) and fuel pipe (2) from support bracket • Release from clip

10. 10. Remove support bracket (1) from engine • Remove 4x bolt (2), nut (3)

Install

Important. Ensure 3x bolt (2, 3, 4) are secured in correct sequence.

11. 11. Install support bracket to engine • Install 3x bolt in sequence (3, 4, 2) 10 Nm • Secure 3x bolt in sequence (3, 4, 2) 65 Nm • Secure bolt (1) 44 Nm • Secure nut (5) 44 Nm

12. 12. Secure harness (1) and fuel pipe (2) to support bracket • Secure to clip

13. 13. Secure power steering reservoir to front panel • Secure to integral clip

14. 14. Raise vehicle
15. 15. Remove Engine Support KM-6210-A from vehicle

16. 16. Install right splash panel • Secure washer hose to 2x clip • Install 2x bolt 8 Nm , screw 6 Nm

17. 17. Install left splash panel • Install 2x bolt 8 Nm , screw 6 Nm
18. 18. Install engine and transmission undershield to vehicle • Install 6x bolt 6 Nm
19. 19. Lower vehicle
20. 20. Connect battery negative lead
21. 21. Program all volatile memories
