How to Replace the Support Bracket, Engine Stabiliser, Upper Opel Vivaro A

Remove

1. 1. Disconnect battery negative lead
2. 2. Raise vehicle
3. 3. Remove engine and transmission undershield from vehicle • Remove 6x bolt
4. 4. Remove right splash panel • Release washer hose from 2x clip • Remove 2x bolt, screw

5. 5. Remove left splash panel • Remove 2x bolt, screw
6. 6. Install Engine Support KM-6210-A to vehicle – see operation “Engine Support KM-6210-A, Install and Remove”

7. 7. Lower vehicle
8. 8. Remove support bracket (4) from upper engine stabiliser (2) and chassis • Remove bolt (5) • Remove 2x bolt (1, 3)

Install

9. 9. Install new support bracket (4) to upper engine stabiliser (2) and chassis • Install bolt (5); do not tighten at this stage • Install 2x bolt (1, 3); do not tighten at this stage • Secure bolt (5) 44 Nm • Secure bolt (3) 44 Nm • Secure bolt (1) 100 Nm

10. 10. Raise vehicle
11. 11. Remove Engine Support KM-6210-A from vehicle

12. 12. Install right splash panel • Secure washer hose to 2x clip • Install 2x bolt 8 Nm , screw 6 Nm

13. 13. Install left splash panel • Install 2x bolt 8 Nm , screw 6 Nm
14. 14. Install engine and transmission undershield to vehicle • Install 6x bolt 6 Nm
15. 15. Lower vehicle
16. 16. Connect battery negative lead
17. 17. Program all volatile memories
