Replace Ribbed V-Belt Opel Astra H

Remove

1. 1. Open bonnet
2. 2. Raise vehicle by its full height
3. 3. Remove engine compartment cover and/or right-hand engine splash guard if necessary
4. 4. Remove ribbed V-belt • Apply tension to ribbed V-belt tensioner via bolt (1) in the direction of the arrow • Secure ribbed V-belt tensioner at bore (2) with KM-6130 • Remove ribbed-V-belt

Note. Mark direction of rotation

Install

5. 5. Insert ribbed V-belt • Position ribbed V-belt – I. Ribbed V-belt without air conditioning – II. Ribbed V-belt with air conditioning • Apply tension to ribbed V-belt tensioner via bolt (1) in the direction of the arrow – Remove KM-6130

Note. Observe direction of rotation

6. 6. Install engine compartment cover and/or right engine splash guard
7. 7. Lower vehicle by its full height
8. 8. Close bonnet
