Replace Ribbed V-Belt Tensioner Opel Astra H

DOHC Diesel Engine 2 illustrations

Remove

1. Remove alternator
2. Remove ribbed V-belt guide roller (2) • Unscrew bolt (1)

Replace Ribbed V-Belt Tensioner

3. Remove ribbed V-belt tensioner • Detach screw connection (arrow)

Replace Ribbed V-Belt Tensioner

Install

4. Install ribbed V-belt tensioner • Tighten screw connection 90 Nm
5. Install ribbed V-belt guide roller • Tighten bolt 50 Nm
6. Install alternator
