DTC P0523: EOP Sensor Circuit High Voltage Honda Civic VIII рестайлинг

Testing & Diagnostics 4 illustrations ~726 words

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ). Information marked with an asterisk (*) applies to '07-10 model.

Scheme 134

Scheme 134: DTC P0523: EOP Sensor Circuit High Voltage
Scheme 134: DTC P0523: EOP Sensor Circuit High Voltage

Scheme 135

Scheme 135
Scheme 135

Scheme 136

Scheme 136
Scheme 136

Scheme 137

Scheme 137
Scheme 137
  1. Turn the ignition switch ON (II).
  2. Check the OIL PRESSURE SENSOR in the DATA LIST with the HDS. Is there about 4.79 V or more? YES - Go to step 3. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the EOP sensor and the ECM/PCM.
  3. Turn the ignition switch OFF.
  4. Disconnect the EOP sensor 3P connector.
  5. Connect EOP sensor 3P connector terminals No. 2 and No. 3 with a jumper wire.
  6. Turn the ignition switch ON (II).
  7. Check the OIL PRESSURE SENSOR in the DATA LIST with the HDS. Is there about 4.79 V or more? YES - Go to step 8. NO - Go to step 18 .
  8. Remove the jumper wire.
  9. Measure voltage between EOP sensor 3P connector terminals No. 1 and No. 3. Is there about 5 V? YES - Go to step 14 . NO - Go to step 10.
  10. Turn the ignition switch OFF.
  11. Jump the SCS line with the HDS.
  12. Disconnect ECM/PCM connector C (44P) (B (44P))*.
  13. Check for continuity between ECM/PCM connector terminal C14 (B33)* and EOP sensor 3P connector terminal No. 3. Is there continuity? YES - Go to step 26 . NO - Repair open in the wire between the ECM/PCM (C14) (B33) * and the EOP sensor, then go to step 20 .
  14. Turn the ignition switch OFF.
  15. Jump the SCS line with the HDS.
  16. Disconnect ECM/PCM connector C (44P).
  17. Check for continuity between ECM/PCM connector terminal C22 and EOP sensor 3P connector terminal No. 2. Is there continuity? YES - Go to step 26 . NO - Repair open in the wire between the ECM/PCM (C22) and the EOP sensor, then go to step 20 .
  18. Turn the ignition switch OFF.
  19. Replace the EOP sensor (see «EOP SENSOR REMOVAL/INSTALLATION»(ref-255541-S27740896892007060300000) ).
  20. Reconnect all connectors.
  21. Turn the ignition switch ON (II).
  22. Reset the ECM/PCM with the HDS.
  23. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-255517-S24591238122007060300000) ).
  24. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0523 indicated? YES - Check for poor connections or loose terminals at the EOP sensor and the ECM/PCM, then go to step 1 . NO - Go to step 25.
  25. Monitor the OBD STATUS for DTC P0523 in the DTCs MENU with the HDS. Does the screen indicated PASSED? YES - Troubleshooting is complete. If any other Temporary DTCs or DTCs were indicated in step 24 , go to the indicated DTCs troubleshooting. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the EOP sensor and the ECM/PCM, then go to step 1 . If the screen indicates NOT COMPLETED, keep idling until a result comes on.
  26. Reconnect all connectors.
  27. Update the ECM/PCM if it does not have the latest software (see «ECM/PCM UPDATE»(ref-355126-S21746322412010012000000) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-379879-S00676494072010121600000) ).
  28. Start the engine, and let it idle.
  29. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0523 indicated? YES - Check for poor connections or loose terminals at the EOP sensor and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-379879-S00676494072010121600000) ), then go to step 28 . If the ECM/PCM was substituted, go to step 1 . NO - Go to step 30.
  30. Monitor the OBD STATUS for DTC P0523 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(ref-355126-S35548339322010012000000) ). If any other Temporary DTCs or DTCs were indicated in step 29 , go to the indicated DTCs troubleshooting. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the EOP sensor and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-379879-S00676494072010121600000) ), then go to step 28 . If the ECM/PCM was substituted, go to step 1 . If the screen indicates NOT COMPLETED, keep idling until a result comes on.
