Electronic Throttle Control System (R18A1 Engine): Removal & Installation Honda Civic VIII рестайлинг

Accelerator Pedal Module Removal/Installation

'06-08 models

Scheme 128

1. Disconnect the APP sensor 6P connector (A), then remove the nuts (B).
2. Remove the accelerator pedal module (B). NOTE: The APP sensor is not available separately. Do not disassemble the accelerator pedal module.
3. Install the parts in the reverse order of removal.

'09-11 models

Scheme 129

1. Disconnect the APP sensor 6P connector (A).
2. Remove the clip (B). NOTE: Do not reuse the clip once it is removed.
3. Push the tab (C), and remove the accelerator pedal pad (D) from the pedal stop (E).
4. Remove the accelerator pedal module (F). NOTE: The APP sensor is not available separately. Do not disassemble the accelerator pedal module.
5. Set the accelerator pedal pad (A) to the pedal stop (B).
6. Install the accelerator pedal module (C) with a new clip (D).
7. Reconnect the APP sensor 6P connector (E).
