Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ). Information marked with an asterisk (*) applies to '07-11 models.
Scheme 846
Scheme 847
Scheme 848
Scheme 849
Scheme 850
Scheme 851
Scheme 852
- Turn the ignition switch to ON (II).
- Check ECT SENSOR 2 in the DATA LIST with the HDS. Is about -40°F (-40°C) or less, or 4.92 V or more indicated? YES -Go to step 3. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at ECT sensor 2 and the ECM/PCM.
- Turn the ignition switch to LOCK (0).
- Disconnect the ECT sensor 2 2P connector.
- Connect ECT sensor 2 2P connector terminals No. 1 and No. 2 with a jumper wire.
- Turn the ignition switch to ON (II).
- Check ECT SENSOR 2 in the DATA LIST with the HDS. Is about -40°F (-40°C) or less, or 4.92 V or more indicated? YES -Go to step 8. NO -Go to step 20 .
- Turn the ignition switch to LOCK (0).
- Remove the jumper wire from the ECT sensor 2 2P connector.
- Turn the ignition switch to ON (II).
- Measure the voltage between ECT sensor 2 2P connector terminal No. 2 (No. 1)* and body ground. '06 model '07-11 models Is there about 5 V? YES -Go to step 12. NO -Go to step 16 .
- Turn the ignition switch to LOCK (0).
- Jump the SCS line with the HDS.
- Disconnect ECM/PCM connector A (44P).
- Check for continuity between ECT sensor 2 2P connector terminal No. 1 (No. 2)* and ECM/PCM connector terminal A9. '06 model '07-11 models Is there continuity? YES -Go to step 27 . NO -Repair open in the wire between the ECM/PCM (A9) and ECT sensor 2, then go to step 22 .
- Turn the ignition switch to LOCK (0).
- Jump the SCS line with the HDS.
- Disconnect ECM/PCM connector A (44P).
- Check for continuity between ECT sensor 2 2P connector terminal No. 2 (No. 1)* and ECM/PCM connector terminal A33. '06 model '07-11 models Is there continuity? YES -Go to step 27 . NO -Repair open in the wire between the ECM/PCM (A33) and ECT sensor 2, then go to step 22 .
- Turn the ignition switch to LOCK (0).
- Replace ECT sensor 2 (see «ECT SENSOR 1 REPLACEMENT»(ref-355126-S41969456932010012000000) ).
- Reconnect all connectors.
- Turn the ignition switch to ON (II).
- Reset the ECM/PCM with the HDS.
- Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-255517-S24591238122007060300000) ).
- Check for Pending or Confirmed DTCs with the HDS. Is DTC P2185 indicated? YES -Check for poor connections or loose terminals at ECT sensor 2 and the ECM/PCM, then go to step 1 . NO -Troubleshooting is complete. If any other Pending or Confirmed DTCs are indicated, go to the «INDICATED DTC'S TROUBLESHOOTING»(ref-355126-S38482784232010012000000) .
- Reconnect all connectors.
- Update the ECM/PCM if it does not have the latest software (see «ECM/PCM UPDATE»(ref-355126-S21746322412010012000000) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-379879-S00676494072010121600000) ).
- Check for Pending or Confirmed DTCs with the HDS. Is DTC P2185 indicated? YES -Check for poor connections or loose terminals at ECT sensor 2 and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-379879-S00676494072010121600000) ), then recheck. If the ECM/PCM was substituted, go to step 1 . NO -If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(ref-355126-S35548339322010012000000) ). If any other Pending or Confirmed DTCs are indicated, go to the «INDICATED DTC'S TROUBLESHOOTING»(ref-355126-S38482784232010012000000) .
