DTC P2185: ECT Sensor 2 Circuit High Voltage Honda Civic VIII рестайлинг

Testing & Diagnostics 4 illustrations ~579 words

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 666

Scheme 666: DTC P2185: ECT Sensor 2 Circuit High Voltage

Scheme 667

Scheme 667

Scheme 668

Scheme 668

Scheme 669

Scheme 669
  1. Turn the ignition switch to ON (II).
  2. Check ECT SENSOR 2 in the DATA LIST with the HDS. Is about -40°F (-40°C) or less, or 4.92 V or more indicated? YES -Go to step 3. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at ECT sensor 2 and the ECM.
  3. Turn the ignition switch to LOCK (0).
  4. Disconnect the ECT sensor 2 2P connector.
  5. Connect ECT sensor 2 2P connector terminals No. 1 and No. 2 with a jumper wire.
  6. Turn the ignition switch to ON (II).
  7. Check ECT SENSOR 2 in the DATA LIST with the HDS. Is about -40°F (-40°C) or less, or 4.92 V or more indicated? YES -Go to step 8. NO -Go to step 20 .
  8. Turn the ignition switch to LOCK (0).
  9. Remove the jumper wire from the ECT sensor 2 2P connector.
  10. Turn the ignition switch to ON (II).
  11. Measure the voltage between ECT sensor 2 2P connector terminal No. 1 and body ground. Is there about 5 V? YES -Go to step 12. NO -Go to step 16 .
  12. Turn the ignition switch to LOCK (0).
  13. Jump the SCS line with the HDS.
  14. Disconnect ECM connector A (44P).
  15. Check for continuity between ECT sensor 2 2P connector terminal No. 2 and ECM connector terminal A9. Is there continuity? YES -Go to step 27 . NO -Repair open in the wire between the ECM (A9) and ECT sensor 2, then go to step 22 .
  16. Turn the ignition switch to LOCK (0).
  17. Jump the SCS line with the HDS.
  18. Disconnect ECM connector A (44P).
  19. Check for continuity between ECT sensor 2 2P connector terminal No. 1 and ECM connector terminal A33. Is there continuity? YES -Go to step 27 . NO -Repair open in the wire between the ECM (A33) and ECT sensor 2, then go to step 22 .
  20. Turn the ignition switch to LOCK (0).
  21. Replace ECT sensor 2 (see ECT SENSOR 2 REPLACEMENT ).
  22. Reconnect all connectors.
  23. Turn the ignition switch to ON (II).
  24. Reset the ECM with the HDS.
  25. Do the ECM idle learn procedure (see ECM IDLE LEARN PROCEDURE ).
  26. Check for Pending or Confirmed or DTCs with the HDS. Is DTC P2185 indicated? YES -Check for poor connections or loose terminals at ECT sensor 2 and the ECM, then go to step 1 . NO -Troubleshooting is complete. If any other Pending or Confirmed or DTCs are indicated, go to the INDICATED DTC'S TROUBLESHOOTING .
