M/T model
Note. For A/T model (see OUTPUT SHAFT (COUNTERSHAFT) SPEED SENSOR REPLACEMENT ).
Scheme 879
- Remove the air cleaner (see «AIR CLEANER ELEMENT INSPECTION/REPLACEMENT»(ref-255501-S41739307232007060300000) ).
- Disconnect the output shaft (countershaft) speed sensor 3P connector (A).
- Remove the output shaft (countershaft) speed sensor (B).
- Install the parts in the reverse order of removal with a new O-ring (C).
Scheme 880
- Remove the intake manifold (see «REMOVAL»(ref-255498-S00789553312007060300000) ).
- Disconnect the knock sensor 1P connector (A).
- Remove the knock sensor (B).
- Install the parts in the reverse order of removal.
Scheme 881
- Remove the cowl cover and the under-cowl panel (see «COWL COVER REPLACEMENT»(ref-255527-S15281345902007060300000) ).
- Disconnect the MAP sensor 3P connector (A).
- Remove the MAP sensor (B).
- Install the parts in the reverse order of removal with a new O-ring (C).
Scheme 882
- Disconnect the MAF sensor/I AT sensor 5P connector (A).
- Remove the bolts (B).
- Remove the MAF sensor/IAT sensor (C).
- Install the parts in the reverse order of removal with a new O-ring (D).
Scheme 883
- Drain the engine coolant (see «COOLANT REPLACEMENT»(ref-255494-S16435980892007060300000) ).
- Disconnect the ECT sensor 1 2P connector (A).
- Remove ECT sensor 1 (B).
- Install the parts in the reverse order of removal with a new O-ring (C), then refill the radiator with engine coolant (see «COOLANT REPLACEMENT»(ref-255494-S16435980892007060300000) ).
Scheme 884
- Drain the engine coolant (see «COOLANT REPLACEMENT»(ref-255494-S16435980892007060300000) ).
- Remove the splash shield; 2-door (see «2-DOOR»(ref-255547-S08422622832007060300000) ), 4-door (see «4-DOOR»(ref-255547-S03853715622007060300000) ).
- Disconnect the ECT sensor 2 2P connector (A).
- Remove ECT sensor 2 (B).
- Install the parts in the reverse order of removal with a new O-ring (C), then refill the radiator with engine coolant (see «COOLANT REPLACEMENT»(ref-255494-S16435980892007060300000) ).
- Install the splash shield; 2-door (see «2-DOOR»(ref-255547-S08422622832007060300000) ), 4-door (see «4-DOOR»(ref-255547-S03853715622007060300000) ).
Scheme 885
Scheme 886
Scheme 887
Scheme 888
- Remove the ECM/PCM (see «ECM/PCM REPLACEMENT»(ref-355126-S35548339322010012000000) ).
- Remove the under-hood fuse/relay box (see «POWER RELAY TEST»(ref-255512-S41789995632007060300000) ).
- Remove the screw (A).
- Turn the housing over, then remove the screw (A).
- Turn the housing over again. Using two flat-tip screwdrivers, release the tabs (A), and pry up the fuse/relay box base (B) from the fuse/relay box housing (C). NOTE: Make sure the terminals (D) are not bent or damaged.
- Remove the ELD (A).
- Install the parts in the reverse order of removal.
ECM/PCM Update
Special Tools Required
- Honda diagnostic system (HDS) tablet tester
- Honda interface module (HIM) and an iN workstation with the latest HDS software version
- HDS pocket tester
- GNA 600 and an iN workstation with the latest HDS software version
Any one of the above updating tools can be used.
Note. Make sure the HDS/iN work station has the latest HDS software version. Before you update the ECM/PCM, make sure the battery in the vehicle is fully charged, and connect a jumper battery (not a battery charger) to maintain system voltage. Never turn the ignition switch to ACC (I) or to LOCK (0) during the update. If there is a problem with the update, leave the ignition switch to ON (II). To prevent ECM/PCM damage, do not operate anything electrical (headlights, audio system, brakes, A/C, power windows, moonroof (if equipped), door locks, etc.) during the update. To ensure the latest program is installed, do an ECM/PCM update whenever the ECM/PCM is substituted or replaced. You cannot update an ECM/PCM with a program it already has. It will only accept a new program. High temperature in the engine compartment might cause the ECM/PCM to become too hot to run the update. If the engine was running before this procedure, open the hood, and cool the engine compartment. If you need to diagnose the Honda interface module (HIM) because the HIM's red (#3) light came on or was flashing during the update, leave the ignition switch in ON (II) when you disconnect the HIM from the data link connector (DLC). This will prevent ECM/PCM damage.
Scheme 889
- Turn the ignition switch to ON (II), but do not start the engine.
- Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
- Make sure the HDS communicates with the ECM/PCM. If it doesn't, go to the «DLC CIRCUIT TROUBLESHOOTING»(ref-355126-S36537043742010012000000) . If you are returning from the DLC circuit troubleshooting, skip steps 4 and 5 and clean the throttle body after updating the ECM/PCM (see «AIR CLEANER ELEMENT INSPECTION/REPLACEMENT»(ref-255501-S41739307232007060300000) ).
- Select the INSPECTION MENU with the HDS.
- Select the ETCS TEST, then select the TP POSITION CHECK, and follow the HDS screen prompts. NOTE: If the TP POSITION CHECK indicates FAILED, continue this procedure.
- Exit the HDS diagnostic system, then select the update mode, and follow the screen prompts to update the ECM/PCM.
- If the software in the ECM/PCM is the latest, disconnect the HDS/HIM from the DLC, and go back to the procedure that you were doing. If the software in the ECM/PCM is not the latest, follow the instructions on the screen. If prompted to choose the PGM-FI system or the A/T system (A/T), make sure you update both. NOTE: If the ECM/PCM update system requires you to cool the ECM/PCM, follow the instructions on the screen. If you have a problem during the update (programming takes over 15 minutes, status bar goes over 100 %, D (A/T) or immobilizer indicator flashes, HDS tablet freezes, etc.), follow these steps to minimize the chance of damaging the ECM/PCM: Leave the ignition switch in ON (II). Connect a jumper battery (do not connect a battery charger). Shut down the HDS. Disconnect the HDS from the DLC. Reboot the HDS. Reconnect the HDS to the DLC, and do the update again.
- If the TP POSITION CHECK failed in step 5 , clean the throttle body (see «THROTTLE BODY CLEANING»(ref-255501-S10490593562007060300000) ).
- Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-255517-S24591238122007060300000) ).
- Do the CKP pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-379879-S24507253742010121600000) ).
