Automatic Transaxle System Diagnosis - Except Hev: Specifications Kia Optima III

Specification

SHIFT LEVER POSITIONS CHART

Scheme 245

Scheme 246

Scheme 247

Scheme 248

Scheme 249

Scheme 250

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "OFF".
3. Select "Current Data" mode and monitor "Inhibitor switch" parameter.
4. Change a shift lever from P-range to D-range.
5. Is the Inhibitor switch value changed in specification? YES Fault is intermittent caused by poor contact of PCM/TCM and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S07305412472011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S04562789422011101500000) procedure.

SHIFT LEVER POSITIONS CHART

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

Scheme 256

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "OFF".
3. Select "Current Data" mode and monitor "Inhibitor switch" parameter.
4. Change a shift lever from P-range to D-range.
5. Is the Inhibitor switch value changed in specification? YES Fault is intermittent caused by poor contact of PCM/TCM and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S02640737502011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S04814448682011101500000) procedure.

OIL TEMPERATURE SENSOR SPECIFICATIONS

Scheme 257

Scheme 258

Scheme 259

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Select "Current Data" mode and monitor "Oil temperature sensor" parameter. Specification : Increasing Gradually
4. Is the Oil temperature sensor within specification? YES Fault is intermittent caused by poor contact of PCM/TCM and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S36200475002011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S23025390432011101500000) procedure.

OIL TEMPERATURE SENSOR SPECIFICATIONS

Scheme 260

Scheme 261

Scheme 262

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Select "Current Data" mode and monitor "Oil temperature sensor" parameter. Specification : Increasing Gradually
4. Is the Oil temperature sensor within specification? YES Fault is intermittent caused by poor contact of PCM/TCM and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S14068257142011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S41256888722011101500000) procedure.

OUTPUT VOLTAGE SPECIFICATIONS

Scheme 263

Scheme 264

Scheme 265

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Select "Current Data" mode and monitor "Input speed sensor (PG-A)" parameter.
4. Driving above 20 Km/h. Specification : Increasing Gradually
5. Is measured "Input speed sensor" value within specification? YES Fault is intermittent caused by poor contact between TCM and Sensor, and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S32920705852011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S10474194072011101500000) procedure.

Operating step table at each status

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H)

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H)

Scheme 276

OUTPUT VOLTAGE SPECIFICATIONS

Scheme 277

Scheme 278

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

Scheme 289

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Select "Current Data" mode and monitor "Output speed sensor (PG-B)" parameter.
4. Driving above 20 Km/h. Specification : Increasing Gradually
5. Is measured "Output speed sensor" value within specification? YES Fault is intermittent caused by poor contact between TCM and Sensor, and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S11501899462011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S09771452482011101500000) procedure.

Operating step table at each status

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H)

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H)

Scheme 290

Scheme 291

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Select "Current Data" mode and monitor "Engine speed, Input speed sensor (PG-A), Output speed sensor (PG-B) and Gear position" parameter.
4. Disconnect Inhibitor switch for locked into 3rd gear and do "Stall Test". Specification : 2200 ~ 2900 engine RPM Operating step table at each status OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H) Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P (1) (1) (1) (1) 1st (1) (2) (1) 2nd (1) (1) (1) 3rd (1) (1) 4th (1) 5th (1) (1) 6th (1) (1) (1) L (1) (1) REV (1) (1) (2) (1) (1) Connected status (2) Connected at Vehicle speed above 8 km/h OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H) Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • (1) • D2 • • D3 • • D4 • • D5 • • D6 • • (1) Operated at Vehicle speed under 5 km/h NOTE: The process of "Stall Test" and Cause at D-RANGE 3RD SPEED The process of "Stall Test" Warm engine enough. Disconnect valve body for locked into 3rd gear and Measure the highest engine speed by full accelerating. * If slip is happened at D-RANGE 3RD SPEED, then It must be detected by stall test at D-RANGE 3RD SPEED. Cause If there isn't mechanical fault in Transmission then the toque converter absorb all slips. So only engine speed value is changed but input/output speed sensor value is zero by wheel locking. If D-RANGE 3RD SPEED is fault then input speed sensor has some value at above status. If Output speed sensor value isn't zero, cause by not enough braking, so Do test again with full braking.
5. Is measured value within specification? YES Go to «SIGNAL CIRCUIT INSPECTION»(ref-429652-S19727005102011101500000) procedure. NO Go to «COMPONENT INSPECTION»(ref-429652-S39041307592011101500000) procedure.

Scheme 292

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Select "Current Data" mode and monitor "Engine speed, Input speed sensor (PG-A), Output speed sensor (PG-B) and Gear position" parameter used select option.
4. Engine speed up to about 2000 RPM and check Input speed (PG-A) & Output speed (PG-B) are within specific at 3rd speed of gear. Specification Output speed>(input speed+200rpm)/3rd. gear ratio Output speed<(input speed-200rpm)/3rd. gear ratio
5. Are measured Input speed (PG-A) & Output speed (PG-B) within specification? YES Go to «COMPONENT INSPECTION»(ref-429652-S39041307592011101500000) procedure. NO Check there are electrical noise at Input/output speed and Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S31990522672011101500000) procedure.

Scheme 293

Scheme 294

1. Connect oil pressure gage at "UD brake" port and "3/5/R brake" port.
2. Engine ON.
3. Driving with 3rd speed of gear at sports mode.
4. Check by below specification table. Specification : See illustration below. * Above specification value can be different by vehicle model/measured variation.
5. Is measured oil pressure value within specification? YES Repair automatic transmission and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S31990522672011101500000) procedure. NO Repair automatic transmission (valve body) and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S31990522672011101500000) procedure.

Operating step table at each status

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H)

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H)

Scheme 295

Scheme 296

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Select "Current Data" mode and monitor "Engine speed, Input speed sensor (PG-A), Output speed sensor (PG-B) and Gear position" parameter.
4. Disconnect solenoid valve for locked into 4th gear and do "Stall Test". Specification : 2200 ~ 2900 engine RPM Operating step table at each status OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H) Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P (1) (1) (1) (1) 1st (1) (2) (1) 2nd (1) (1) (1) 3rd (1) (1) 4th (1) 5th (1) (1) 6th (1) (1) (1) L (1) (1) REV (1) (1) (2) (1) (1) Connected status (2) Connected at Vehicle speed above 8 km/h OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H) Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • (1) • D2 • • D3 • • D4 • • D5 • • D6 • • (1) Operated at Vehicle speed under 5 km/h NOTE: The process of "Stall Test" and Cause at D-RANGE 4TH SPEED The process of "Stall Test" Warm engine enough. Disconnect solenoid valve connector for locked into 4th gear and Measure the highest engine speed by full accelerating. * If slip is happened at D-RANGE 4TH SPEED, then It must be detected by stall test at D-RANGE 4TH SPEED. Cause If there isn't mechanical fault in Transmission then the toque converter absorb all slips. So only engine speed value is changed but input/output speed sensor value is zero by wheel locking. If D-RANGE 4TH SPEED is fault then input speed sensor has some value at above status. If Output speed sensor value isn't zero, cause by not enough braking, so Do test again with full braking.
5. Is measured value within specification? YES Go to «SIGNAL CIRCUIT INSPECTION»(ref-429652-S16150372932011101500000) procedure. NO Go to «COMPONENT INSPECTION»(ref-429652-S25645113932011101500000) procedure.

Scheme 297

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Select "Current Data" mode and monitor "Engine speed, Input speed sensor (PG-A), Output speed sensor (PG-B) and Gear position" parameter used select option.
4. Engine speed up to about 2000 RPM and check Input speed (PG-A) & Output speed (PG-B) are within specific at 4th speed of gear. Specification Output speed>(input speed+200rpm)/4th. gear ratio Output speed<(input speed-200rpm)/4th. gear ratio
5. Are measured Input speed (PG-A) & Output speed (PG-B) within specification? YES Go to «COMPONENT INSPECTION»(ref-429652-S25645113932011101500000) procedure. NO Check there are electrical noise at Input/output speed and Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S04742105982011101500000) procedure.

Scheme 298

Scheme 299

1. Connect oil pressure gage at "UD brake" port and "OD Clutch" port.
2. Engine ON.
3. Driving with 4th speed of gear at sports mode.
4. Check by below specification table. Specification : See illustration below. * Above specification value can be different by vehicle model/measured variation.
5. Is measured oil pressure value within specification? YES Repair automatic transmission and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S04742105982011101500000) procedure. NO Repair automatic transmission (valve body) and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S04742105982011101500000) procedure.

Operating step table at each status

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H)

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H)

Scheme 300

Operating step table at each status

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H)

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H)

Scheme 301

Scheme 302

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Select "Current Data" mode and monitor "Engine speed, Input speed sensor (PG-A), Output speed sensor (PG-B) and Gear position" parameter.
4. Do a stall test at 1st speed of gear. Specification : 2200 ~ 2900 engine RPM Operating step table at each status OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H) Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P (1) (1) (1) (1) 1st (1) (2) (1) 2nd (1) (1) (1) 3rd (1) (1) 4th (1) 5th (1) (1) 6th (1) (1) (1) L (1) (1) REV (1) (1) (2) (1) (1) Connected status (2) Connected at Vehicle speed above 8 km/h OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H) Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • (1) • D2 • • D3 • • D4 • • D5 • • D6 • • (1) Operated at Vehicle speed under 5 km/h NOTE: The process of "Stall Test" and Cause at D-RANGE 1ST SPEED The process of "Stall Test" Warm engine enough. Measure the highest engine speed by full accelerating at D-RANGE 1ST SPEED. * If slip is happened at D-RANGE 1ST SPEED, then It must be detected by stall test at D-RANGE 1ST SPEED. Cause If there isn't mechanical fault in Transmission then the toque converter absorb all slips. So only engine speed value is changed but input/output speed sensor value is zero by wheel locking. If D-RANGE 1ST SPEED is fault then input speed sensor has some value at above status. If Output speed sensor value isn't zero, cause by not enough braking, so Do test again with full braking.
5. Is measured value within specification? YES Go to «SIGNAL CIRCUIT INSPECTION»(ref-429652-S29904532562011101500000) procedure. NO Go to «COMPONENT INSPECTION»(ref-429652-S08741318592011101500000) procedure.

Scheme 303

1. Connect scantool to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Select "Current Data" mode and monitor "Engine speed, Input speed sensor (PG-A), Output speed sensor (PG-B) and Gear position" parameter used select option.
4. Engine speed up to about 2000 RPM and check Input speed (PG-A) & Output speed (PG-B) are within specific at 1st speed of gear. Specification : Output speed<(input speed-200rpm)/1st. gear ratio
5. Are measured Input speed (PG-A) & Output speed (PG-B) within specification? YES Go to «COMPONENT INSPECTION»(ref-429652-S08741318592011101500000) procedure. NO Check there are electrical noise at Input/output speed and Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S08720122222011101500000) procedure.

Scheme 304

Scheme 305

1. Connect oil pressure gage at "UD" port and "L/R" port.
2. Engine ON.
3. Driving with 1st speed of gear at sports mode.
4. Check by below specification table. Specification : See illustration below. * Above specification value can be different by vehicle model/measured variation.
5. Is measured oil pressure value within specification? YES Repair automatic transmission and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S08720122222011101500000) procedure. NO Repair automatic transmission (valve body) and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S08720122222011101500000) procedure.

Operating step table at each status

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H)

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H)

Scheme 306

1. Supplied pressure 5.5 kgf/cm 2 (Controlled pressure area 0~5.5)
2. Working temperature : -40°C~150°C
3. Internal resistance : 5.1 ± 0.3 ohms (25°C normal temperature)
4. Hysteresis : 0.3 kgf/cm 2

Scheme 307

Scheme 308

Scheme 309

Scheme 310

Scheme 311

Scheme 312

* Working above 3rd speed, but it may be working or not by driving variation at 3rd speed.

Scheme 313

Scheme 314

Scheme 315

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Scheme 320

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Select "Current Data" mode and monitor "Torque converter clutch" parameter. Specification : See below data
5. Is Torque converter clutch value within specification? YES Fault is intermittent caused by poor contact of PCM/TCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S26110430452011101500000) procedure. NO Go to «COMPONENT INSPECTION»(ref-429652-S05243811482011101500000) procedure.

1. Working temperature : -40°C~150°C
2. Internal resistance : 5.1 ± 0.3 ohms (25°C normal temperature)

Scheme 321

Scheme 322

Scheme 323

Scheme 324

Scheme 325

Scheme 326

* Working above 3rd speed, but it may be working or not by driving variation at 3rd speed.

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

Scheme 332

Scheme 333

Scheme 334

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Select "Current Data" mode and monitor "Torque converter clutch" parameter.
5. Is Torque converter clutch value within specification? YES Fault is intermittent caused by poor contact of PCM/TCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S16073353722011101500000) procedure. NO Go to «COMPONENT INSPECTION»(ref-429652-S29399561502011101500000) procedure.

1. Working temperature : -40°C~150°C
2. Internal resistance : 5.1 ± 0.3 ohms (25°C normal temperature)

Scheme 335

Scheme 336

Scheme 337

Scheme 338

Scheme 339

Scheme 340

Scheme 341

Scheme 342

Scheme 343

Scheme 344

Scheme 345

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Select "Current Data" mode and monitor "Pressure Control Solenoid Valve" parameter. Specification : See below data
5. Is Pressure Control Solenoid Valve within specification? YES Fault is intermittent caused by poor contact of PCM/TCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S00142794652011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S13557914462011101500000) procedure.

Operating step table at each status

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H)

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H)

1. Working temperature : -40°C~150°C
2. Internal resistance : 5.1 ± 0.3 ohms (25°C normal temperature)

Scheme 346

Scheme 347

Scheme 348

Scheme 349

Scheme 350

Scheme 351

Scheme 352

Scheme 353

Scheme 354

Scheme 355

Scheme 356

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Select "Current Data" mode and monitor "Shift Control Solenoid Valve (UD-VFS)" parameter current value. Specification : See below data Operating step table at each status OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H) Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P (1) (1) (1) (1) 1st (1) (2) (1) 2nd (1) (1) (1) 3rd (1) (1) 4th (1) 5th (1) (1) 6th (1) (1) (1) L (1) (1) EV (1) (1) (2) (1) (1) Connected status (2) Connected at Vehicle speed above 8 km/h OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H) Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • (1) • D2 • • D3 • • D4 • • D5 • • D6 • • (1) Operated at Vehicle speed under 5 km/h
5. Is Shift Control Solenoid Valve (UD-VFS) within specification? YES Fault is intermittent caused by poor contact of PCM/TCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S03729485982011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S31316427392011101500000) procedure.

Operating step table at each status

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H)

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H)

1. Working temperature : -40°C~150°C
2. Internal resistance : 5.1 ± 0.3 ohms (25°C normal temperature)

Scheme 357

Scheme 358

Scheme 359

Scheme 360

Scheme 361

Scheme 362

Scheme 363

Scheme 364

Scheme 365

Scheme 366

Scheme 367

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Select "Current Data" mode and monitor "Shift Control Solenoid Valve (26/B-VFS)" parameter current value. Specification : See below data Operating step table at each status OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H) Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P (1) (1) (1) (1) 1st (1) (2) (1) 2nd (1) (1) (1) 3rd (1) (1) 4th (1) 5th (1) (1) 6th (1) (1) (1) L (1) (1) REV (1) (1) (2) (1) (1) Connected status (2) Connected at Vehicle speed above 8 km/h OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H) Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • (1) • D2 • • D3 • • D4 • • D5 • • D6 • • (1) Operated at Vehicle speed under 5 km/h
5. Is Shift Control Solenoid Valve (26/B-VFS) within specification? YES Fault is intermittent caused by poor contact of PCM/TCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S14887189322011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S12930901142011101500000) procedure.

Operating step table at each status

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H)

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H)

1. Working temperature : -40°C~150°C
2. Internal resistance : 5.1 ± 0.3 ohms (25°C normal temperature)

Scheme 368

Scheme 369

Scheme 370

Scheme 371

Scheme 372

Scheme 373

Scheme 374

Scheme 375

Scheme 376

Scheme 377

Scheme 378

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Select "Current Data" mode and monitor "Shift Control Solenoid Valve (35R/C-VFS)" parameter current value. Specification : See below data Operating step table at each status OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H) Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P (1) (1) (1) (1) 1st (1) (2) (1) 2nd (1) (1) (1) 3rd (1) (1) 4th (1) 5th (1) (1) 6th (1) (1) (1) L (1) (1) REV (1) (1) (2) (1) (1) Connected status (2) Connected at Vehicle speed above 8 km/h OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H) Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • (1) • D2 • • D3 • • D4 • • D5 • • D6 • • (1) Operated at Vehicle speed under 5 km/h
5. Is Shift Control Solenoid Valve (26/B-VFS) within specification? YES Fault is intermittent caused by poor contact of PCM/TCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S05971215202011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S20988169872011101500000) procedure.

Operating step table at each status

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H)

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H)

1. Working temperature : -40°C~150°C
2. Internal resistance : 5.1 ± 0.3 ohms (25°C normal temperature)

Scheme 379

Scheme 380

Scheme 381

Scheme 382

Scheme 383

Scheme 384

Scheme 385

Scheme 386

Scheme 387

Scheme 388

Scheme 389

Scheme 390

Scheme 391

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Select "Current Data" mode and monitor "Shift Control Solenoid Valve (OD/C-VFS)" parameter current value. Specification : See below data Operating step table at each status OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H) Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P (1) (1) (1) (1) 1st (1) (2) (1) 2nd (1) (1) (1) 3rd (1) (1) 4th (1) 5th (1) (1) 6th (1) (1) (1) L (1) (1) REV (1) (1) (2) (1) (1) Connected status (2) Connected at Vehicle speed above 8 km/h OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H) Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • (1) • D2 • • D3 • • D4 • • D5 • • D6 • • (1) Operated at Vehicle speed under 5 km/h
5. Is Shift Control Solenoid Valve (OD/C-VFS) within specification? YES Fault is intermittent caused by poor contact of PCM/TCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S07033732652011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S37021577252011101500000) procedure.

Operating step table at each status

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H)

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H)

1. Working voltage: under 7.5v (Supplied pressure 5.0kgf/cm 2 , Oil temperature 85°C)
2. Release voltage: under 5.5v (Supplied pressure 5.0kgf/cm 2 , Oil temperature 85°C)
3. Release current: under 5.5v (Supplied pressure 0.51kgf/cm 2 , Oil temperature 85°C)
4. Internal resistance : 10 ~ 11 ohms (20°C)

Scheme 392

Scheme 393

Scheme 394

Scheme 395

Scheme 396

Scheme 397

Scheme 398

Scheme 399

Scheme 400

Scheme 401

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Select "Current Data" mode and monitor "Shift Control Solenoid Valve (SS-A)" parameter current value. Specification : See below data Operating step table at each status OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H) Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P (1) (1) (1) (1) 1st (1) (2) (1) 2nd (1) (1) (1) 3rd (1) (1) 4th (1) 5th (1) (1) 6th (1) (1) (1) L (1) (1) REV (1) (1) (2) (1) (1) Connected status (2) Connected at Vehicle speed above 8 km/h OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H) Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • (1) • D2 • • D3 • • D4 • • D5 • • D6 • • (1) Operated at Vehicle speed under 5 km/h
5. Is Shift Control Solenoid Valve (SS-A) within specification? YES Fault is intermittent caused by poor contact of PCM/TCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S31252173902011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S10302148622011101500000) procedure.

Operating step table at each status

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H)

OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H)

1. Working voltage: under 7.5v (Supplied pressure 5.0kgf/cm 2 , Oil temperature 85°C)
2. Release voltage: under 5.5v (Supplied pressure 5.0kgf/cm 2 , Oil temperature 85°C)
3. Release current: under 5.5v (Supplied pressure 0.51kgf/cm 2 , Oil temperature 85°C)
4. Internal resistance : 10 ~ 11 ohms (20°C)

Scheme 402

Scheme 403

Scheme 404

Scheme 405

Scheme 406

Scheme 407

Scheme 408

Scheme 409

Scheme 410

Scheme 411

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Driving 1st speed to 6th speed at D-range.
4. Select "Current Data" mode and monitor "Shift Control Solenoid Valve (SS-B)" parameter current value. Specification : See below data Operating step table at each status OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED ABOVE 8 KM/H) Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P (1) (1) (1) (1) 1st (1) (2) (1) 2nd (1) (1) (1) 3rd (1) (1) 4th (1) 5th (1) (1) 6th (1) (1) (1) L (1) (1) REV (1) (1) (2) (1) (1) Connected status (2) Connected at Vehicle speed above 8 km/h OPERATING STEP CHART AT EACH STATUS (VEHICLE SPEED UNDER 5 KM/H) Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • (1) • D2 • • D3 • • D4 • • D5 • • D6 • • (1) Operated at Vehicle speed under 5 km/h
5. Is Shift Control Solenoid Valve (SS-B) within specification? YES Fault is intermittent caused by poor contact of PCM/TCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «VERIFICATION OF VEHICLE REPAIR»(ref-429652-S21189426342011101500000) procedure. NO Go to «TERMINAL & CONNECTOR INSPECTION»(ref-429652-S22548082392011101500000) procedure.
