Automatic Transaxle Control System - Hev: Specifications Kia Optima III

Automatic Trans 17 illustrations ~148 words

Specifications

Type: Negative Thermal Coefficient Type

Temp.(°C)°FResistance (kohms)
(-40)-4046.8
(-20)-4.015.6
(0)32.05.88
(20)68.02.51
(40)104.01.17
(60)140.00.59
(80)176.00.32
(100)212.00.18
(120)248.00.11
(140)284.00.07
(165)329.00.04

Scheme 669

Scheme 669
Scheme 669

Scheme 670

Scheme 670: Circuit Diagram
Scheme 670: Circuit Diagram

Type: Hall effect sensor

Operation condition (°C)°F((-)40 ~ 150)) -40 ~ 302
Air gap(mm)in.(0.95~1.65) 0.037 ~ 0.065
Output voltage(V)High1.18 ~ 1.68
Low0.59 ~ 0.84

Scheme 671

Scheme 671: Circuit Diagram
Scheme 671: Circuit Diagram

Scheme 672

Scheme 672: Signal Waveform
Scheme 672: Signal Waveform

Scheme 673

Scheme 673
Scheme 673

Type: Hall effect sensor

Operation condition (°C)°F((-)40 ~ 150)) -40 ~ 302
Air gap(mm)in.(0.25 ~ 1.9) 0.00984 ~ 0.0748
Output voltageHigh1.18 ~ 1.68
Low0.59 ~ 0.84

Scheme 674

Scheme 674: Circuit Diagram
Scheme 674: Circuit Diagram

Scheme 675

Scheme 675: Signal Waveform
Scheme 675: Signal Waveform

Scheme 676

Scheme 676
Scheme 676

Direct control VFS [E/C]

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value (mA)50~850
Internal resistance (ohms)5.1

Scheme 677

Scheme 677: Circuit Diagram
Scheme 677: Circuit Diagram

Direct control VFS[26/B]

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

Scheme 678

Scheme 678: Circuit Diagram
Scheme 678: Circuit Diagram

Direct control VFS[LINE Pressure]

Control type: Normal high type

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

Scheme 679

Scheme 679: Circuit Diagram
Scheme 679: Circuit Diagram

Direct control VFS[35R/C]

Control type: Normal high type

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

Scheme 680

Scheme 680: Circuit Diagram
Scheme 680: Circuit Diagram

Direct control VFS [UD/B]

Control type: Normal high type

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

Scheme 681

Scheme 681: Circuit Diagram
Scheme 681: Circuit Diagram

Direct control VFS [OD/C]

Control type: Normal high type

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

Scheme 682

Scheme 682: Circuit Diagram
Scheme 682: Circuit Diagram

ON/OFF Solenoid Valve(SS-A, SS-B)

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10 ~ 11

Scheme 683

Scheme 683: Circuit Diagram
Scheme 683: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10 ~ 11

Scheme 684

Scheme 684: Circuit Diagram
Scheme 684: Circuit Diagram

Type: Combination of output signals from 4 terminals

Power supply (V)12
Output typeCombination of output signals

TERMINAL OUTPUT SIGNALS SPECIFICATIONS

PP-RRR-NNN-DD
Signal "1"12V12V00000
Signal "2"012V12V12V000
Signal "3"00012V12V12V0
Signal "4"0000012V12V

SIGNAL CODE

Scheme 685

Scheme 685: Circuit Diagram
Scheme 685: Circuit Diagram
