Automatic Transaxle Control System (A6MF2) - 2.4L: Specifications Kia Optima III

Automatic Trans 16 illustrations ~228 words

Specifications

  1. Type: Negative Thermal Coefficient Type
Temp ((°C) °F)Resistance (kohms)
(-40)-4048.1
(-20)-4.015.6
(0)32.05.88
(20)68.02.51
(40)104.01.11
(60)140.00.61
(80)176.00.32
(100)212.00.18
(120)248.00.10
(140)284.00.06
(150)302.00.05

TEMPERATURE AND RESISTANCE REFERENCE CHART

Scheme 161

Scheme 161

Scheme 162

Scheme 162: Circuit Diagram
  1. Type: Hall effect sensor
Operation condition (°C (°F))((-)40~150)) -40~302
Air gap (mm) in.(0.95~1.65)0.037~0.065
Output voltage (V)High1.18~1.68
Low0.59~0.84

HALL EFFECT SENSOR SPECIFICATIONS

Scheme 163

Scheme 163: Circuit Diagram

Scheme 164

Scheme 164: Signal Waveform

Scheme 165

Scheme 165

(Scheme 164)) Input/Output speed sensor at low speed

(Scheme 165)) Input/Output speed sensor at high speed

  1. Type: Hall effect sensor
Operation condition (°C (°F))((-)40~150)) -40~302
Air gap (mm) in.(0.55~1) 0.0217~0.0394
Output voltageHigh1.18~1.68
Low0.59~0.84

HALL EFFECT SENSOR SPECIFICATIONS

Scheme 166

Scheme 166: Circuit Diagram

Scheme 167

Scheme 167: Signal Waveform

Scheme 168

Scheme 168

Direct control VFS (T/CON)

  1. Control type : Normal low type
Control Pressure kpa(kgf/cm 2 , psi)9.81~500.14 (0.1~5.1, 1.42~72.54)
Current value (mA)50~850
Internal resistance (ohms)5.1

DIRECT CONTROL VFS (T/CON) SPECIFICATIONS

Scheme 169

Scheme 169: Circuit Diagram

Direct control VFS (26/B)

  1. Control type : Normal low type
Control Pressure kPa (kgf/cm 2 , psi)9.81~500.14 (0.1~5.1, 1.42~72.54)
Current value (mA)50~850
Internal resistance (ohms)5.1

DIRECT CONTROL VFS (26/B) SPECIFICATIONS

Scheme 170

Scheme 170: Circuit Diagram

Direct control VFS (LINE Pressure)

  1. Control type : Normal low type
Control Pressure kPa (kgf/cm 2 , psi)500.14~9.81 (5.1~0.1, 72.54~1.42)
Current value (mA)50~850
Internal resistance (ohms)5.1

DIRECT CONTROL VFS (LINE PRESSURE) SPECIFICATIONS

Scheme 171

Scheme 171: Circuit Diagram

Direct control VFS (35R/C)

  1. Control type : Normal low type
Control Pressure kPa (kgf/cm 2 , psi)500.14~9.81 (5.1~0.1, 72.54~1.42)
Current value (mA)50~850
Internal resistance (ohms)5.1

DIRECT CONTROL VFS (35R/C) SPECIFICATIONS

Scheme 172

Scheme 172: Circuit Diagram

Direct control VFS (35R/C)

  1. Control type : Normal low type
Control Pressure kPa (kgf/cm 2 , psi)500.14~9.81 (5.1~0.1, 72.54~1.42)
Current value (mA)50~850
Internal resistance (ohms)5.1

DIRECT CONTROL VFS (35R/C) SPECIFICATIONS

Scheme 173

Scheme 173: Circuit Diagram

Direct control VFS (35R/C)

  1. Control type : Normal low type
Control Pressure kPa (kgf/cm 2 , psi)500.14~9.81 (5.1~0.1, 72.54~1.42)
Current value (mA)50~850
Internal resistance (ohms)5.1

DIRECT CONTROL VFS (35R/C) SPECIFICATIONS

Scheme 174

Scheme 174: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

  1. Control type : Normal low type
Control pressure kPa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10~11

ON/OFF SOLENOID VALVE (SS-A, SS-B) SPECIFICATIONS

Scheme 175

Scheme 175: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

  1. Control type : Normal low type
Control pressure kPa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10~11

ON/OFF SOLENOID VALVE (SS-A, SS-B) SPECIFICATIONS

Scheme 176

Scheme 176: Circuit Diagram
  1. Type: Combination of output signals from 4 terminals
Power supply (V)12
Output typePin to Pin

INHIBITOR SWITCH SPECIFICATIONS
