Automatic Transaxle Control System - Hev: Removal & Installation Kia Optima III

Installation

In the case of the vehicle equipped with immobilizer or button engine start system, perform "Key Teaching" procedure together (Refer to " IMMOBILIZER LAMP " or "Button Engine Start System in BE group).

1. Installation is reverse of removal.

1. Installation is the reverse of removal.

Note. After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Adding automatic transaxle fluid. (Refer to "Hydraulic system(Fluid)" in this group.) Bleed air from the hybrid motor cooling system using GDS. (Refer to " HYBRID MOTOR " in HM group)

1. Installation is the reverse of removal.

Note. After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Adding automatic transaxle fluid. (Refer to "Hydraulic system(Fluid)" in this group.) Bleed air from the hybrid motor cooling system using GDS. (Refer to " HYBRID MOTOR " in HM group)

1. Installation is the reverse of removal.

Note. After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Adding automatic transaxle fluid. (Refer to "Hydraulic system(Fluid)" in this group.) Bleed air from the hybrid motor cooling system using GDS. (Refer to " HYBRID MOTOR " in HM group)

Removal

Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

1. Installation is the reverse of removal.

Note. When installing, apply the ATF oil or White Vaseline to the O-ring (A) to prevent damage during installation.

Scheme 724

After replacement or reinstallation procedure of the valve body assembly, must perform procedures below.

1. Adding automatic transaxle fluid. (Refer to "Hydraulic system(Fluid)" in this group.)
2. Bleed air from the hybrid motor cooling system using GDS.

(Refer to " HYBRID MOTOR " in HM group)

1. Installation is the reverse of removal.

Note. When installing, apply the ATF oil or White Vaseline to the O-ring (A) to prevent damage during installation. Adding automatic transaxle fluid. (Refer to "Hydraulic system(Fluid)" in this group.) Bleed air from the hybrid motor cooling system using GDS. (Refer to " HYBRID MOTOR " in HM group)

1. Installation is the reverse of removal.

Note. Bleed air from the hybrid motor cooling system using GDS. (Refer to " COOLANT " in HM group.)

Scheme 725

Scheme 726

Scheme 727

Scheme 728

1. Remove the center console assembly. (Refer to " «INTERIOR C»(ref-535752-S36089732432013031200000) " in BD group.)
2. Disconnect sports mode connector (A).
3. Remove the shift cable (B).
4. Remove the shift lever assembly (B) by removing the bolts (A-4ea). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.9 lb-ft)
5. Installation is the reverse of removal.

Note. Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.

Scheme 729

Scheme 730

Scheme 731

1. Remove the center console assembly. (Refer to " «INTERIOR C»(ref-535752-S36089732432013031200000) " in BD group.)
2. Remove the control cable (B).
3. Remove the control cable assembly in the vehicle after removing the nuts (B) and the retainer (A). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.9 lb-ft)
4. Remove the nut (C).
5. Remove the cable (B) from the bracket (A) at transaxle assembly side (Refer to " «AUTOMATIC TRANSAXLE»(ref-535716-S07341099932013031200000) " in this group).
6. Remove the control cable inside of cab.

1. Installation is the reverse of removal.

Note. Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.

Scheme 732

1. Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.
2. Connect room side shift lever and control cable.
3. Push cable to "F" direction shown to eliminate FREE PLAY.
4. Tighten adjusting nut (A). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.9 lb-ft)
5. After adjusting, check to be sure that this part operates as designed at each range of T/M side corresponding to each position of room lever.
