Automatic Transaxle System Diagnosis - Hev: Other Kia Optima III

Automatic Trans 52 illustrations ~6611 words

Verification of Vehicle Repair

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1248

Scheme 1248: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1249

Scheme 1249: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1250

Scheme 1250: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1251

Scheme 1251: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1252

Scheme 1252: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1253

Scheme 1253: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1254

Scheme 1254: Component Location

Monitor Scantool Data

Pass "Stall Test" caused by hard to test at D-RANGE 6TH SPEED, go to " VERIFICATION OF VEHICLE REPAIR " procedure.

Scheme 1255

Scheme 1255: Signal Circuit Inspection
  1. Connect scantool to Data Link Connector(DLC).
  2. Engine "ON".
  3. Select "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter used select option.
  4. Engine speed up to about 2000rpm and check Input speed(PG-A)&Output speed(PG-B) are within specific at 6th speed of gear. Specification: Output speed>(input speed+200rpm)/6th. gear ratio Output speed<(input speed-200rpm)/6th. gear ratio
  5. Are measured Input speed(PG-A)&Output speed(PG-B) within specific? YES Go to " «COMPONENT INSPECTION»(ref-535826-S31195202322013031200000) " procedure. NO Check there are electrical noise at Input/output speed and Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S23987923282013031200000) " procedure.

Scheme 1256

Scheme 1256: Component Inspection
  1. Connect oil pressure gage at "2/6 Brake" port and "OD Clutch" port.
  2. Engine ON.
  3. Driving with 6th speed of gear at sports mode.
  4. Check by below specific table. Specification : See below specific table Shift lever position RPM Solenoid current (mA) ON/OFF Solenoid Pressure (kgf/cm 2 ) UD/B OD/C 26-B 35R/C LP ENG-C SS-A SS-B UD/C OD/C 26/B 35R/C LR/B RED1 RED2 ENG/C D1 2500 0 852 0 852 0 852 OFF OFF 16.3±0.5 - 0.1 Under - - 5±0.3 5.5±0.3 16.3±0.5 ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 0.6~1.4 - - - - - - - ↑ ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 2.6~3.2 - - - - - - - ↑ ↑ 500 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 4.6~5.4 - - - - - - - ↑ EOP1300 0 852 0 852 0 352 ↑ ↑ - - - - - - - 1.0~1.8 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ - - - - - - - 2.4~3.0 D2 2500 0 852 852 852 0 852 OFF OFF 15~17.5 - 16.3±0.5 0.03~0.4 - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ 352 ↑ ↑ ↑ ↑ ↑ - - 0.96~1.7 - - - - - ↑ ↑ ↑ ↑ 452 ↑ ↑ ↑ ↑ ↑ - - 2.7~3.3 - - - - - ↑ ↑ ↑ ↑ 552 ↑ ↑ ↑ ↑ ↑ - - 4.6~5.6 - - - - - D3 ↑ 0 852 0 0 0 852 OFF OFF 15~17.5 0.03~0.4 - 16.3±0.5 0.03~0.4 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ - - - 0.4~1.2 - - - - ↑ ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ ↑ - - - 2.4~3.0 - - - - ↑ ↑ ↑ ↑ ↑ 500 ↑ ↑ ↑ ↑ - - - 4.3~5.1 - - - - D4 ↑ 0 0 0 852 0 852 OFF OFF 15~17.5 15~17.5 - - - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ - 0.6~1.4 - - - - - - ↑ ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ ↑ - 2.1~2.7 - - - - - - D5 ↑ 852 0 0 0 0 852 OFF ON 0.03~0.4 16.3±0.5 - 15~17.5 - 5±0.3 5.5±0.3 15~17.5 D6 ↑ 852 0 852 852 0 852 OFF OFF - 15~17.5 15~17.5 - - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ ↑ ↑ 400 ↑ ↑ ↑ - 12.5~13.5 - - - - - - ↑ ↑ ↑ ↑ ↑ ↑ 852 ↑ ↑ ↑ - 3.9~5.1 - - - - - - L ↑ 0 0 0 852 0 852 ON OFF 15~17.5 - - - 16.3±0.5 - - - ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Above 3.9 - - - Above 3.9 5±0.3 5.5±0.3 Above 3.9 ↑ EOP1100 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Above 4.7 - - - Above 4.7 5±0.3 5.5±0.3 Above 4.7 N ↑ 852 0 0 852 0 852 ON OFF - - - - Above 6.0 5±0.3 5.5±0.3 Above 6.0 R 2500 852 852 0 0 0 852 OFF ON - - - 15~17.5 15~17.5 5±0.3 5.5±0.3
  5. Is measured oil pressure value within specific? YES Repair automatic transmission and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S23987923282013031200000) " procedure. NO Repair automatic transmission(valve body) and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S23987923282013031200000) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1257

Scheme 1257: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1258

Scheme 1258: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1259

Scheme 1259: Component Location

Pass "Stall Test" caused by hard to test at D-RANGE 6TH SPEED, go to " VERIFICATION OF VEHICLE REPAIR " procedure.

Scheme 1260

Scheme 1260: Signal Circuit Inspection
  1. Connect scantool to Data Link Connector(DLC).
  2. Engine "ON".
  3. Select "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter used select option.
  4. Engine speed up to about 2000rpm and check Input speed(PG-A)&Output speed(PG-B) are within specific at 1st speed of gear. Specification: Output speed>(input speed+200rpm)/1th. gear ratio Output speed<(input speed-200rpm)/1th. gear ratio
  5. Are measured Input speed(PG-A)&Output speed(PG-B) within specific? YES Go to " «COMPONENT INSPECTION»(ref-535826-S21953006562013031200000) " procedure. NO Check there are electrical noise at Input/output speed and Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S31629818752013031200000) " procedure.

Scheme 1261

Scheme 1261: Component Inspection
  1. Connect oil pressure gage at "UD" port and "L/R" port.
  2. Engine ON.
  3. Driving with 1st speed of gear at sports mode.
  4. Check by below specific table. Specification : See below specific table Shift lever position RPM Solenoid current (mA) ON/OFF Solenoid Pressure (kgf/cm 2 ) UD/B OD/C 26-B 35R/C LP ENG-C SS-A SS-B UD/C OD/C 26/B 35R/C LR/B RED1 RED2 ENG/C D1 2500 0 852 0 852 0 852 OFF OFF 16.3±0.5 - 0.1 Under - - 5±0.3 5.5±0.3 16.3±0.5 ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 0.6~1.4 - - - - - - - ↑ ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 2.6~3.2 - - - - - - - ↑ ↑ 500 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 4.6~5.4 - - - - - - - ↑ EOP1300 0 852 0 852 0 352 ↑ ↑ - - - - - - - 1.0~1.8 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ - - - - - - - 2.4~3.0 D2 2500 0 852 852 852 0 852 OFF OFF 15~17.5 - 16.3±0.5 0.03~0.4 - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ 352 ↑ ↑ ↑ ↑ ↑ - - 0.96~1.7 - - - - - ↑ ↑ ↑ ↑ 452 ↑ ↑ ↑ ↑ ↑ - - 2.7~3.3 - - - - - ↑ ↑ ↑ ↑ 552 ↑ ↑ ↑ ↑ ↑ - - 4.6~5.6 - - - - - D3 ↑ 0 852 0 0 0 852 OFF OFF 15~17.5 0.03~0.4 - 16.3±0.5 0.03~0.4 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ - - - 0.4~1.2 - - - - ↑ ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ ↑ - - - 2.4~3.0 - - - - ↑ ↑ ↑ ↑ ↑ 500 ↑ ↑ ↑ ↑ - - - 4.3~5.1 - - - - D4 ↑ 0 0 0 852 0 852 OFF OFF 15~17.5 15~17.5 - - - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ - 0.6~1.4 - - - - - - ↑ ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ ↑ - 2.1~2.7 - - - - - - D5 ↑ 852 0 0 0 0 852 OFF ON 0.03~0.4 16.3±0.5 - 15~17.5 - 5±0.3 5.5±0.3 15~17.5 D6 ↑ 852 0 852 852 0 852 OFF OFF - 15~17.5 15~17.5 - - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ ↑ ↑ 400 ↑ ↑ ↑ - 12.5~13.5 - - - - - - ↑ ↑ ↑ ↑ ↑ ↑ 852 ↑ ↑ ↑ - 3.9~5.1 - - - - - - L ↑ 0 0 0 852 0 852 ON OFF 15~17.5 - - - 16.3±0.5 - - - ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Above 3.9 - - - Above 3.9 5±0.3 5.5±0.3 Above 3.9 ↑ EOP1100 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Above 4.7 - - - Above 4.7 5±0.3 5.5±0.3 Above 4.7 N ↑ 852 0 0 852 0 852 ON OFF - - - - Above 6.0 5±0.3 5.5±0.3 Above 6.0 R 2500 852 852 0 0 0 852 OFF ON - - - 15~17.5 15~17.5 5±0.3 5.5±0.3
  5. Is measured oil pressure value within specific? YES Repair automatic transmission and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S31629818752013031200000) " procedure. NO Repair automatic transmission(valve body) and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S31629818752013031200000) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1262

Scheme 1262: Component Location

Pass "Stall Test" caused by hard to test at D-RANGE 6TH SPEED, go to " VERIFICATION OF VEHICLE REPAIR " procedure.

Scheme 1263

Scheme 1263: Signal Circuit Inspection
  1. Connect scantool to Data Link Connector(DLC).
  2. Engine "ON".
  3. Select "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter used select option.
  4. Engine speed up to about 2000rpm and check Input speed(PG-A)&Output speed(PG-B) are within specific at 2th speed of gear. Specification: Output speed>(input speed+200rpm)/2th. gear ratio Output speed<(input speed-200rpm)/2th. gear ratio
  5. Are measured Input speed(PG-A)&Output speed(PG-B) within specific? YES Go to " «COMPONENT INSPECTION»(ref-535826-S06367725422013031200000) " procedure. NO Check there are electrical noise at Input/output speed and Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S22892874232013031200000) " procedure.

Scheme 1264

Scheme 1264: Component Inspection
  1. Connect oil pressure gage at "UD brake" port and "2/6 brake" port.
  2. Engine ON.
  3. Driving with 2nd speed of gear at sports mode.
  4. Check by below specific table. Specification : See below specific table Shift lever position RPM Solenoid current (mA) ON/OFF Solenoid Pressure (kgf/cm 2 ) UD/B OD/C 26-B 35R/C LP ENG-C SS-A SS-B UD/C OD/C 26/B 35R/C LR/B RED1 RED2 ENG/C D1 2500 0 852 0 852 0 852 OFF OFF 16.3±0.5 - 0.1 Under - - 5±0.3 5.5±0.3 16.3±0.5 ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 0.6~1.4 - - - - - - - ↑ ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 2.6~3.2 - - - - - - - ↑ ↑ 500 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 4.6~5.4 - - - - - - - ↑ EOP1300 0 852 0 852 0 352 ↑ ↑ - - - - - - - 1.0~1.8 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ - - - - - - - 2.4~3.0 D2 2500 0 852 852 852 0 852 OFF OFF 15~17.5 - 16.3±0.5 0.03~0.4 - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ 352 ↑ ↑ ↑ ↑ ↑ - - 0.96~1.7 - - - - - ↑ ↑ ↑ ↑ 452 ↑ ↑ ↑ ↑ ↑ - - 2.7~3.3 - - - - - ↑ ↑ ↑ ↑ 552 ↑ ↑ ↑ ↑ ↑ - - 4.6~5.6 - - - - - D3 ↑ 0 852 0 0 0 852 OFF OFF 15~17.5 0.03~0.4 - 16.3±0.5 0.03~0.4 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ - - - 0.4~1.2 - - - - ↑ ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ ↑ - - - 2.4~3.0 - - - - ↑ ↑ ↑ ↑ ↑ 500 ↑ ↑ ↑ ↑ - - - 4.3~5.1 - - - - D4 ↑ 0 0 0 852 0 852 OFF OFF 15~17.5 15~17.5 - - - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ - 0.6~1.4 - - - - - - ↑ ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ ↑ - 2.1~2.7 - - - - - - D5 ↑ 852 0 0 0 0 852 OFF ON 0.03~0.4 16.3±0.5 - 15~17.5 - 5±0.3 5.5±0.3 15~17.5 D6 ↑ 852 0 852 852 0 852 OFF OFF - 15~17.5 15~17.5 - - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ ↑ ↑ 400 ↑ ↑ ↑ - 12.5~13.5 - - - - - - ↑ ↑ ↑ ↑ ↑ ↑ 852 ↑ ↑ ↑ - 3.9~5.1 - - - - - - L ↑ 0 0 0 852 0 852 ON OFF 15~17.5 - - - 16.3±0.5 - - - ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Above 3.9 - - - Above 3.9 5±0.3 5.5±0.3 Above 3.9 ↑ EOP1100 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Above 4.7 - - - Above 4.7 5±0.3 5.5±0.3 Above 4.7 N ↑ 852 0 0 852 0 852 ON OFF - - - - Above 6.0 5±0.3 5.5±0.3 Above 6.0 R 2500 852 852 0 0 0 852 OFF ON - - - 15~17.5 15~17.5 5±0.3 5.5±0.3
  5. Is measured oil pressure value within specific? YES Repair automatic transmission and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S22892874232013031200000) " procedure. NO Repair automatic transmission(valve body) and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S22892874232013031200000) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1265

Scheme 1265: Component Location

Pass "Stall Test" caused by hard to test at D-RANGE 6TH SPEED, go to " VERIFICATION OF VEHICLE REPAIR " procedure.

Scheme 1266

Scheme 1266: Signal Circuit Inspection
  1. Connect scantool to Data Link Connector(DLC).
  2. Engine "ON".
  3. Select "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter used select option.
  4. Engine speed up to about 2000rpm and check Input speed(PG-A)&Output speed(PG-B) are within specific at 3th speed of gear. Specification: Output speed>(input speed+200rpm)/3th. gear ratio Output speed<(input speed-200rpm)/3th. gear ratio
  5. Are measured Input speed(PG-A)&Output speed(PG-B) within specific? YES Go to " «COMPONENT INSPECTION»(ref-535826-S35754182922013031200000) " procedure. NO Check there are electrical noise at Input/output speed and Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S25405091002013031200000) " procedure.

Scheme 1267

Scheme 1267: Component Inspection
  1. Connect oil pressure gage at "UD brake" port and "3/5/R brake" port.
  2. Engine ON.
  3. Driving with 3rd speed of gear at sports mode.
  4. Check by below specific table. Specification : See below specific table Shift lever position RPM Solenoid current (mA) ON/OFF Solenoid Pressure (kgf/cm 2 ) UD/B OD/C 26-B 35R/C LP ENG-C SS-A SS-B UD/C OD/C 26/B 35R/C LR/B RED1 RED2 ENG/C D1 2500 0 852 0 852 0 852 OFF OFF 16.3±0.5 - 0.1 Under - - 5±0.3 5.5±0.3 16.3±0.5 ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 0.6~1.4 - - - - - - - ↑ ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 2.6~3.2 - - - - - - - ↑ ↑ 500 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 4.6~5.4 - - - - - - - ↑ EOP1300 0 852 0 852 0 352 ↑ ↑ - - - - - - - 1.0~1.8 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ - - - - - - - 2.4~3.0 D2 2500 0 852 852 852 0 852 OFF OFF 15~17.5 - 16.3±0.5 0.03~0.4 - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ 352 ↑ ↑ ↑ ↑ ↑ - - 0.96~1.7 - - - - - ↑ ↑ ↑ ↑ 452 ↑ ↑ ↑ ↑ ↑ - - 2.7~3.3 - - - - - ↑ ↑ ↑ ↑ 552 ↑ ↑ ↑ ↑ ↑ - - 4.6~5.6 - - - - - D3 ↑ 0 852 0 0 0 852 OFF OFF 15~17.5 0.03~0.4 - 16.3±0.5 0.03~0.4 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ - - - 0.4~1.2 - - - - ↑ ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ ↑ - - - 2.4~3.0 - - - - ↑ ↑ ↑ ↑ ↑ 500 ↑ ↑ ↑ ↑ - - - 4.3~5.1 - - - - D4 ↑ 0 0 0 852 0 852 OFF OFF 15~17.5 15~17.5 - - - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ - 0.6~1.4 - - - - - - ↑ ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ ↑ - 2.1~2.7 - - - - - - D5 ↑ 852 0 0 0 0 852 OFF ON 0.03~0.4 16.3±0.5 - 15~17.5 - 5±0.3 5.5±0.3 15~17.5 D6 ↑ 852 0 852 852 0 852 OFF OFF - 15~17.5 15~17.5 - - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ ↑ ↑ 400 ↑ ↑ ↑ - 12.5~13.5 - - - - - - ↑ ↑ ↑ ↑ ↑ ↑ 852 ↑ ↑ ↑ - 3.9~5.1 - - - - - - L ↑ 0 0 0 852 0 852 ON OFF 15~17.5 - - - 16.3±0.5 - - - ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Above 3.9 - - - Above 3.9 5±0.3 5.5±0.3 Above 3.9 ↑ EOP1100 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Above 4.7 - - - Above 4.7 5±0.3 5.5±0.3 Above 4.7 N ↑ 852 0 0 852 0 852 ON OFF - - - - Above 6.0 5±0.3 5.5±0.3 Above 6.0 R 2500 852 852 0 0 0 852 OFF ON - - - 15~17.5 15~17.5 5±0.3 5.5±0.3
  5. Is measured oil pressure value within specific? YES Repair automatic transmission and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S25405091002013031200000) " procedure. NO Repair automatic transmission(valve body) and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S25405091002013031200000) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1268

Scheme 1268: Component Location

Pass "Stall Test" caused by hard to test at D-RANGE 6TH SPEED, go to " VERIFICATION OF VEHICLE REPAIR " procedure.

Scheme 1269

Scheme 1269: Signal Circuit Inspection
  1. Connect scantool to Data Link Connector(DLC).
  2. Engine "ON".
  3. Select "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter used select option.
  4. Engine speed up to about 2000rpm and check Input speed(PG-A)&Output speed(PG-B) are within specific at 4th speed of gear. Specification: Output speed>(input speed+200rpm)/4th. gear ratio Output speed<(input speed-200rpm)/4th. gear ratio
  5. Are measured Input speed(PG-A)&Output speed(PG-B) within specific? YES Go to " «COMPONENT INSPECTION»(ref-535826-S05642076702013031200000) " procedure. NO Check there are electrical noise at Input/output speed and Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S41223287312013031200000) " procedure.

Scheme 1270

Scheme 1270: Component Inspection
  1. Connect oil pressure gage at "UD brake" port and "OD Clutch" port.
  2. Engine ON.
  3. Driving with 4th speed of gear at sports mode.
  4. Check by below specific table. Specification : See below specific table Shift lever position RPM Solenoid current (mA) ON/OFF Solenoid Pressure (kgf/cm 2 ) UD/B OD/C 26-B 35R/C LP ENG-C SS-A SS-B UD/C OD/C 26/B 35R/C LR/B RED1 RED2 ENG/C D1 2500 0 852 0 852 0 852 OFF OFF 16.3±0.5 - 0.1 Under - - 5±0.3 5.5±0.3 16.3±0.5 ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 0.6~1.4 - - - - - - - ↑ ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 2.6~3.2 - - - - - - - ↑ ↑ 500 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 4.6~5.4 - - - - - - - ↑ EOP1300 0 852 0 852 0 352 ↑ ↑ - - - - - - - 1.0~1.8 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ - - - - - - - 2.4~3.0 D2 2500 0 852 852 852 0 852 OFF OFF 15~17.5 - 16.3±0.5 0.03~0.4 - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ 352 ↑ ↑ ↑ ↑ ↑ - - 0.96~1.7 - - - - - ↑ ↑ ↑ ↑ 452 ↑ ↑ ↑ ↑ ↑ - - 2.7~3.3 - - - - - ↑ ↑ ↑ ↑ 552 ↑ ↑ ↑ ↑ ↑ - - 4.6~5.6 - - - - - D3 ↑ 0 852 0 0 0 852 OFF OFF 15~17.5 0.03~0.4 - 16.3±0.5 0.03~0.4 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ - - - 0.4~1.2 - - - - ↑ ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ ↑ - - - 2.4~3.0 - - - - ↑ ↑ ↑ ↑ ↑ 500 ↑ ↑ ↑ ↑ - - - 4.3~5.1 - - - - D4 ↑ 0 0 0 852 0 852 OFF OFF 15~17.5 15~17.5 - - - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ - 0.6~1.4 - - - - - - ↑ ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ ↑ - 2.1~2.7 - - - - - - D5 ↑ 852 0 0 0 0 852 OFF ON 0.03~0.4 16.3±0.5 - 15~17.5 - 5±0.3 5.5±0.3 15~17.5 D6 ↑ 852 0 852 852 0 852 OFF OFF - 15~17.5 15~17.5 - - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ ↑ ↑ 400 ↑ ↑ ↑ - 12.5~13.5 - - - - - - ↑ ↑ ↑ ↑ ↑ ↑ 852 ↑ ↑ ↑ - 3.9~5.1 - - - - - - L ↑ 0 0 0 852 0 852 ON OFF 15~17.5 - - - 16.3±0.5 - - - ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Above 3.9 - - - Above 3.9 5±0.3 5.5±0.3 Above 3.9 ↑ EOP1100 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Above 4.7 - - - Above 4.7 5±0.3 5.5±0.3 Above 4.7 N ↑ 852 0 0 852 0 852 ON OFF - - - - Above 6.0 5±0.3 5.5±0.3 Above 6.0 R 2500 852 852 0 0 0 852 OFF ON - - - 15~17.5 15~17.5 5±0.3 5.5±0.3
  5. Is measured oil pressure value within specific? YES Repair automatic transmission and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S41223287312013031200000) " procedure. NO Repair automatic transmission(valve body) and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S41223287312013031200000) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1271

Scheme 1271: Component Location

Pass "Stall Test" caused by hard to test at D-RANGE 6TH SPEED, go to " VERIFICATION OF VEHICLE REPAIR " procedure.

Scheme 1272

Scheme 1272: Signal Circuit Inspection
  1. Connect scantool to Data Link Connector(DLC).
  2. Engine "ON".
  3. Select "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter used select option.
  4. Engine speed up to about 2000rpm and check Input speed(PG-A)&Output speed(PG-B) are within specific at 5th speed of gear. Specification: Output speed>(input speed+200rpm)/5th. gear ratio Output speed<(input speed-200rpm)/56th. gear ratio
  5. Are measured Input speed(PG-A)&Output speed(PG-B) within specific? YES Go to " «COMPONENT INSPECTION»(ref-535826-S38214099432013031200000) " procedure. NO Check there are electrical noise at Input/output speed and Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S14479256462013031200000) " procedure.

Scheme 1273

Scheme 1273: Component Inspection
  1. Connect oil pressure gage at "3/5/R Clutch" port and "OD Clutch" port.
  2. Engine ON.
  3. Driving with 5th speed of gear at sports mode.
  4. Check by below specific table. Specification : See below specific table Shift lever position RPM Solenoid current (mA) ON/OFF Solenoid Pressure (kgf/cm 2 ) UD/B OD/C 26-B 35R/C LP ENG-C SS-A SS-B UD/C OD/C 26/B 35R/C LR/B RED1 RED2 ENG/C D1 2500 0 852 0 852 0 852 OFF OFF 16.3±0.5 - 0.1 Under - - 5±0.3 5.5±0.3 16.3±0.5 ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 0.6~1.4 - - - - - - - ↑ ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 2.6~3.2 - - - - - - - ↑ ↑ 500 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 4.6~5.4 - - - - - - - ↑ EOP1300 0 852 0 852 0 352 ↑ ↑ - - - - - - - 1.0~1.8 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ - - - - - - - 2.4~3.0 D2 2500 0 852 852 852 0 852 OFF OFF 15~17.5 - 16.3±0.5 0.03~0.4 - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ 352 ↑ ↑ ↑ ↑ ↑ - - 0.96~1.7 - - - - - ↑ ↑ ↑ ↑ 452 ↑ ↑ ↑ ↑ ↑ - - 2.7~3.3 - - - - - ↑ ↑ ↑ ↑ 552 ↑ ↑ ↑ ↑ ↑ - - 4.6~5.6 - - - - - D3 ↑ 0 852 0 0 0 852 OFF OFF 15~17.5 0.03~0.4 - 16.3±0.5 0.03~0.4 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ - - - 0.4~1.2 - - - - ↑ ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ ↑ - - - 2.4~3.0 - - - - ↑ ↑ ↑ ↑ ↑ 500 ↑ ↑ ↑ ↑ - - - 4.3~5.1 - - - - D4 ↑ 0 0 0 852 0 852 OFF OFF 15~17.5 15~17.5 - - - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ - 0.6~1.4 - - - - - - ↑ ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ ↑ - 2.1~2.7 - - - - - - D5 ↑ 852 0 0 0 0 852 OFF ON 0.03~0.4 16.3±0.5 - 15~17.5 - 5±0.3 5.5±0.3 15~17.5 D6 ↑ 852 0 852 852 0 852 OFF OFF - 15~17.5 15~17.5 - - 5±0.3 5.5±0.3 15~17.5 ↑ ↑ ↑ ↑ ↑ ↑ 400 ↑ ↑ ↑ - 12.5~13.5 - - - - - - ↑ ↑ ↑ ↑ ↑ ↑ 852 ↑ ↑ ↑ - 3.9~5.1 - - - - - - L ↑ 0 0 0 852 0 852 ON OFF 15~17.5 - - - 16.3±0.5 - - - ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Above 3.9 - - - Above 3.9 5±0.3 5.5±0.3 Above 3.9 ↑ EOP1100 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ Above 4.7 - - - Above 4.7 5±0.3 5.5±0.3 Above 4.7 N ↑ 852 0 0 852 0 852 ON OFF - - - - Above 6.0 5±0.3 5.5±0.3 Above 6.0 R 2500 852 852 0 0 0 852 OFF ON - - - 15~17.5 15~17.5 5±0.3 5.5±0.3
  5. Is measured oil pressure value within specific? YES Repair automatic transmission and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S14479256462013031200000) " procedure. NO Repair automatic transmission(valve body) and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535826-S14479256462013031200000) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1274

Scheme 1274: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1275

Scheme 1275: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1276

Scheme 1276: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1277

Scheme 1277: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1278

Scheme 1278: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1279

Scheme 1279: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1280

Scheme 1280: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1281

Scheme 1281: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1282

Scheme 1282: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1283

Scheme 1283: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1284

Scheme 1284: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1285

Scheme 1285: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1286

Scheme 1286: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1287

Scheme 1287: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1288

Scheme 1288: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1289

Scheme 1289: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1290

Scheme 1290: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1291

Scheme 1291: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1292

Scheme 1292: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1293

Scheme 1293: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1294

Scheme 1294: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1295

Scheme 1295: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1296

Scheme 1296: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1297

Scheme 1297: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1298

Scheme 1298: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 1299

Scheme 1299: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTC)" mode and then clear DTC.
  2. Operate the vehicle within DTC Enable conditions in General information.
  3. Are any DTCs recorded? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.
