Sensors
Input Speed Sensor
- Type: Hall effect sensor
- Specifications
| Operation condition (°C)°F | ((-) 40~150)) -40~302 | |
|---|---|---|
| Air gap (mm) in. | (0.95~1.65) 0.037~0.065 | |
| Output voltage (V) | High | 1.18~1.68 |
| Low | 0.59~0.84 | |
INPUT SPEED SENSOR SPECIFICATIONS
Output Speed Sensor
- Type: Hall effect sensor
- Specifications
| Operation condition (°C)°F | ((-) 40~150)) -40~302 | |
|---|---|---|
| Air gap (mm) in. | (0.55~1) 0.0217~0.0394 | |
| Output voltage | High | 1.18~1.68 |
| Low | 0.59~0.84 | |
OUTPUT SPEED SENSOR SPECIFICATIONS
Oil Temperature Sensor
- Type: Negative thermal coefficient type
- Specifications
| Temp.((°C)°F) | Resistance (kohms) |
|---|---|
| (-40)-40 | 48.1 |
| (-20)-4.0 | 15.6 |
| (0) 32.0 | 5.88 |
| (20) 68.0 | 2.51 |
| (40) 104.0 | 1.11 |
| (60) 140.0 | 0.61 |
| (80) 176.0 | 0.32 |
| (100) 212.0 | 0.18 |
| (120) 248.0 | 0.10 |
| (140) 284.0 | 0.06 |
| (150) 302.0 | 0.05 |
OIL TEMPERATURE SENSOR SPECIFICATIONS
Inhibitor Switch
- Type: Combination of output signals from 4 terminals
- Specifications
| Power supply (V) | 12 |
|---|---|
| Output type | Pin to Pin |
INHIBITOR SWITCH SPECIFICATIONS
Solenoid Valves
Direct control VFS (26/B, T/CON)
- Control type : Normal low type
| Control Pressure kPa (kgf/cm 2 , psi) | 9.81~500.14 (0.1~5.1, 1.42~72.54) |
|---|---|
| Current value (mA) | 50~850 |
| Internal resistance (ohms) | 5.1 |
SOLENOID VALVES SPECIFICATIONS
Direct control VFS (UD/B, OD/C, 35R/C)
- Control Type : Normal high type
| Control Pressure kPa (kgf/cm 2 , psi) | 500.14~9.81 (5.1~0.1, 72.54~1.42) |
|---|---|
| Current value (mA) | 50~850 |
| Internal resistance (ohms) | 5.1 |
DIRECT CONTROL VFS (UD/B, OD/C, 35R/C) SPECIFICATIONS
Line Pressure Control VFS
- Control type : Normal high type
| Control Pressure kPa (kgf/cm 2 , psi) | 500.14~9.81 (5.1~0.1, 72.54~1.42) |
|---|---|
| Current value (mA) | 50~850 |
| Internal resistance (ohms) | 5.1 |
LINE PRESSURE CONTROL VFS SPECIFICATIONS
ON/OFF Solenoid Valve (SS-A, SS-B)
- Control type : Normal low type
| Control pressure kPa (kgf/cm 2 , psi) | 490.33 (5.0, 71.12) |
|---|---|
| Internal resistance (ohms) | 10~11 |
ON/OFF SOLENOID VALVE (SS-A, SS-B) SPECIFICATIONS
Lubricants
| Item | Specified lubricant | Quantity |
|---|---|---|
| Transaxle fluid | SK ATF SP-IV, MICHANG ATF SP-IV, NOCA ATF SP-IV, Kia Genuine ATF SP-IV or other brands meeting the above specification approved by Kia Motors Corp. | 7.1L (1.88 U.S gal., 7.50 U.S.qt., 6.24 lmp.qt.) |
LUBRICANTS SPECIFICATIONS
Sealant
| Item | Specified sealant |
|---|---|
| Rear cover | LOCTITE FMD-546 or THREE-BOND TB1281B |
| Torque converter housing | |
| Valve body cover |
SEALANT SPECIFICATIONS
Special Service Tools
SPECIAL SERVICE TOOLS CHART Tools (Number and name) Illustration Use 09200-38001 Engine support fixture Removal and installation of the transaxle. 09453-3L240 Oil seal installer Installation of transaxle case oil seal. (Using with handle (SST No.:09231-H1100)) 09231-H1100 Bar Installation of transaxle case oil seal. (Using with oil seal installer (SST No.:09453-3L240))
