Automatic Transaxle Control System (A6LF2) - 2.0L: Removal & Installation Kia Optima III

Automatic Trans 17 illustrations ~1237 words

Installation

  1. Installation is reverse of removal. NOTE: In the case of the vehicle equipped with immobilizer or button engine start system, perform "Key Teaching" procedure together. Refer to «TEACHING PROCEDURES»(ref-429553-S12950411932011101500000) .
  1. Installation is the reverse of removal. NOTE: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to «HYDRAULIC SYSTEM (FLUID)»(ref-429560-S16638232802011101500000) .
  1. Installation is the reverse of removal. NOTE: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to «HYDRAULIC SYSTEM (FLUID)»(ref-429560-S16638232802011101500000) .
  1. Installation is the reverse of removal. NOTE: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to «HYDRAULIC SYSTEM (FLUID)»(ref-429560-S16638232802011101500000) .

Removal

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Scheme 91

Scheme 91: Removal
Scheme 91: Removal

Scheme 92

Scheme 92
Scheme 92

Scheme 93

Scheme 93
Scheme 93

Scheme 94

Scheme 94
Scheme 94
  1. Remove the battery and the battery tray. Refer to «BATTERY»(ref-429541-S17247731372011101500000) .
  2. Remove the under cover (A). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. Refer to «HYDRAULIC SYSTEM (FLUID)»(ref-429560-S16638232802011101500000) .
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 13.8~14.7 N.m (1.3~1.5kgf.m, 9.4~10.8 lb-ft) 34.3~44.1 N.m (3.5~4.5kgf.m, 25.3~32.6 lb-ft) CAUTION: Always replace the gasket of the eyebolt use new one whenever loosening eyebolt. NOTE: Remove installation bolts in the engine compartment first.
  5. Remove the bolt (3 ea) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  6. Remove the solenoid valve (A) after removing the solenoid support.

Scheme 95

Scheme 95: Installation
Scheme 95: Installation
  1. Installation is the reverse of removal. NOTE: When installing, apply the ATF oil or white Vaseline to the O-ring (A) not to be damaged. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to «HYDRAULIC SYSTEM (FLUID)»(ref-429560-S16638232802011101500000) .

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. Refer to VALVE BODY .

Scheme 96

Scheme 96: Removal
Scheme 96: Removal

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99
  1. Remove the battery and the battery tray. Refer to «BATTERY»(ref-429541-S17247731372011101500000) .
  2. Remove the under cover (A). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. Refer to «HYDRAULIC SYSTEM (FLUID)»(ref-429560-S16638232802011101500000) .
  4. Remove the valve body cover (B) and eyebolt (A). Tightening torque: 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) 13.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) CAUTION: Always replace the gasket of the eyebolt use new one whenever loosening eyebolt. NOTE: Remove installation bolts in the engine compartment first.
  5. Remove the bolt (3 ea) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  6. Remove the solenoid valve (A) after removing the solenoid support.

Scheme 100

Scheme 100: Installation
Scheme 100: Installation
  1. Installation is the reverse of removal. NOTE: When installing, apply the ATF oil or white Vaseline to the O-ring (A) not to be damaged. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name : Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Refer to «HYDRAULIC SYSTEM (FLUID)»(ref-429560-S16638232802011101500000) .
  1. Installation is the reverse of removal.

Scheme 101

Scheme 101: Components
Scheme 101: Components

Shift Lever Assembly Replacement

Scheme 102

Scheme 102: Removal
Scheme 102: Removal

Scheme 103

Scheme 103
Scheme 103

Scheme 104

Scheme 104
Scheme 104
  1. Remove the center console assembly. Refer to «INTERIOR (CONSOLE)»(ref-429563-S42679254862011101500000) .
  2. Disconnect sports mode connector (A).
  3. Remove the shift cable (B).
  4. Remove the shift lever assembly (B) by removing the bolts (A-4ea). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.9 lb-ft)
  5. Installation is the reverse of removal. NOTE: Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.

Scheme 105

Scheme 105: Control Cable Replacement
Scheme 105: Control Cable Replacement

Scheme 106

Scheme 106
Scheme 106

Scheme 107

Scheme 107
Scheme 107
  1. Remove the center console assembly. Refer to «INTERIOR (CONSOLE)»(ref-429563-S42679254862011101500000) .
  2. Remove the control cable (B).
  3. Remove the control cable assembly in the vehicle after removing the nuts (B) and the retainer (A). Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.9 lb-ft)
  4. Remove the nut (C).
  5. Remove the cable (B) from the bracket (A) at transaxle assembly side. Refer to «AUTOMATIC TRANSAXLE»(ref-429557-S08988038382011101500000) .
  6. Remove the control cable inside of cab.
  1. Installation is the reverse of removal. NOTE: Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.
