Automatic Transaxle Control System (A6MF2) - 2.4L: Other Kia Optima III

TCM Learning

When shift shock is occurred or parts related with the transaxle are replaced, TCM learning should be performed.

In the following case, TCM learning is required.

1. Transaxle assembly replacement
2. TCM replacement
3. TCM upgrading

1. TCM learning condition ATF temperature: 40~100°C (104~212°F)
2. TCM learning procedure

Scheme 224

1. Stop learning Repeat the below shift pattern four times or more with stepping on the brake.
2. Driving learning

1. Drive the vehicle through all gears at D range. Drive from stop to 1st to 2nd to 3rd to 4th to 5th to 6th with keeping fixed throttle open.
2. Down shift from 6th to 5th, 5th to 4th, 4th to 3rd, 3rd to 2nd, 2nd to 1st.
3. Repeat the above driving pattern four times or more. Up-shift throttle open : 15~30%

Scheme 225

Scheme 226

Scheme 227

Functions

1. Monitors the vehicle's operating conditions to determine the optimal gear setting.
2. Performs a gear change if the current gear setting differs from the identified optimal gear setting.
3. Determines the need for damper clutch (D/C) activation and engages the clutch accordingly.
4. Calculates the optimal line pressure level by constantly monitoring the torque level and adjusts the pressure accordingly.
5. Diagnoses the automatic transaxle for faults and failures.

Scheme 228

Scheme 229

TCM Terminal Function

Connector (CHG-AG)

PIN DESCRIPTION CHART

TCM Terminal Input/Output Signal

Connector (CHG-AG)

PIN DESCRIPTION CHART

Scheme 230

Scheme 231

Signal Code Table

SIGNAL CODE CHART

Scheme 232

Scheme 233

Scheme 234

Scheme 235

1. Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.
2. Remove the battery and the battery tray. Refer to «BATTERY»(ref-429624-S21182795222011101500000) .
3. Remove the air cleaner assembly. Refer to «INTAKE MANIFOLD»(ref-429620-S13854361072011101500000) .
4. Remove the shift cable mounting nut (B).
5. Disconnect the inhibitor switch connector (A).
6. Remove the manual control lever (A) and the washer (B) after removing a nut (C). CAUTION: When installing, affix the manual control lever and the inhibitor switch with Ø5 mm (0.1969 in.). Then tighten the inhibitor assembly mounting bolts.
7. Remove the inhibitor assembly (A) after removing the bolts (2 ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: When installing, tighten the inhibitor assembly mounting bolt lightly, so that necessary adjustments can be made. Tighten to specifications.
