Automatic Transaxle Control System (A6LF2) - 2.0L: Specifications Kia Optima III

Automatic Trans 16 illustrations ~209 words

Specifications

Type: Negative Thermal Coefficient Type

Temp.((°C) °F)Resistance (kohms)
(-40)-4048.1
(-20)-4.015.6
(0) 32.05.88
(20) 68.02.51
(40) 104.01.11
(60) 140.00.61
(80) 176.00.32
(100) 212.00.18
(120) 248.00.10
(140) 284.00.06
(150) 302.00.05

TEMPERATURE AND RESISTANCE REFERENCE CHART

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38: Circuit Diagram
Scheme 38: Circuit Diagram

Type: Hall effect sensor

Operation condition (°C (°F))((-) 40~150)) -40~302
Air gap (mm) in.(0.95~1.65) 0.037~0.065
Output voltage (V)High1.18~1.68
Low0.59~0.84

HALL EFFECT SENSOR SPECIFICATION CHART

Scheme 39

Scheme 39: Circuit Diagram
Scheme 39: Circuit Diagram

Scheme 40

Scheme 40: Signal Waveform
Scheme 40: Signal Waveform

Scheme 41

Scheme 41
Scheme 41

Type: Hall effect sensor

Operation condition (°C (°F))((-) 40~150)) -40~302
Air gap (mm) in.(0.55~1) 0.0217~0.0394
Output voltageHigh1.18~1.68
Low0.59~0.84

HALL EFFECT SENSOR SPECIFICATION CHART

Scheme 42

Scheme 42: Circuit Diagram
Scheme 42: Circuit Diagram

Scheme 43

Scheme 43: Signal Waveform
Scheme 43: Signal Waveform

Scheme 44

Scheme 44
Scheme 44

Direct control VFS (T/CON)

Control type : Normal low type

Control Pressure kPa (kgf/cm 2 , psi)9.81~500.14 (0.1~5.1, 1.42~72.54)
Current value (mA)50~850
Internal resistance (ohms)5.1

DIRECT CONTROL SPECIFICATION CHART

Scheme 45

Scheme 45: Circuit Diagram
Scheme 45: Circuit Diagram

Direct control VFS (26/B)

Control type : Normal low type

Control Pressure kPa (kgf/cm 2 , psi)9.81~500.14 (0.1~5.1, 1.42~72.54)
Current value (mA)50~850
Internal resistance (ohms)5.1

DIRECT CONTROL SPECIFICATION CHART

Scheme 46

Scheme 46: Circuit Diagram
Scheme 46: Circuit Diagram

Direct control VFS (LINE Pressure)

Control type : Normal low type

Control Pressure kPa (kgf/cm 2 , psi)500.14~9.81 (5.1~0.1, 72.54~1.42)
Current value (mA)50~850
Internal resistance (ohms)5.1

DIRECT CONTROL VFS SPECIFICATION CHART

Scheme 47

Scheme 47: Circuit Diagram
Scheme 47: Circuit Diagram

Direct control VFS (35R/C)

Control type : Normal low type

Control Pressure kPa (kgf/cm 2 , psi)500.14~9.81 (5.1~0.1, 72.54~1.42)
Current value (mA)50~850
Internal resistance (ohms)5.1

DIRECT CONTROL VFS SPECIFICATION CHART

Scheme 48

Scheme 48: Circuit Diagram
Scheme 48: Circuit Diagram

Direct control VFS (35R/C)

Control type : Normal low type

Control Pressure kPa (kgf/cm 2 , psi)500.14~9.81 (5.1~0.1, 72.54~1.42)
Current value (mA)50~850
Internal resistance (ohms)5.1

DIRECT CONTROL VFS SPECIFICATION CHART

Scheme 49

Scheme 49: Circuit Diagram
Scheme 49: Circuit Diagram

Direct control VFS (35R/C)

Control type : Normal low type

Control Pressure kPa (kgf/cm 2 , psi)500.14~9.81 (5.1~0.1, 72.54~1.42)
Current value (mA)50~850
Internal resistance (ohms)5.1

DIRECT CONTROL VFS SPECIFICATION CHART

Scheme 50

Scheme 50: Circuit Diagram
Scheme 50: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

Control type : Normal low type

Control pressure kPa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10~11

ON/OFF SOLENOID VALVE SPECIFICATION CHART

Scheme 51

Scheme 51: Circuit Diagram
Scheme 51: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

Control type : Normal low type

Control pressure kPa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10~11

ON/OFF SOLENOID VALVE SPECIFICATION CHART

Scheme 52

Scheme 52: Circuit Diagram
Scheme 52: Circuit Diagram

Type: Combination of output signals from 4 terminals

Power supply (V)12
Output typeCombination of output signals

VOLTAGE SPECIFICATION CHART
